Service Literature
COMMUNICATING ENABLED SL297UHNV SERIES UNITS
SL297UHNV series units are 90% efficiency gas furnaces
used
for
upflow
or
SL297UHNV units are available in heating capacities of
40,000 to 80,000 Btuh and cooling applications up to 4
tons. Refer to Product Specifications Manual for proper siz­
ing.
Units are factory equipped for use with natural gas.
SL297UHNV model units are equipped with a communicat­
®
ing enabled SureLight
two-stage variable speed integrated
control. All units use a redundant gas valve to assure safety
shut-off as required by C.S.A.
All specifications in this manual are subject to change. Pro­
cedures outlined in this manual are presented as a recom­
mendation only and do not supersede or replace local or
state codes. In the absence of local or state codes, the
guidelines and procedures outlined in this manual (except
where noted) are recommendations only and do not consti­
tute code.
TABLE OF CONTENTS
Specifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I Unit Components
. . . . . . . . . . . . . . . . . . . . . . .
II Installation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
III Start Up
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IV Heating System Service Checks
V Typical Operating Characteristics
VI Maintenance
. . . . . . . . . . . . . . . . . . . . . . . . . .
VII Wiring and Sequence of Operation
VIII Field Wiring and Jumper Settings
IX Program Unit Capacity Size Mode
X Troubleshooting
. . . . . . . . . . . . . . . . . . . . . . . .
horizontal
applications
Page 2
Page 11
Page 33
Page 51
. . . . . . . . .
Page 52
. . . . . . . . .
Page 58
Page 58
. . . . . .
Page 61
. . . . . . .
Page 66
. . . . . . .
Page 70
Page 71
Corp. 1802-L1
Revised 02/2021
only.
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, person­
al injury or loss of life. Installation and service must
be performed by a licensed professional HVAC in­
staller (or equivalent), service agency or the gas sup­
plier.
As with any mechanical equipment, contact with
sharp sheet metal edges can result in personal in­
jury. Take care while handling this equipment and
wear gloves and protective clothing.
Page 1
SL297UHNV
WARNING
CAUTION
© 2021 Lennox Industries Inc.
