Quick Installation Guide
TEG-524WS (V1)

Advertisement

loading

Related Manuals for TRENDnet TEG-524WS

Summary of Contents for TRENDnet TEG-524WS

  • Page 1 Quick Installation Guide TEG-524WS (V1)
  • Page 2 Table of Contents 1 English 1. Before You Start 2. Hardware Installation and Configuration...

  • Page 3: Before You Start

    1. Before You Start Package Contents TEG-524WS Ÿ Quick Installation Guide Ÿ CD-ROM (Utility and User's Guide) Ÿ Power cord (1.8m / 6 ft.) Ÿ Rack mount kit Ÿ Minimum Requirements Computer with an Ethernet port and web browser Ÿ...

  • Page 4: Hardware Installation And Configuration

    2. Hardware Installation and Configuration TEG-524WS 3. Assign a Static IP address to your computer's network adapter in the subnet of 192.168.10.x (e.g. 192.168.10.25) and a subnet mask of 255.255.255.0. 4. Open your web browser, type the IP address of the switch in the address bar, and then press Enter.
  • Page 5 5. Enter the User name and Password, and then click Login. By default: User Name: admin Password: admin Note: User Name and Password are case sensitive. 6. Click System and then click IPv4 Setup. 7. Configure the switch to match the requirements of your network. Then click Apply. Switch Info IPv4 Setup System...

  • Page 6: Save Settings To Flash

    IP Address, change the password, and upgrade new firmware, then install the Web Smart Switch Management Utility. Follow the steps provided on the User's Guide. 2. For detailed information regarding the TEG-524WS’s configuration and advanced settings, please refer to the User's Guide on the provided CD-ROM.
  • Page 7 Product Name: 52-Port Gigabit Web Smart Switch Trade Name: TRENDnet TRENDnet hereby declare that the product is in compliance with the essential requirements and other relevant provisions under our sole responsibility. Safety EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 EN 55032:2012+AC: 2013 (CISPR32:2012) (Class A)
  • Page 8 Product Warranty Registration If you have any questions regarding the product Please take a moment to register your installation, please contact our Technical Support. product online. Go to TRENDnet’s website at: Toll free US/Canada: 1-866-845-3673 www.trendnet.com/register Regional phone numbers available at www.trendnet.com/support...
