Amtrol EXTROL LBC Series Replacement Instructions

NOTE: Inspect for shipping damage and notify freight carrier or store where purchased immediately if damage is present. To avoid risk of personal
injury and property damage, if the product appears to be malfunctioning or shows signs of corrosion, call a licensed professional immediately.
Current copies of the Product manual can be viewed at www.amtrol.com. Use proper safety equipment when installing.
THIS IS THE SAFETY ALERT SYMBOL. IT IS USED TO ALERT YOU TO POTENTIAL PERSONAL INJURY AND
OTHER HAZARDS. OBEY ALL SAFETY MESSAGES THAT FOLLOW THIS SYMBOL TO REDUCE THE RISK OF
PERSONAL INJURY AS WELL AS PROPERTY DAMAGE.
READ CAREFULLY THE EXTROL REPLACEMENT
BLADDER INSTRUCTIONS TO AVOID SERIOUS
PERSONAL INJURY AND PROPERTY HAZARDS AND TO ENSURE SAFE
USE AND PROPER CARE OF THIS PRODUCT.
EXPLOSION OR RUPTURE HAZARD. THE EXPANSION
TANK MUST BE OPERATED SO THAT THE
PRESSURE DOES NOT EXCEED THE MAXIMUM WORKING PRESSURE.
This Product, like most Products under pressure, may
over time corrode, weaken and burst or explode, causing
serious or fatal injury, leaking or flooding and/or property damage. To minimize
risk, a licensed professional must install and periodically inspect and service the
Product. A drip pan connected to an adequate drain must be installed if leaking
or flooding could cause property damage. Do not locate in an area where
leaking could cause property damage to the area adjacent to the appliance or
to lower floors of the structure.
EXPLOSION HAZARD. Failure to follow instructions in
the accompanying product manual can cause rupture or
explosion, possibly causing serious or fatal injury, leaking or flooding and/or
property damage.
This product can expose you to chemicals including lead,
which is known to the State of California to cause cancer
and birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov.
EXTROL
REPLACEMENT BLADDER INSTRUCTIONS
Models 35-LBC through 600-LBC
Nut
Adapter
Diffuser
Drain
Stand
LBC SERIES
®
Lifting
Ring
Flange Ring
Blind Flange
Elbow
Air Charge
Lifting
Ring
Bladder
