User Manual
F24T40*
The colour and the appearance may differ depending on the product, and the specifications are subject to change without
prior notice to improve the performance.
The contents of this manual are subject to change without notice to improve quality.
© Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.
Trademarks other than that of Samsung Electronics are owned by their respective owners.
An administration fee may be charged in the following situations:
(a) An engineer is called out at your request, but it is found that the product has no defect (i.e., where the user manual has
not been read).
(b) You bring the unit to a repair centre, but it is found that the product has no defect (i.e., where the user manual has not
been read).
You will be informed of the administration fee amount before a technician visits.
Advertisement
Table of Contents
Related Manuals for Samsung F24T40 Series
Summary of Contents for Samsung F24T40 Series
- Page 1 © Samsung Electronics Samsung Electronics owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited. Trademarks other than that of Samsung Electronics are owned by their respective owners.
-
Page 2: Table Of Contents
Setting Optimum Resolution settings Parts Control Panel Transparency Function Key Guide Screen Setup Direct Key guide Position Types of Ports SAMSUNG MAGIC Bright Language Anti-theft Lock Brightness Display Time Installation Attaching the Stand Contrast Precautions for moving the product Sharpness... - Page 3 Table of contents Setup and Reset Troubleshooting Guide Appendix FreeSync Requirements Before Contacting Samsung Responsibility for the Pay Service (Cost to Customer Service Centre Customers) Eco Saving Plus Testing the Product Not a product defect Checking the Resolution and Frequency...
-
Page 4: Before Using The Product
Chapter 01 Before Using the Product Securing the Installation Space Safety Precautions Ensure some space around the product for ventilation. An internal temperature rise may cause fire and Warning A serious or fatal injury may result if instructions are not followed. damage the product. -
Page 5: Cleaning
• Do not use a damaged power cord or plug, or a loose power socket. ― Contact your nearest Samsung Customer Service Centre if you want to clean the inside of the product (Service fee will be charged.) •... -
Page 6: Installation
‒ The product lifespan may be reduced or a fire may result. ‒ Be sure to consult Samsung Customer Service Centre if you want to install the product at such a •... -
Page 7: Operation
‒ Be sure to power off the product and disconnect the power cord when water or other foreign ‒ Contact Samsung Customer Service Centre for repairs. substances have entered the product. Then contact Samsung Customer Service Centre. • To move the product, first disconnect all the cables from it, including the power cable. - Page 8 Caution • Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage • Do not touch the screen when the product has been turned on for an extended period of time as it burn-in or defective pixels.
-
Page 9: Preparations
Chapter 02 Preparations Parts Icons Description Multi directional button that helps navigate. JOG Button ― The JOG button is located on the rear left side of the product. The button can be used to move up, down, left or right, or as Enter. Control Panel This LED is power status indicator and works as •... -
Page 10: Function Key Guide
Press to enable or disable Eye Saver Mode. The items below are not available if the Eye Saver Mode function is enable. • Picture → SAMSUNG Bright, Brightness, Color, Game Mode MAGIC • System → Eco Saving Plus Selects to turn the product off by moving the JOG button in the Function Key Guide screen. -
Page 11: Direct Key Guide
Direct Key guide Types of Ports ― On the Direct Key Guide screen, the following menu options appear when the product screen is switched on ― The functions available may vary depending on the product model. The colour and shape of parts may differ or the input source is changed. -
Page 12: Anti-Theft Lock
Anti-theft Lock ― An anti-theft lock allows you to use the product securely even in public places. ― The locking device shape and locking method depend on the manufacturer. Refer to the user guide provided with your anti-theft locking device for details. To lock an anti-theft locking device: Fix the cable of your anti-theft locking device to a heavy object such as a desk. -
Page 13: Installation
Installation Attaching the Stand ― Before assembling the product, place the product down on a flat and stable surface so that the screen is facing downwards. ― The exterior may differ depending on the product. ― Disassembly is the reverse order of assembly. Place a protective cloth or cushion on a flat Do not remove the fixing pin until you are Insert the stand base into the stand in the... -
Page 14: Precautions For Moving The Product
Precautions for moving the product Adjusting the Product Tilt and Height ― The colour and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. -3° (±2°) ~ +25° (±2°) 0 (±2 mm) - 130 mm (±2 mm) •... -
Page 15: Rotating The Product
Rotating the Product Installing a Wall-mount Kit or Desktop Stand ― The colour and shape of parts may differ from what is shown. Specifications are subject to change without ― Power the product off and remove the power cable from the power socket. notice to improve quality. - Page 16 ‒ Samsung shall not be held liable for any product damage or personal injury caused by using a wall-mount kit other than the one specified or from an attempt to install the wall-mount kit on your own.
