2.4GHz CORDLESS CALLER ID TELEPHONE
WITH CALL WAITING
40 CHANNEL AUTOSCAN
Model GH9620
OWNER'S MANUAL
INSTALLATION AND
OPERATING
INSTRUCTIONS
PLEASE READ THIS
MANUAL CAREFULLY
BEFORE USE.
KEEP FOR YOUR
REFERENCE.
For installation information, please
see "Getting Started" instructions
on or your separate Quick Start
Guide.
Visit Us on the Web:
www.uselectronics.info
©2004 BellSouth Corporation
This system can be expanded to 9 handsets maximum.
Special Features
Congratulations on your selection of a quality BellSouth product. With proper care, and by
following the set-up and user instructions in this manual. This unit will provide you with years of
trouble-free service.
BellSouth is committed to providing quality products that fit your needs. We would like to have any
comments or suggests you might have on this product. You may mail your comments to:
U.S. Electronics
105 Madison Avenue
New York, NY 10016
When examining your new BellSouth cordless telephone, you will find an array of special features
including:
CORDLESS TELEPHONE FEATURES
Filtered Sound™ System – Gets considerably less noise than conventional cordless telephones
because of a special circuit which delivers the clearest possible reception.
40 Channel Auto Scan – Press the button
clearest channel for any call.
Desk or Wall Mount – Use this equipment as a desk phone or as a wall phone.
Tone or PULSE Dialing – Use this phone for either TONE or push-button PULSE (rotary) dialing.
Automated Functions – Redial the last number called and automatic STANDBY mode.
Security – Ensures greater privacy because a built-in security code with 65,536 combinations
prevents use of your telephone line by another nearby cordless phone.
Dependable Battery – Recharge your BATTERY PACK many times with the built-in charger. The
battery low warning tone tells you when the BATTERY PACK needs recharging.)
Special Services – Use the
flash
button to access special services such as Call Waiting supplied
by your Telephone Company or company switchboard.
STANDBY Mode – When in STANDBY mode (ON-HOOK), the phone is capable of receiving a call.
When the HANDSET is on the BASE UNIT, it is automatically in the STANDBY mode (ON-HOOK).
When the HANDSET is taken off the BASE UNIT, it remains in the STANDBY mode until you
activate the
talk
button
Battery Power Saver – Once fully charged, in STANDBY mode, the HANDSET can receive/send
calls for a maximum of give days without the need for recharging. Length of charge depends on
frequency of use.
Luminous LCD Screen – The LCD Screen emits light for 5 seconds every time you press any of the
buttons on the HANDSET, or when calls come in.
HANDSET Ringer Level – Select the ringer volume level (HI, LOW, OFF).
HANDSET VOLUME CONTROL Switch – Select the receiver volume level (HI, MID, LOW).
HEADSET JACK – Your telephone can utilize a headset for hands-free communication.
BELT CLIP – Use the BELT CLIP to hang your HANDSET on your belt.
Scan
delete
on the HANDSET to find and lock on the

Advertisement

Table of Contents
loading

Related Manuals for BellSouth GH9620

Summary of Contents for BellSouth GH9620

  • Page 1 WITH CALL WAITING trouble-free service. 40 CHANNEL AUTOSCAN BellSouth is committed to providing quality products that fit your needs. We would like to have any Model GH9620 comments or suggests you might have on this product. You may mail your comments to: OWNER’S MANUAL...
  • Page 2 Special Features HANDSET Controls CALLER ID SYSTEM Multi-Function Large LCD Screen – Shows the number you are dialing, and with Caller ID services (available through subscription from your local telephone company), display information about the caller before you answer the call. Name and Number DIRECTORY –...
  • Page 3 BASE UNIT Controls HANDSET Controls Save/pause redial 5. REDIAL /SAVE/PAUSE Button: (REDIAL) Press to redial the last number you dialed. (SAVE) Press and hold down to save the changes on the listed items. (PAUSE) Press to insert Save/pause redial a pause while dialing. (You will need the button to dial numbers which use an alternative Long Distance Access Code.) OPER...

  • Page 4: Table Of Contents

    Contents Contents Safety Instructions..........................3 Deleting All Recordings in the DIRECTORY................23 Getting Started ........................... 5 Selecting Deleting in the DIRECTORY ................... 23 Choosing A Location .......................... 9 Function Operation ........................24 Desk Mounting ..........................10 1. Language ..........................25 Wall Mounting ..........................

  • Page 5: Safety Instructions

    Safety Instructions Safety Instructions IMPORTANT SAFETY INSTRUCTIONS If the telephone exhibits a distinct change in performance. 13. Do not use the telephone to report a gas leak in the vicinity of the leak To reduce the risk of fire, electric shock and /or injury, always follow these basic 14.
  • Page 6 Getting Started Getting Started Connecting Your Phone This section is a reference guide to the basic functions and operations of your cordless telephone. For more detailed descriptions of the operations and features of this telephone, 1. Carefully remove your cordless telephone from its shipping carton. If there is any visible damage, do not attempt to operate this equipment.

  • Page 7: Getting Started

    HANDSET. 13. Set the date and time on the HANDSET You are now ready to use you new BellSouth Cordless Telephone IMPORTANT In order to utilize the Caller ID feature, you must subscribe to Caller ID service from your local telephone company.

