APPLICANT: MOTOROLA, INC.
FCC ID: IHDT6FF1
INSTRUCTION MANUAL
An English version preliminary draft copy of the Users Manual follows:
EXHIBIT 8

Advertisement

Table of Contents
loading

Related Manuals for Motorola V360

Summary of Contents for Motorola V360

  • Page 1 APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FF1 INSTRUCTION MANUAL An English version preliminary draft copy of the Users Manual follows: EXHIBIT 8...
  • Page 2 V360...
  • Page 4 HELLOMOTO Introducing your new Motorola V360 GSM wireless phone. Here’s a quick anatomy lesson. Open menus. Navigate menus. Select menu items. Left Soft Key Right Soft Key Volume Keys Voice dial. PTT/Smart Key Make & answer calls. Turn on & off, hang up, exit menus.
  • Page 5 1307 East Algonquin Road Schaumburg, IL 60196 www.hellomoto.com MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.

  • Page 6: Feature Locator

    feature locator main menu á Phonebook Web Access • Browser Recent Calls • Web Shortcuts • Received Calls • Stored Pages • Dialed Calls • History • Notepad • Go To URL • Call Times * • Browser Setup • Call Cost * •...
  • Page 7 settings menu Personalize Headset • Home Screen • Auto Answer • Main Menu • Voice Dial • Skin Car Settings • Greeting • Auto Answer • Wallpaper • Auto Handsfree • Screen Saver • Power-Off Delay Ring Styles • Charger Time •...

  • Page 8: Table Of Contents

    contents feature locator..3 basics....31 display... . . 31 Safety Information .
  • Page 9 calls ....48 index ....87 turn off a call alert . . . 48 recent calls .

  • Page 10: Safety Information

    RF energy. When you communicate with your phone, the system handling your call controls the power level at which your phone transmits. Your Motorola phone is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.
  • Page 11 If you do not use one of the body-worn accessories approved or supplied by Motorola, and are not using the phone held in the normal use position, ensure the phone and its antenna are at least 2.5 centimeters (1 inch) from your body when transmitting.
  • Page 12 Facilities Turn off your phone in any facility where posted notices instruct you to do so. These facilities may include hospitals or health care facilities that may be using equipment that is sensitive to external RF energy. Aircraft Turn off your wireless device whenever instructed to do so by airline staff. If your device offers a flight mode or similar feature, consult airline staff about use in flight.
  • Page 13 • Pull off the road and park before making or answering a call if driving conditions so require. Responsible driving best practices can be found in the “Wireless Phone Safety Tips” at the end of this guide and/or at the Motorola website: www.motorola.com/callsmart. Operational Warnings...
  • Page 14 If your phone or battery has been submerged in water, punctured, or subjected to a severe fall, do not use it until you take it to a Motorola Authorized Service Center to determine if it has been damaged. Do not attempt to dry it with an external heat source, such as a microwave oven.
  • Page 15 Symbol Definition Important safety information will follow. 032374o Your battery or phone should not be disposed of in a 032376o fire. Your battery or phone may require recycling in 032375o accordance with local laws. Contact your local regulatory authorities for more information. Your battery or phone should not be thrown in the trash.
  • Page 16 occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. To limit the likelihood of such symptoms, please take the following safety precautions: • Do not play or use a flashing-lights feature if you are tired or need sleep.

  • Page 17: Eu Conformance

    European Union Directives Conformance Statement EU Conformance Hereby, Motorola declares that this product is in compliance with: • The essential requirements and other relevant provisions of Directive 1999/5/EC • All other relevant EU Directives 0168 Product Approval Number The above gives an example of a typical Product Approval Number.

  • Page 18: Recycling Information

    Recycling Information Caring for the Environment by Recycling When you see this symbol on a Motorola product, do not dispose the product with household waste. Recycling Mobile Phones and Accessories Do not dispose of mobile phones or electrical accessories, such as chargers or headsets, with your household waste.

