Graco RS 24P947 Instructions Manual

Gun auto kit

Download this manual

Instructions - Parts

24P947 RS

Auto Kit

For use with the RS Gel Coat Gun. Allows conversion of a standard RS Gel Coat Gun to an

auto robotic version.

Important Safety Instructions

Read all warnings and instructions in this

manual and the RS Gun and Cutter manual.

Save these instructions.

™

Gun

332134A

Page 1 Instructions - Parts ™ 24P947 RS Auto Kit 332134A For use with the RS Gel Coat Gun. Allows conversion of a standard RS Gel Coat Gun to an auto robotic version. Important Safety Instructions Read all warnings and instructions in this manual and the RS Gun and Cutter manual.
Page 2: Installation
Installation Installation NOTICE To avoid personal injury, following all shutdown and pressure relief procedures of the machine to allow the installation of the kit. 1. Remove trigger guard. 3. Mount the RS auto bracket. 25.4 mm 31.8 mm M8 x 1.25 50.8 mm 2.
Page 3 Installation 5. Supply the gun solenoid with a 24 VDC signal. 7. Connect the air lines from the gun manifold to the air cylinders. Refer to Parts, page 4, for pneumatic NOTE: The 24 VDC will be used to trigger the gun. connections.
Page 4 Parts Parts 332134A...
Page 5 Parts Quantity 24P947, KIT, mounting, auto, rs Part Description 124806 VALVE, solenoid, atex 124807 MANIFOLD, 2 station 125007 PLATE, blanking 11021-24 PLUG, pipe, soc, 3/8, zp 111881 MUFFLER 23581-00 CYLINDER, bimba, 7/8bore 23582-00 BRACKET, mtg, bimba 94/0499/96 ADAPTER, hex, 1/4nptx1/8npt, mxm, brs 94/0500/96 FITTING, elbow, 1/4npt, f, 90deg, brs 94/0507/96...
