OWNER'S MANUAL
DRYER
Read this owner's manual thoroughly before operating the appliance and keep it handy for
reference at all times.
ENGLISH
DLE7100*
DLG7101*
DLE7150*
DLG7151*
DLE7000*
DLG7001*
www.lg.com
MFL67652535
Copyright © 2021 LG Electronics Inc. All Rights Reserved.
Rev.00_030821

Advertisement

Table of Contents
loading

Related Manuals for LG DLE7100 Series

Summary of Contents for LG DLE7100 Series

  • Page 1 OWNER'S MANUAL DRYER Read this owner’s manual thoroughly before operating the appliance and keep it handy for reference at all times. ENGLISH DLE7100* DLG7101* DLE7150* DLG7151* DLE7000* DLG7001* www.lg.com MFL67652535 Copyright © 2021 LG Electronics Inc. All Rights Reserved. Rev.00_030821...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS SAFETY INSTRUCTIONS SMART FUNCTIONS IMPORTANT SAFETY INSTRUCTIONS LG ThinQ Application GROUNDING INSTRUCTIONS Smart Diagnosis™ Feature PRODUCT FEATURES MAINTENANCE Regular Cleaning PRODUCT OVERVIEW TROUBLESHOOTING Parts Accessories FAQs: Frequently Asked Questions User Support Videos Before Calling for Service...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Safety for a Dryer WARNING Fire Hazard Failure to follow safety warnings exactly could result in serious injury, death or property damage. Do not install a booster fan in the exhaust duct. Install all clothes dryer in accordance with the installation instructions of the manufacturer of dryer.
  • Page 4 SAFETY INSTRUCTIONS WARNING - RISK OF FIRE Install the clothes dryer according to the manufacturer’s instructions and local codes. • Clothes dryer installation must be performed by a qualified installer. • Do not install a clothes dryer with flexible plastic venting materials. If flexible metal (foil type) duct is installed, it must be of a specific type identified by the appliance manufacturer as suitable for use with clothes dryers. Flexible venting materials are known to collapse, be easily crushed, and trap lint.

  • Page 5: Important Safety Instructions

    SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: Installation • Remove all protective vinyl film from the product. Failure to do so may result in product damage, smoke, •...
  • Page 6 SAFETY INSTRUCTIONS Operation • Do not put any part of your body, such as your hands or feet, or metal objects under the product. • Read all instructions before using the appliance. • Do not let your hand get pinched when opening or •...

  • Page 7: Grounding Instructions

    SAFETY INSTRUCTIONS GROUNDING INSTRUCTIONS WARNING Improper connection of the equipment-grounding conductor may result in a risk of electric shock. Check with a qualified electrician or service person if you are in doubt that the appliance is properly grounded. • This appliance must be grounded. In the event • Do not, under any circumstances, cut or of malfunction or breakdown, grounding will reduce remove the ground prong from the power cord. the risk of electric shock by providing a path of least To prevent personal injury or damage to the dryer, resistance for electric current.

  • Page 8: Product Features

    PRODUCT FEATURES PRODUCT FEATURES Easy-to-Use Control Panel An entire selection of user-friendly functions make operating the dryer easy. Easy-Access Reversible Door The wide-opening door provides easy access for loading and unloading. The door hinge can be reversed to adjust for installation location. Flow Sense Duct Blockage Sensing System Indicator The Flow Sense...

  • Page 9: Product Overview

    Kit No. 383EEL9001B NOTE • Visit www.lg.com to purchase accessories. • Contact LG Customer Service at 1-800-243-0000 (1-888-542-2623 in Canada) if any accessories are missing. • For your safety and for extended product life, use only authorized components. The manufacturer is not responsible for product malfunction or accidents caused by the use of separately purchased unauthorized components or parts.

  • Page 10: Installation

    10 INSTALLATION INSTALLATION Installation Overview Please read the following installation instructions first after purchasing this product or transporting it to another location. Check and choose Level the dryer Vent the dryer the proper location Gas dryer Electric dryer Connect electric dryers Connect gas dryers Plug in the power cord Installation test...