  • Page 19: Essentials

    essentials about this guide This guide shows how to locate a menu feature as follows: Find it: Press M > Recent Calls > Dialed Calls This example shows that, from the home screen, you press M to open the menu, highlight and select s Recent Calls, then highlight and select Dialed Calls.

  • Page 20: Battery

    battery battery installation essentials...
  • Page 21 Use the travel charger. battery tips Battery life depends on the network, signal strength, temperature, features, and accessories you use. • Always use Motorola Original batteries and chargers. The warranty does not cover damage caused by non-Motorola batteries and/or chargers.

  • Page 22: Turn It On & Off

    • Never expose batteries to temperatures below -10°C (14°F) or above 45°C (113°F). Always take your phone with you when you leave your vehicle. • It is normal for batteries to gradually wear down and require longer charging times. If you notice a change in your battery life, it is probably time to purchase a new battery.

  • Page 23: Make A Call

    make a call Enter a phone number and press n to make a call. To “hang up, ” close the flip or press o. answer a call Note: Your phone cannot receive data over an EDGE network while it is playing videos or some sound files. The EDGE È status indicator appears at the top of your display when you can receive data over an EDGE network.

  • Page 24: Main Attractions

    main attractions You can do much more with your phone than make and receive calls! take & send a photo Press j to see the camera viewfinder: Press Remaining up or down to photos you zoom in or can capture. IMAGE out.
  • Page 25 • To delete the photo and return to the active viewfinder, press the DISCARD key. • To store or send the photo, press the STORE key. When the viewfinder is active, press M to open the Pictures Menu: option Go To Pictures View stored pictures and photos.

  • Page 26: Record Video

    record video Press M > Multimedia > Video Camera to see the video viewfinder. Press Remaining up or down to clips you can zoom in or out. capture VIDEO CLIP AREA Start video capture. Video Clip Name Press 10 Remaining left or right to BACK CAPTURE...

  • Page 27: Cable Connections

    To transfer data between your phone and computer, you must install the software included with the Motorola Original data kit. See the data kit user’s guide for more information. main attractions...

  • Page 28: Memory Card

    To make data and fax calls through a connected computer, see page 72. memory card You can use a removable memory card with your phone to store and retrieve multimedia objects (such as photos and sounds). Note: If you download a copyrighted file and store it on your memory card, you can use the file only while your memory card is inserted in your phone.
  • Page 29 Press M > Settings > Connection > USB Settings > Memory Card. This directs the USB connection to your memory card. Attach the Motorola Original USB cable to the accessory port on your phone and to an available USB port on your computer. Then follow these...

  • Page 30: Bluetooth® Wireless

    3 To store the desired files onto the memory card, drag and drop them as follows: MP3 files: > mobile > audio screen savers: > mobile > picture wallpapers: > mobile > picture video clips: > mobile > video 4 When you finish, remove the device by selecting the “Safely Remove Hardware”...
  • Page 31 If Bluetooth Power is On, your phone can automatically pair with the handsfree device you have used before. Just turn on the device or move it near the phone. Note: To extend battery life, use the above procedure and set Bluetooth Power to Off when not in use.
  • Page 32 copy objects to another device You can use Bluetooth pairing to copy a media object, phonebook entry, datebook event, or bookmark from your phone to a computer or other device. 1 Highlight the object on your phone that you want to copy to the other device.
  • Page 33 feature move Move a multimedia object to multimedia another device: object to Highlight the object, press M > Move, device select the device name. Caution: Moving an object deletes the original object from your phone. edit device Edit the properties of a recognized properties device: Highlight the device name, press the...

