D-Link xStack DGS-3627 Specifications

High Performance Switching
+ IPv4/IPv6 Routing
+ Up to 12K Routes
+ 40 Gigabit Stacking Backplane
+ Physical Data Stack Up to 12 Units per
Stack
+ IP Stacking Up to 32 Units per IP
+ Up to 576Gbps Bandwidth per Stack
+ Optional 10-Gigabit Uplinks
+ Jumbo Frame Support (Up to 9216 Bytes)
Security
+ Microsoft NAP
®
+ Enhanced Access Control List
+ Guest VLAN
+ Up to 4K 802.1Q VLANs
+ 802.1X (Port and MAC Authentication)
+ TACACS+ & RADIUS
+ SSH/SSL
+ Traffi c Segmentation
+ IP-MAC Port Binding
+ MAC-based Access Control
+ Web-based Access Control
+ DHCP Server Screening
1

Layer 3 Support

+ RIPv1, RIPv2
+ RIPng
+ Up to 64 IP Interfaces
+ Multiple IP Interfaces per VLAN
+ VRRP
+ Up to 1K Multicast Groups
+ IGMP v1, v2, v3
+ DVMRP v3
+ PIM-DM/SM/SDM for IPv4
Advanced Enterprise Features
+ IGMP/MLD Snooping
+ Spanning Tree 802.1D, 802.1w, 802.1s
+ LAG (32 Groups/8 Ports)
+ Cross Stack Port Mirroring and
Trunking
+ 802.1p QoS (8 Queues)
+ Broadcast Storm Control
+ SNMP v1/2c/3
+ CLI or Web GUI Interface
+ sFLOW
+ RSPAN
1
xStack DGS-3600 Series (DGS-3627, DGS-3627G, and DGS-3650)
®
xStack Managed 24/48-Port Gigabit Stackable L3 Switch with
®
4 Combo SFP Slots
Overview
The latest generation of D-Link
supports IPv6 routing and has more advanced features
than ever to address today's security, QoS, and
management concerns. The xStack DGS-3600 Series
includes three gigabit managed switches with a choice of
24 or 48 Gibabit 10/100/1000BASE-T ports. The DGS-3627
comes with four combo SFP slots and three optional
10-Gigabit uplinks. The DGS-3627G is the fi ber version
equipped with four combo 10/100/1000 Base-T ports and
three optional 10-Gigabit uplinks. The DGS-3650 has four
combo SFP slots and two optional 10-Gigabit uplinks.
The xStack DGS-3600 Series is equipped with robust
features that fulfi ll the most demanding network's needs
for voice and video streaming. Stackable up to 12 units
under a single IP, the switches are able to provide a total
of up to 576Gbps aggregated bandwidth fi xed-in. To help
secure your network, the D-Link Safeguard Engine™
helps prevent Denial-of-Service (DoS) attacks while the
Access Control List (ACL) enhances network security.
The DGS-3600 Series is equipped with industry standard
management features including easy-to-use CLI and
web-based administrator interfaces. D-Link provides
these features on a scalable platform, increasing your
company's productivity while protecting your investment.
IPv6 and IPv4 Routing
The xStack DGS-3600 Series provides current IPv4 networks
with a simple migration path to IPv6 and protects your
investment for future network upgrades when greater
security and larger addressing are required. Basic static
routing such as RIP and RIPv2 are supported for small
network routing applications. Advanced routing protocols
such as OSPF and equal cost routing are supported for load
balancing and building a scalable network.
Stackable Up to 12 Units
xStack Switches Each switch in the xStack DGS-3600 Series has two optional
® ®
ports to install stacking modules that provide up to 40Gbps
in data stacking backplane while in full-duplex mode. This
enhances your overall network performance for switches
transmitting large fi les such as graphics or pictures. Under
stacking mode, the switches are hot-swappable. This means
that in a stack confi guration, any of the switches can be
replaced or removed without affecting the network. There is
no need to reconfi gure a replacement switch; just give the
new switch the same stack number ID as the old switch and
the network will carry the same confi guration as before. This
minimizes network downtime and maximizes the productivity
of your business. Also, to facilitate network administration,
cross stack port mirroring and port trunking are supported.
The D-Link Safeguard Engine and Security
The DGS-3600 Series incorporates advanced mechanisms
to detect an attack against the central processing unit of
the switch and to take corrective action on the attacking
interface. When a DoS attack is waged against any of the
DGS-3600 switches, the D-Link Safeguard Engine detects
the threat and prevents overload of the CPU, thus ensuring
network integrity and helping to maintain open network
bandwidth channels.
In addition, the xStack DGS-3600 Series offers a variety
of authentication methods, including those without the
requirement of a RADIUS server. It supports MAC-based
Access Control, which authenticates the user based on
the MAC address of the client so that authentication is
transparent to the client. It also supports Web-based
Access Control, which prompts for username and password
before allowing access to TCP traffi c. Lastly, the xStack
DGS-3600 Series supports Network Access Protection (NAP).
This feature works in conjunction with Microsoft
platforms such as Windows Vista
health and security policies including policy validation,
network restriction, remediation, and ongoing compliance.
software
®
to reinforce network
®