  • Page 11: Installation Location Requirements

    INSTALLATION Installation Location Requirements WARNING Read all installation instructions completely before installing and operating the dryer! It is important that you review this entire manual before installing and using the dryer. Detailed instructions concerning electrical connections, gas connections, and exhaust requirements are provided on the following pages. The installation requires: •...
  • Page 12 12 INSTALLATION Closet Ventilation Requirements Closets with doors must have both an upper and lower vent to prevent heat and moisture buildup in the closet. One upper vent opening with a minimum opening of 48 sq. in. (310 cm ) must be installed no lower than 6 feet above the floor.

  • Page 13: Leveling The Dryer

    INSTALLATION Leveling the Dryer Use an adjustable wrench to turn the leveling feet. Unscrew the legs to raise the dryer or screw in the legs to lower it. Raise or lower with WARNING the leveling feet until the dryer is level from side to side and front to back.

  • Page 14: Reversing The Door

    14 INSTALLATION Reversing the Door Remove the 4 screws securing the hinges to the door frame. Remove the two plastic cover caps. Reinstall the hinges and cover caps on the WARNING opposite sides from which they were removed. THE DRYER DOOR IS VERY LARGE AND HEAVY.

  • Page 15: Installing The Side Vent Kit

    (right-side (3.8 cm) venting is not available on gas models). An adapter kit, part number 383EEL9001B, may be purchased from an LG retailer. This kit contains the Option 2: Bottom Venting necessary duct components to change the dryer vent location.

  • Page 16: Venting The Dryer

    16 INSTALLATION Venting the Dryer • DO NOT use sheet metal screws or other fasteners which extend into the duct that could catch lint and reduce the efficiency of WARNING the exhaust system. Secure all joints with duct tape. Failure to follow these instructions may result To reduce the risk of fire or explosion, electric in fire or death.
  • Page 17 INSTALLATION Routing And Connecting Ductwork NOTE Follow the guidelines below to maximize drying performance and reduce lint buildup and condensation in the ductwork. Ductwork and fittings are NOT included and must be purchased separately. • Use 4-inch (10.2 cm) diameter rigid, semi-rigid or flexible metal ductwork.

  • Page 18: Connecting Gas Dryers

    18 INSTALLATION Connecting Gas Dryers • Use only a new AGA- or CSA-certified gas supply line (in compliance with the Standard for Connectors for Gas Appliances, ANSI WARNING Z21.24 • CSA 6.10) with flexible stainless steel connectors. To reduce the risk of fire or explosion, electric shock, property damage, injury to persons, or •...
  • Page 19 INSTALLATION Connecting the Gas Supply Securely tighten all connections between the dryer and your laundry room’s gas supply. • Installation and service must be performed by a qualified installer, service agency, or the Turn on your laundry room’s gas supply. gas supplier. Failure to do so may result in fire, explosion, or death. Check all pipe connections (both internal and •...

  • Page 20: Connecting Electric Dryers

    20 INSTALLATION Connecting Electric Dryers Electrical Requirements for Electric Models Only WARNING To help prevent fire, electric shock, serious injury, or death, the wiring and grounding must conform to the latest edition of the National Electrical Code, ANSI/NFPA 70 and all applicable local regulations.
  • Page 21 INSTALLATION Attach the white neutral wire to the center screw WARNING of the terminal block. Connect the power cord to the terminal block. Connect each wire in the power cord to the Attach the power cord ground wire to the green terminal block screw with the matching colored ground screw.
  • Page 22 22 INSTALLATION Four-Wire Direct Wire Attach the white neutral wire to the center screw of the terminal block. • A UL-listed strain relief is required. • Use UL-listed 4-wire #10 AWG- Attach the power cord ground wire to the green minimum copper conductor cable.
  • Page 23 INSTALLATION Attach the neutral (white) wire to the center WARNING terminal block screw. Connect the power cord to the terminal block. NOTE Connect each wire in the power cord to the terminal block screw with the matching colored The dryer is supplied with the neutral conductor wire.

