TM
User's guide for OfficeStation
-PCI
(L150 Series)
© Copyright by Ncomputing Co. Ltd. 2004 . - Illegal copying of this software, hardware and this
documentation is prohibited by law. All other brand- and product names are trademarks of
registered trademarks of the respective owners.
1

Advertisement

loading

Summary of Contents for NComputing OfficeStation L150 series

  • Page 1 -PCI (L150 Series) © Copyright by Ncomputing Co. Ltd. 2004 . - Illegal copying of this software, hardware and this documentation is prohibited by law. All other brand- and product names are trademarks of registered trademarks of the respective owners.

  • Page 2: Safety Instructions

    Safety Instructions The following instructions pertain to the risk of fire, electric shock or bodily injury. Please read all of these instructions carefully. Warning - Do not use this system on an unstable cart, stand or table. The product may fall, causing serious damage to the product. - Slots and openings in the cabinet and the back have been provided for ventilation.
  • Page 3 FCC Information to Use Note : This equipment has been tested and found to comply with the limit for a Class B digital device, pursuant 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 4 Introductions What is OfficeStation OfficeStation is an unique networking device using WoIP (Windows over IP) based on networking standards. You can share the resources of the host PC system by connecting OfficeStation terminal(s) to it, thus giving you the benefit of having several networked PCs.
  • Page 5 OS (Operating System) Windows XP Home Edition Windows XP Professional Edition Windows 2000 Professional Edition...
  • Page 6 Setting up the OfficeStation 1. Component Names and Functions 1-1 Product Photo...
  • Page 7 1-2 Port of PCI Card Type Audio out Jack The Stereo headphone jack is used to connect the OfficeStation’s audio out signal to amplified External Monitor speakers connect your OfficeStation to External Monitor that RGB types PS/2 Port (Mouse) monitors The PS/2 port is for connect PS/2 types Mouse PS/2 Port (Keyboard)
  • Page 8 2. Connecting OfficeStation to a PC Your OfficeStation can be connected to a PC in one of two ways 2-1 Connecting to a PC Directly(Peer-to-Peer) In order to connect the OfficeStation to a PC directly using wire, you must have a LAN card installed in your PC, or must have that function built in.
  • Page 9 2.2 Connecting to a PC through a Hub or a Router Connect the OfficeStation to a PC through a Hub or Router as shown below. Host PC Ethernet Router /Hub Ethernet Cable OfficeStation 1 OfficeStation 2 OfficeStation..10...
  • Page 10 Installing the OfficeStation Software 1. Quick Installation the Host PC Program Insert the driver for OfficeStation installation CD into your PC’s CD-ROM driver and follow the instructions. You need to setup program manually in the present. Start -> Run -> Open type X:/install.exe Substitute your CD-ROM drive letter for the “x”.
  • Page 11 Select installation folder windows appears Click [Next] button if you want to install NCT-2000-XP in the default folder Click [Disable password protection] button if you want to not to use password. If you want to specify password, type the password, and confirm it.
  • Page 12 Click [Next] Copies files needed for installation. When the ‘installation complete’ window appears, click button after select “Yes, I want to restart my [Restart] computer now.”...

  • Page 13: Network Setup

    2. Network Setup 2-1 setting up the network environment in Windows XP Connecting to a PC Directly (Peer-to-Peer) You can set up the network environment in your PC, Go to Start -> right Click on My Network Places -> Double Click the “network Connection” icon Click the Local network connection status Click the Prosperities Icon...
  • Page 14 Click Internet Protocol (TCP/IP) Click Properties -> Select “Use an IP following IP address” Type in the IP address, subnet mask and Default gateway of the your PC And Click OK e.g) IP Address: 192.168.1.1 Subnet mask: 255.255.255.0 Default gateway: 192.168.10.0 Power on the OfficeStation->...
  • Page 15 Click Network Tap -> Click Use Static IP Address-> Type in the IP Address and Gateway address of your a OfficeStation. e.g) IP Address: 192.168.1.2 Default gateway: 192.168.10.0 Click TS Option Tap -> Type the Host PC’s IP address in the Terminal Server Network address.
  • Page 16 Connecting to a PC through a Hub or a Router To connect to the PC make sure the network in your computer is configured properly. Here’s how to configure the network properties to connect PC with the OfficeStation. Connect to PC with a Hub You can set up the network environment in your PC, Go to Start ->...
  • Page 17 Click Network Tap -> Click Use Static IP Address-> Type in the IP Address and Gateway address of your a OfficeStation. e.g) IP Address: 192.168.1.2 Default gateway: 192.168.10.0 Click TS Option Tap -> Type the Host PC’s IP address in the Terminal Server Network address.
  • Page 18 Connect to PC with a Router For additional settings or information about your Router, refer to its Manual. You can set up the network environment in your PC, Go to Start -> right Click on My Network Places -> Double Click on the Network Connection associated with the Ethernet adapter.
  • Page 19 Click Network Tap -> Click Get Dynamic IP address -> Click TS Option Tap -> Type the Host PC’s IP address in the Terminal Server Network address from received the Router. And Click Save...