  • Page 34: Basics

    basics See page 1 for a basic phone diagram. display The home screen displays when you turn on the phone. To dial a number from the home screen, press number keys and Note: Your home screen may look different from the one below, depending on your service provider.
  • Page 35 Status indicators can display at the top of the home screen: 1. Signal 8. Battery Strength Level Service Provider 2. EDGE / 7. Ring Style GPRS 12:00 040079b 3. PTT / Data News and graphics from 6. Message your Service Provider 4.
  • Page 36 4 = secure packet data 7 = unsecure packet data transfer transfer 3 = secure application 6 = unsecure application connection connection 2 = secure Circuit Switch 5 = unsecure CSD call Data (CSD) call à = Bluetooth® connection is active 4 Roam Indicator –...

  • Page 37: Menus

    7 Ring Style Indicator – Shows the ring style setting. y = loud ring Ó = vibrate then ring z = soft ring Ò = silent | = vibrate 8 Battery Level Indicator – Vertical bars show the battery charge level. Recharge the battery when your phone shows Low Battery.
  • Page 38 The following menu icons may be available, depending on your service provider and service subscription options. menu features n Phonebook h Multimedia e Messages E Bluetooth Link s Recent Calls w Settings É Tools I Camera Q Games & Apps M Datebook á...

  • Page 39: Text Entry

    • In an alphabetized list, press a key repeatedly to cycle through its letters and highlight the closest matching list option. • When an option has a list of possible settings, scroll left or right to select the setting. • When an option has a list of possible numeric values, press a number key to set the value.
  • Page 40 Press # in a text entry screen to select an entry mode: entry mode j or g Your Primary text entry mode can be set to any iTAP® j or tap g mode. p or m Your Secondary text entry mode can be set to any iTAP p or tap m mode, or set to None if you don’t want a secondary entry mode.
  • Page 41 For example, if you press 7 7 6 4, your phone displays: Press up to accept Program. Prog Press right to highlight Press DELETE another ProgProhSpoiProi key to delete combination. DELETE SELECT Press * to last letter. enter Prog and Press SELECT key to lock a space.
  • Page 42 To enter text in tap mode, press a keypad key repeatedly to cycle through the letters and number on the key. Repeat this step to enter each letter. For example, if you press 8 one time, your phone displays: After 2 seconds, character is Character...
  • Page 43 When you enter three or more characters in a row, your phone may guess the rest of the word. For example, if you enter prog your phone might display: Press right to accept Prog Character Program, or displays at press * insertion point.

  • Page 44: Volume

    symbol mode Press # in a text entry screen until you see [. Press a keypad key to show its symbols at the bottom of the display. Highlight the symbol you want, then press the SELECT key. volume Press the volume keys to: •...

  • Page 45: Handsfree Speaker

    calls and other events. For a list of phone status indicators, see page 32. To set the phone ring style in the external display: 1 Press a volume key to display Ring Styles. 2 Press the smart key repeatedly, until the style you want appears.

  • Page 46: Lock & Unlock Phone

    If you forget your unlock code: At the Enter Unlock Code prompt, try entering 1234 or the last four digits of your phone number. If that doesn’t work, press M and enter your 6-digit security code instead. If you forget other codes: If you forget your security code, SIM PIN code, PIN2 code, or call barring password, contact your service provider.

  • Page 47: Customize

    customize ring style Each ring style profile uses a different set of sounds or vibrations for incoming calls and other events. Here are the profiles you can choose: y Loud | Vibrate Ò Silent z Soft Ó Vibe then Ring The ring style profile’s indicator displays at the top of your home screen.

  • Page 48: Time & Date

    time & date You need to set your phone’s time and date to use the datebook. To synchronize the time and date with the network: Press M > Settings > Initial Setup > Time and Date > Autoupdate > On. To manually set the time and date, turn off Autoupdate, then: Press M >...

  • Page 49: Screen Saver

    screen saver Set a photo, picture, or animation as a screen saver. The screen saver displays when the flip is open and no activity is detected for a specified time. Tip: This feature helps save your screen, but not your battery. To extend battery life, turn off the screen saver.

  • Page 50: Answer Options

    To save battery life, the display can turn off when you’re not using your phone. The display turns back on when you open the flip or press any key. To set how long your phone waits before the display turns off: Press M >...