  • Page 24: Final Installation Check

    24 INSTALLATION Three-Wire Direct Wire Reinstall the terminal block access cover. • A 3-wire connection is NOT permitted Neutral (Black) (White) on new construction after January 1, 1996. (Red) Ground • A UL-listed strain relief is required. Screw • Use UL-listed 3-wire, #10 AWG-minimum copper conductor cable.

  • Page 25: Installation Test (Duct Check)

    INSTALLATION Installation Test (Duct Check) Check the display for results. During the test cycle, monitor the Flow Sense™ Once you have completed the installation of the display on the control panel. If the Flow Sense™ dryer, use this test to make sure the condition of the LED is not turned on, when the cycle ends, exhaust system is adequate for proper operation of the exhaust system is adequate.
  • Page 26 26 INSTALLATION Restricted or Blocked Airflow • Check the duct condition If the Flow Sense LED is turned on, check the Avoid long runs or runs with multiple elbows or bends. exhaust system for restrictions and damage. Repair or replace the exhaust system as needed. NOTE When the dryer is first installed, this test should be performed to alert you to any existing...

  • Page 27: Operation

    OPERATION OPERATION WARNING To reduce the risk of fire, electric shock, or injury to persons, read this entire manual, including the IMPORTANT SAFETY INSTRUCTIONS, before operating this dryer. Using the Dryer Lint 1 Clean the Lint Filter Filter If the lint filter has not already been cleaned, lift out the filter and remove the lint from the last load.

  • Page 28: Check The Lint Filter Before Every Load

    28 OPERATION Check the Lint Filter Before Group Similar Items Every Load For best results, sort clothes into loads that can be dried with the same drying cycle. Always make sure the lint filter is clean before starting Different fabrics have different care requirements, and a new load;...

  • Page 29: Control Panel

    OPERATION Control Panel DLE7100*, DLG7101* DLE7150*, DLG7151*, DLE7000*, DLG7001* 1 POWER Button 4 Time and Status Display Press to turn the dryer ON. Press again to turn the The display shows the settings, estimated time dryer OFF. remaining, options, and status messages for the dryer.
  • Page 30 30 OPERATION DLE7100*, DLG7101* DLE7150*, DLG7151*, DLE7000*, DLG7001* ™ 8 Clean Filter Reminder 11 Flow Sense Duct Blockage Sensing System Indicator The display will show Clean Filter when the dryer is The Flow Sense™ duct blockage sensing system turned on as a reminder to check the filter. It turns off detects and alerts you to blockages in the ductwork when the START/PAUSE button is pressed.

  • Page 31: Cycle Guide

    OPERATION Cycle Guide = default setting = allowable option More Time/ Wrinkle Damp Dry Energy Cycle Fabric Type Dry Level Temp. Less Time Care Signal Saver Normal Dry Bedding Comforters, pillows, shirts Medium Adjustable Normal Dry Heavy Duty Jeans, heavyweight items High Adjustable Normal Dry...
  • Page 32 32 OPERATION Sensor Dry Cycles Manual Dry Cycles Sensor dry cycles utilize LG’s unique dual sensor Use manual dry cycles to select a specific amount system to detect and compare the moisture level of drying time and a drying temperature. When a...

  • Page 33: Cycle Settings And Options

    OPERATION Cycle Settings and Options Cycle Option Buttons The dryer features several additional cycle options to Cycle Modifier Buttons customize cycles to meet individual needs. Certain option buttons also feature a special function that SENSOR DRY cycles have preset settings that can be activated by pressing and holding that option are selected automatically.
  • Page 34 34 OPERATION Special Functions Some cycle option buttons also activate secondary functions. These special functions are marked with an asterisk (*). Press and hold the option button marked with the special function to activate it. * Control Lock Use this option to prevent unwanted use of the dryer or to keep cycle settings from being changed while the dryer is operating.