-
Page 17: Connecting And Using A Source Device
Chapter 03 Connecting and Using a Source Device Read below before installing the product. Connecting and Using a PC Before installing the product, check the shapes of both ports of the supplied signal cables and the Select a connection method suitable for your PC. shapes and locations of the ports on the product and external device. -
Page 18: Connection Using The Hdmi Or Hdmi-Dvi Cable
Connection Using the HDMI or HDMI-DVI Cable Connecting the Power Connect the power cable to the AC/DC adapter. Then, connect the AC/DC adapter to the DC 14V port on the back of the product. Next, connect the power cable to the power outlet. Press the JOG button on the back of the product to turn it on. -
Page 19: Correct Posture To Use The Product
Driver Installation ― You can set the optimum resolution and frequency for this product by installing the corresponding drivers. ― To install the latest version of the product driver, download it from the Samsung Electronics website at http://www.samsung.com. Setting Optimum Resolution An information message about setting optimum resolution will appear if you power on the product for the first time after purchase. -
Page 20: Screen Setup
Configure the screen settings such as brightness. A detailed description of each function is provided. Refer to your product for details. The functions available on the product may vary depending on the model. Refer to the actual product. SAMSUNG MAGIC Bright mode •... -
Page 21: Brightness
You can adjust the general brightness of the picture. (Range: 0~100) Adjust the tint of the screen. A higher value will make the picture appear brighter. ― This menu is not available when SAMSUNG Bright is set to Cinema Dynamic Contrast mode. -
Page 22: Samsung Magic Upscale
SAMSUNG MAGIC Upscale Eye Saver Mode Upscale function can enhance the layers of the picture details and the vividness of the picture. Set to an optimum picture quality suitable for eye relaxation. SAMSUNG MAGIC The function has more obvious effects on low-resolution pictures. -
Page 23: Picture Size
Picture Size Screen Adjustment Change the picture size. ― This menu is available in Analog mode only. ― This option is not available when FreeSync is enabled. ― This menu is only available when Picture Size is set to Screen Fit Mode. -
Page 24: Adjusting Osd (On Screen Display) Settings
Chapter 05 Adjusting OSD (On Screen Display) settings A detailed description of each function is provided. Refer to your product for details. The functions available on the product may vary depending on the model. Refer to the actual product. Transparency Position Set the transparency for the menu windows. -
Page 25: Setup And Reset
• The response rate during the game may fluctuate depending on the resolution. A higher resolution generally decreases the response rate. ― If you encounter any issues when using the function, contact the Samsung Service Centre. - Page 26 The models in the Graphic Cards list supports FreeSync FreeSync can only be used with specific AMD graphics card models. Refer to the following list for supported graphics cards: Make sure to install the latest official graphics drivers from AMD that support FreeSync. ―...
-
Page 27: Eco Saving Plus
Reduce energy consumption compared to consumption at the maximum brightness level. PC/AV Mode to AV. The picture size will be enlarged. This option is useful when you view a movie. ― This option is not available when SAMSUNG Bright is in Dynamic Contrast mode. -
Page 28: Power Led On
Power LED On Information Configure the settings to enable or disable the power LED located at the lower part of the product. View the current input source, frequency and resolution. • Working: The power LED is on when the product is turned on. Information •... -
Page 29: Installing The Software
Easy Setting Box enables users to use the product by partitioning multiple sections. • Windows 10 32Bit/64Bit To install the latest version of Easy Setting Box, download it from the Samsung Electronics website at http://www.samsung.com. ― The software may not work properly if you do not restart the PC after the installation. -
Page 30: Troubleshooting Guide
Check the following. Customer Service Centre Installation issue (PC mode) ― Before calling Samsung Customer Service Centre, test your product as follows. If the problem persists, contact Samsung Customer Service Centre. The screen keeps switching on and off. Check the cable connection between the product and PC, and ensure the connectors are locked. - Page 31 Not Optimum Mode is displayed. There is no image on the screen and the power LED blinks every 0.5 to 1 second. This message appears when the signal from the graphics card exceeds the maximum resolution or The product is operating in power-saving mode. frequency for the product.
-
Page 32: Q & A
Q & A ― Refer to the user manual for your PC or graphics card for further instructions on adjustment. How can I change the frequency? Set the frequency on your graphics card. • Windows 7: Go to Control Panel → Appearance and Personalization → Display → Screen Resolution → Advanced settings → Monitor, and adjust Screen Refresh Rate under Monitor settings. •... -
Page 33: Specifications
Based on the AC voltage of the adapter. For the DC voltage of the ― The above specifications are subject to change without notice to improve quality. product, refer to the product label. ― For detailed device specifications, visit the Samsung Electronics website. Signal connectors D-SUB, HDMI... -
Page 34: Standard Signal Mode Table
Standard Signal Mode Table Model Name F24T40* Synchronization Horizontal Frequency 30 – 81 kHz Vertical Frequency 56 – 75 Hz Resolution Optimum Resolution 1920 x 1080 @ 60 Hz Maximum Resolution 1920 x 1080 @ 60 Hz If a signal that belongs to the following standard signal modes is transmitted from your PC, the screen will automatically be adjusted. If the signal transmitted from the PC does not belong to the standard signal modes, the screen may be blank even though the power LED turns on. - Page 35 Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Pixel Clock (MHz) Sync Polarity (H/V) VESA DMT, 1440 x 900 55.935 59.887 106.500 VESA DMT, 1600 x 900 60.000 60.000 108.000 VESA DMT, 1680 x 1050 65.290 59.954 146.250 VESA DMT, 1920 x 1080 67.500 60.000 148.500...
-
Page 36: Appendix
• Use of supplies or separately sold product unspecified by Samsung. • Repair from a person besides an engineer of outsourcing service company or partner of Samsung Not a product defect Electronics Co., Ltd. • Remodeling or repairing the product by customer.