  • Page 51: Calls

    calls To make and answer calls, see page 20. turn off a call alert You can press the volume keys to turn off a call alert before answering the call. recent calls Your phone keeps lists of incoming and outgoing calls, even for calls that didn’t connect.

  • Page 52: Redial

    option Store Create a phonebook entry with the number in the No. field. Store does not appear if the number is already stored. Delete Delete the entry. Delete All Delete all entries in the list. Hide ID/Show ID Hide or show your caller ID for the next call.

  • Page 53: Return A Call

    vibrates one time, displays Redial Successful, and connects the call. return a call Your phone keeps a record of your unanswered calls, and displays X Missed Calls, where X is the number of missed calls. 1 Press the VIEW key to see the received calls list. 2 Highlight the call you want to return, then press n.

  • Page 54: Call Waiting

    call waiting When you’re on a call, you’ll hear an alert if you receive a second call. Press n to answer the new call. • To switch between calls, press the SWITCH key. • To connect the two calls, press the LINK key. •...

  • Page 55: Emergency Calls

    emergency calls Your service provider programs one or more emergency phone numbers, such as 911 or 112, that you can call under any circumstances, even when your phone is locked or the SIM card is not inserted. Note: Emergency numbers vary by country. Your phone’s preprogrammed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference...

  • Page 56: Voicemail

    Find it: Press M > Settings > Initial Setup > 1 Touch Dial > Phone, SIM, or Fixed Dial To add a new phonebook entry, see page 61. To edit the Speed No. for a phonebook entry, press M > Phonebook, highlight the entry, and press M >...

  • Page 57: Push To Talk (Ptt) Calls

    push to talk (PTT) calls Push to Talk (PTT) lets you talk walkie-talkie style with other PTT subscribers. You can talk to one person or a group. PTT and the other related features indicated are network and subscription dependent features, and are not available in all areas.
  • Page 58 To end the call, press o. If nobody speaks for 20 seconds, the call ends. To send a PTT alert instead of a standard PTT call, highlight a PTT contact in PTT Contacts and press the ALERT key. The contact’s phone rings or vibrates, and the contact can speak first.
  • Page 59 To store a contact, press PTT key M > Add. Enter the contact’s Name and phone number (No.), then press the DONE key. Your network stores the contact and your phone returns to the PTT Contacts list with the new contact displayed. To create a group of contacts that you can call at the same time, press PTT key M >...
  • Page 60 Icons in the PTT contact and group lists indicate if someone is online (C, D) or offline (B, A). They also tell you if a contact is blocked j (highlight the contact and press M > Block or Unblock). To set an online alert o to tell you when a contact comes online, highlight the contact and press M >...
  • Page 61 option Open To From the home screen, the PTT key can open the PTT menu (Main Menu), or your contacts list sorted by name (Top of List), or most recent call (Last Call). Sort by Sort your contacts and groups by Name, online Status, or call Frequency.

  • Page 62: Other Features

    other features advanced calling feature conference call During a call: Dial next number, press n, press the LINK key. transfer a call During a call: M > Transfer, dial transfer number, press n attach a phone Dial an area code or prefix for a number phonebook number, then: M >...
  • Page 63 feature restrict calls Restrict outgoing or incoming calls: M > Settings > Security > Restrict Calls call barring Restrict outgoing or incoming calls: M > Settings > Security > Call Barring TTY calls Set up your phone for use with an optional TTY device: M >...