  • Page 35: Smart Functions

    Follow the instructions below to use the audible diagnosis method. Installing the LG ThinQ Application • Launch the LG ThinQ application and select the Smart Diagnosis™ feature in the menu. Search for the LG ThinQ application from the Google Follow the instructions for audible diagnosis Play Store or Apple App Store on a smartphone.

  • Page 36: Maintenance

    36 MAINTENANCE MAINTENANCE Maintaining Ductwork Vent ductwork should be checked for lint buildup once per month and cleaned at least once per year. If any Regular Cleaning noticeable reduction in airflow or drying performance occurs, immediately check ductwork for obstructions WARNING and blockages.

  • Page 37: Troubleshooting

    User Support Videos For further assistance, there are videos and tutorials available through the LG.com website. On the lg.com/us home page, click on the Support menu tab to bring up the menu selections. Select Video Tutorials. Select Appliances and Dryers in the search menu on the new page.

  • Page 38: Before Calling For Service

    38 TROUBLESHOOTING Before Calling for Service This dryer is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the dryer does not function properly or does not function at all, check the following before you call for service.
  • Page 39 TROUBLESHOOTING Problem Possible Cause Solutions Clothes take too long to Exhaust ducts are blocked, dirty, Confirm that the exhaust duct is properly or duct run is too long. configured and free of debris, lint, and obstructions. Make sure that outside wall dampers can open properly and are not blocked, jammed, or damaged.
  • Page 40 40 TROUBLESHOOTING Problem Possible Cause Solutions Clothes take too long to Energy Saver option selected If using the Cotton/Normal cycle, deselect (on some models) the Energy Saver option. This option reduces energy use by adding an air dry section to the beginning of the cycle. Drying time is not Heat settings, load size, or The drying time for a load will vary...
  • Page 41 TROUBLESHOOTING Performance Problem Possible Cause Solutions Greasy or dirty spots Fabric softener used incorrectly. Confirm and follow the instructions on clothes provided with your fabric softener. Clean and dirty clothes are being Use your dryer to dry only clean items. dried together.
  • Page 42 42 TROUBLESHOOTING Problem Possible Cause Solutions Lint on clothes Excess static in clothes. Use a fabric softener to reduce static electricity. Be sure to follow the manufacturer’s instructions. Overdrying a load of laundry can cause a buildup of static electricity. Adjust settings and use a shorter drying time, or use SENSOR DRY cycles.
  • Page 43 TROUBLESHOOTING Error Codes Problem Possible Cause Solutions Error code: tE1 through Temperature sensor failure. Turn off the dryer and call for service. Display shows error Power cord is connected Check the connection of the power cord code: PS (electric incorrectly. to the terminal block.
  • Page 44 44 TROUBLESHOOTING Problem Possible Cause Solutions The display shows d90, The duct work is about 90%-95% Do not use the dryer until the exhaust blocked.(“d90” or “d95” error system has been cleaned and/or repaired. code is displayed for 2 hours Using the dryer with a severely restricted only) exhaust is dangerous and could result in...

  • Page 45: Warranty (Usa)

    Should your LG Dryer (“Product”) fail due to a defect in materials or workmanship under normal home use, during the warranty period set forth below, LG will at its option repair or replace the product. This limited warranty is valid only to the original retail purchaser of the product and applies only when purchased and used within the United States including U.S.
  • Page 46 TO OBTAIN WARRANTY SERVICE AND ADDITIONAL INFORMATION For additional product information, visit the LG website at http://www.lg.com For assistance using this product or to schedule service, contact LG Electronics at 1-800-243-0000. For further assistance, write: LG Electronics, 201 James Record Road, Huntsville, Alabama 35813...
  • Page 47 If you and LG are unable to resolve the dispute within 30 days, either party Agreement to Binding Arbitration and Class Action Waiver.
  • Page 48 Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar optout@lge.com, with the subject line: “Arbitration Opt Out”...
  • Page 49 Memo...
  • Page 50 Memo...