  • Page 8: Choosing A Location

    Choosing A Location Desk Mounting Do the following: Desk Mounting Choose the best location Connect the base phone One of the special features of your telephone is the unique design if the MOUNTING BRACKET Choose the dialing mode which can hold your phone at an angle of 30º when desk mounting. 1.

  • Page 9: Wall Mounting

    Wall Mounting Wall Mounting Wall Mounting You may choose to put the BASE UNIT of your cordless telephone on a wall. 1. With the back of the BASE UNIT facing up, connect the SHORT TELEPHONE LINE CORD to the TELEPHONE LINE CONNECTION JACK. 2.

  • Page 10: Cordless Telephone Operation

    Cordless Telephone Operation Cordless Telephone Operation Preparing for Use NOTE: talk 1. The Call Timer will start to count once you press the button. Before you can use your cordless telephone, you must charge the HANDSET for 12 hours. 2. The LCD Screen emits light for 5 seconds every time you press any buttons on the HANDSET. Failure to do so will require recharging of the BATTERY PACK more often.

  • Page 11: Call Transfer

    Cordless Telephone Operation Caller ID System Operation Call Transfer Caller ID System When User expect to transfer a call made or receive from one handset to another, just simply This telephone automatically displays an incoming caller’s name and telephone number together press the call transfer key &...
  • Page 12 Caller ID System Operation Caller ID System Operation Call Waiting Viewing the Caller List When you subscribe to a Call Waiting service from your local telephone company, this telephone will 1. Press the SCROLL DOWN button to view the lasted Caller ID record, or press the SCROLL display the name and number of the second caller while you are having a conversation with your first button to view the first Caller ID record, press the SHIFT RIGHT button if the name has...
  • Page 13 Caller ID System Operation Caller ID System Operation Saving the Name and Number in the Caller List into the DIRECTORY Speed Viewing the DIRECOTRY Phone 1. Press the SCROLL UP or DOWN button to find the caller. book 1. Press the button.
  • Page 14 Caller ID System Operation Caller ID System Operation Editing a Name and Number in the DIRECOTRY Editing the Number in the DIRECTOTY before Dialing Phone Phone book 1. Press the button. book Press the button. 2. Press the SCROLL UP button or DOWN button to find the record you want to edit.
  • Page 15 Caller ID System Operation Caller ID System Operation Placing Calls from the DIRECTORY Function Operation This unit contains the following special functions: Phone book 1. Press the button. LANGUAGE 7. FLASH TIME 2. Press the SCROLL UP or DOWN button to find the record you want to call. SILENT ON/OFF 8.
  • Page 16 Caller ID System Operation Caller ID System Operation Language Save/pause redial 5. Press and hold down the button. This telephone offers English, Spanish, and French languages for your convenience Voice mail menu 6. Press the button to return to STANDBY mode. Voice mail menu Press the...
  • Page 17 Caller ID System Operation Caller ID System Operation 4. Press the SCROLL UP or DOWN button to select the PAUSE TIME. You can also set the 2. Press the TELEPHONE KEYPAD button or the SCROLL UP or DOWN button until the “PBX NO.” option display. OPER PAUSE TIME by entering the PAUSE TIME number using the TELEPHONE KEYPAD edit...

  • Page 18: Tone/Pulse Setting

    Caller ID System Operation Caller ID System Operation TONE/PULSE Setting Telephone Keypad Character Set the TONE or PULSE dialing system. (Depending on the user’s service type.) Wxyz OPER The TELEPHONE KEYPAD buttons are used to enter characters when entering Voice mail menu names.

  • Page 19: Security

    Security Recharging the BATTERY PACK Security System BATTERY Type Your cordless telephone uses a digital coding security system to prevent unauthorized use of your Use the following type and size of BATTERY PACK: telephone line by another nearby cordless telephone. The system has its own identifying signal Cordless Telephone BATTERY PACK created by microcomputers in both the BASE UNIT and the HANDSET.

  • Page 20: Changing The Battery Pack

    Changing the BATTERY PACK Problem Solving Changing the BATTERY PACK Problem Solving Section For your assistance, we have listed below a few common problems. The BATTERY PACK provides power for the HANDSET of your cordless telephone. Phone does not work, check the following: To Replace BATTERY PACK: 1.

  • Page 21: Technical Information

    Technical Information FCC Requirements Technical information Federal Communications Commission Requirements This cordless telephone uses radio frequencies to allow mobility. There are certain difficulties, in This equipment complies with Part 68 of the FCC rules. A label on the BASE UNIT of the equipment using radio frequencies with a cordless telephone.

  • Page 22: Warranty

    Telephone companies use different types of equipment and offer various types of services to customers. BellSouth Products does not warrant that this telephone is compatible with the type of equipment of any particular telephone company or the services provided by it.

  • Page 23: Wall Mounting Template

    7137 Southlake Parkway Morrow, GA30260 NOTE: A telephone product received which was not made for BellSouth Products or which is not defective as determined by our test procedures will not be repaired and will be returned to you C.O.D, freight collect.
  • Page 24 IMPORTANT In order to get maximum life from the HANDSET BATTERY PACK, be sure to charge the HANDSET for 12 hours before initial use. STOP IMPORTANT Placing your BASE UNIT near appliances such as televisions, refrigerators, radios, or microwave ovens May cause interference.