  • Page 64: Phonebook

    feature DTMF tones Activate DTMF tones: M > Settings > Initial Setup > DTMF To send DTMF tones during a call, just press number keys or highlight a number in the phonebook or recent calls lists and press M > Send Tones. phonebook feature add new entry M >...
  • Page 65 feature record a When creating a phonebook entry, voice name highlight Voice Name and press the RECORD key. Press and release the voice key and say the entry’s name (within 2 seconds). When prompted, press and release the voice key and repeat the name.
  • Page 66 feature set picture ID Assign a photo or picture to display for entry when you receive a call from an entry: M > Phonebook > entry M > Edit > Picture > picture name Note: The Picture option isn’t available in entries stored on the SIM card.
  • Page 67 feature set primary Set the primary number for an entry with number or multiple numbers: address M > Phonebook, highlight the entry, press M > Set Primary > number or address Tip: In Primary number view mode, you can still peek at other numbers stored for the same name.

  • Page 68: Messages

    feature send Send a phonebook entry in a text or phonebook email message: entry in a text M > Phonebook, highlight the entry, press message M > Send Contact send Send a phonebook entry to another phonebook phone, computer, or device: entry over M >...
  • Page 69 feature M > Messages > Create Message send voice message > New Voice Msg To record the voice message, press the RECORD key, speak, then press the STOP key. Your phone inserts the voice recording into a message and lets you enter email addresses or phone numbers to receive the message.
  • Page 70 feature store message Go to a multimedia message page, objects or highlight an object in a letter, then: M > Store store text To store incoming text messages messages on on your SIM card, press: your SIM card M > Messages M > Text Msg Setup > Store To >...

  • Page 71: Personalizing

    personalizing feature language Set menu language: M > Settings > Initial Setup > Language scroll Set the highlight bar to stop or wrap around in menu lists: M > Settings > Initial Setup > Scroll activate ringer Activate ringer IDs assigned to phonebook entries and categories: M >...
  • Page 72 feature menu view Display the main menu as graphic icons or as a text-based list: M > Settings > Personalize > Main Menu > View main menu Reorder your phone’s main menu: M > Settings > Personalize > Main Menu > Reorder show/hide Show or hide menu feature icons in the menu icons...

  • Page 73: Call Times & Costs

    feature master reset Reset all options except unlock code, security code, and lifetime timer: M > Settings > Initial Setup > Master Reset master clear Clear all settings and entries you made except SIM card information, downloaded pictures and sound files, and reset all options except unlock code, security code, and lifetime timer: M >...

  • Page 74: Handsfree

    feature call times Display call timers: M > Recent Calls > Call Times in-call timer Display time or cost information during a call: M > Settings > In-Call Setup > In-Call Timer call cost Display call cost trackers: M > Recent Calls > Call Cost handsfree Note: The use of wireless devices and their accessories may be prohibited or restricted in certain areas.

  • Page 75: Data & Fax Calls

    feature auto handsfree Automatically route calls to a car kit (car kit) when connected: M > Settings > Car Settings > Auto Handsfree power-off Set the phone to stay on for a delay (car kit) specified time after the ignition is switched off: M >...

  • Page 76: Network

    feature using sync You can call an Internet server and synchronize your phonebook and datebook entries with the server. To set up an Internet sync partner, press M > Settings > Connection > Sync > [New Entry]. Enter the server details, including Server URL (you can omit http://) and Data Path (the folder below the URL where your data is stored).
  • Page 77 feature turn off alarm When an alarm displays: To turn off the alarm, press the DISABLE key or o. To set an 8 minute delay, press the SNOOZE key. M > Tools > Datebook, highlight the day, add new press s, press M > New datebook event view datebook...

  • Page 78: Security

    feature create voice Create a voice record: record Press and hold the voice key, speak into the phone, release the voice key. Note: Recording phone calls is subject to varying state and federal laws regarding privacy and recording of conversations. Always obey the laws and regulations on the use of this feature.

  • Page 79: Fun & Games

    feature manage Enable or disable Internet access certificates certificates stored on your phone: M > Settings > Security > Certificate Mgmt Certificates are used to verify the identity and security of Web sites when you download files or share information. fun &...
  • Page 80 feature download Download a picture, sound, or objects from other object from a Web page: Web page Go to the page that links to the file, highlight the file, press the SELECT key, and press the STORE key. Note: Normal airtime and/or carrier usage charges apply.

  • Page 81: Troubleshooting

    If you have questions or need assistance, we're here to help. Go to www.motorola.com/consumer/support, where you can select from a number of customer care options. You can also contact the Motorola Customer Support Center at 1-800-331-6456 (United States), 1-888-390-6456 (TTY/TDD United States for hearing impaired), or 1-800-461-4575 (Canada).

  • Page 82: Sar Data

    Specific Absorption Rate Data The model wireless phone meets the government’s requirements for exposure to radio waves. Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S.
  • Page 83 2. AThe SAR information includes the Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product.

  • Page 84: Warranty

    United States and Canada Warranty What Does this Warranty Cover? Subject to the exclusions contained below, Motorola, Inc. warrants its telephones, pagers, messaging devices, and consumer and professional two-way radios (excluding commercial, government or industrial radios) that operate via Family Radio Service or General Mobile Radio Service, Motorola-branded or certified accessories sold for use with these Products (“Accessories”) and Motorola software contained on CD-ROMs or other...
  • Page 85 Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of Motorola, are excluded from coverage. Use of Non-Motorola Products and Accessories. Defects or damage that result from the use of Non-Motorola branded or certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.
  • Page 86 Unauthorized Service or Modification. Defects or damages resulting from service, testing, adjustment, installation, maintenance, alteration, or modification in any way by someone other than Motorola, or its authorized service centers, are excluded from coverage. Altered Products. Products or Accessories with (a) serial numbers or date tags that have been removed, altered or obliterated;...
  • Page 87 This warranty extends only to the first consumer purchaser, and is not transferable. What Will Motorola Do? Motorola, at its option, will at no charge repair, replace or refund the purchase price of any Products, Accessories or Software that does not conform to this warranty. We may use functionally equivalent reconditioned/refurbished/pre-owned or new Products, Accessories or parts.
  • Page 88 You will receive instructions on how to ship the Products, Accessories or Software, at your expense, to a Motorola Authorized Repair Center. To obtain service, you must include: (a) a copy of your receipt, bill of sale or other comparable proof of purchase; (b) a written description of the problem;...
  • Page 89 Motorola software. Motorola software may only be copied into, used in, and redistributed with, the Products associated with such Motorola software. No other use, including without limitation disassembly of such Motorola software or exercise of the exclusive rights reserved for Motorola, is permitted.
  • Page 90 index calculator 75 call accessories 16, 71 answer 20, 47 accessory connector port 1 end 20 active line indicator 33 make 20, 61 active line, changing 60 call barring 42, 60 alarm clock 73, 74 call forward indicator 33 alert call forwarding 59 set 41, 44 call timers 71...
  • Page 91 dial a phone number 20, 60, handsfree speaker 42 dialed calls 48 headset 71 display 31, 46, 68 headset jack 1 download media objects 67, hold a call 50 home screen 31, 68, 69 DTMF tones 49, 61 in-call indicator 33 earpiece volume 41 Incoming Call message 51 EDGE indicator 32...
  • Page 92 open to answer 47 optional accessory 16 make a call 20, 61 optional feature 16 master clear 70 master reset 70 memory card 25 pairing. See Bluetooth menu 34, 68, 69 connection menu icons 35, 69 passwords. See codes menu indicator 31 personalize 68 menu key 1, 16 phone number 20, 60, 61...
  • Page 93 recent calls 48 redial 49 tap text entry mode 38 reminders 68 telephone number. See restrict calls 60 phone number return a call 50 text entry 36 ring style indicator 34 text message 65, 66, 67 ring style, setting 41, 44 time, setting 45 ring tone 76 timers 71...
  • Page 94 volume 41, 68 wallpaper 45 warranty 81 Web pages 76 Web sessions 77 wireless connection. See Bluetooth connection your phone number 20 U.S. patent Re. 34,976 index...
  • Page 95 index...
