Quick Installation Guide
DIR-615S
Wireless N300 Router

Advertisement

Table of Contents
loading

Related Manuals for D-Link DIR-615S

Summary of Contents for D-Link DIR-615S

  • Page 1 Quick Installation Guide DIR-615S Wireless N300 Router...

  • Page 2: Before You Begin

    If any of the items are missing, please contact your reseller. The “User Manual” and “Quick Installation Guide” documents are available on D-Link website (see www.dlink.ru). Using a power supply with a different voltage rating than the one included will cause damage and void the warranty for this product.

  • Page 3: System Requirements And Equipment

    DIR-615S Quick Installation Guide System Requirements and Equipment A computer with any operating system that supports a web browser. • A web browser to access the web-based interface of the router: • ◦ Apple Safari 5 and later ◦ Google Chrome 5 and later ◦...

  • Page 4: Pc With Ethernet Adapter

    DIR-615S Quick Installation Guide CONNECTING TO PC PC with Ethernet Adapter 1. Make sure that your PC is powered off. 2. Connect an Ethernet cable between any of LAN ports located on the back panel of the router and the Ethernet port of your PC.
  • Page 5 DIR-615S Quick Installation Guide Obtaining Address Automatically in OS Windows XP 1. Click the Start button and proceed to the Control Panel > Network and Internet Connections > Network Connections window. 2. In the Network Connections window, right-click the relevant Local Area Connection icon and select the Properties line in the menu displayed.
  • Page 6 DIR-615S Quick Installation Guide 4. Select the Obtain an IP address automatically and Obtain DNS server address automatically radio buttons. Click the OK button. 5. Click the ОК button in the connection properties window. Now your computer is configured to obtain an IP address automatically.
  • Page 7 DIR-615S Quick Installation Guide Obtaining Address Automatically in OS Windows 7 1. Click the Start button and proceed to the Control Panel window. 2. Select the Network and Sharing Center section. (If the Control Panel has the category view (the Category value is selected from the View by...
  • Page 8 DIR-615S Quick Installation Guide 6. Select the Obtain an IP address automatically and Obtain DNS server address automatically radio buttons. Click the OK button. 7. Click the OK button in the connection properties window. Now your computer is configured to obtain an IP address automatically.

  • Page 9: Pc With Wi-Fi Adapter

    DIR-615S Quick Installation Guide PC with Wi-Fi Adapter 1. Connect the power cord to the power connector port on the back panel of the router, then plug the power adapter into an electrical outlet or power strip. 2. Turn on the router by pressing the ON/OFF button on its back panel.

  • Page 10: Configuring Wi-Fi Adapter In Os Windows Xp

    DIR-615S Quick Installation Guide Configuring Wi-Fi Adapter in OS Windows XP 1. Click the Start button and proceed to the Control Panel > Network and Internet Connections > Network Connections window. 2. Select the icon of the wireless network connection and make sure that your Wi-Fi adapter is on.

  • Page 11: Configuring Wi-Fi Adapter In Os Windows 7

    DIR-615S Quick Installation Guide Configuring Wi-Fi Adapter in OS Windows 7 1. Click the Start button and proceed to the Control Panel window. 2. Select the Network and Sharing Center section. (If the Control Panel has the category view (the Category value is selected from the View by...
  • Page 12 DIR-615S Quick Installation Guide 6. In the opened window, in the list of available wireless networks, select the wireless network DIR-615 and click the Connect button. 7. In the opened window, enter the network key (see WPS PIN on the barcode label on the bottom panel of the device) in the Security key field and click the OK button.

  • Page 13: Configuring Router

    DIR-615S Quick Installation Guide CONFIGURING ROUTER Connecting to Web-based Interface Start a web browser. In the address bar of the web browser, enter the IP address of the router (by default, the following IP address is specified: 192.168.0.1). Press the Enter key.
  • Page 14 DIR-615S Quick Installation Guide When the web-based interface is accessed the next time and after, the login page opens. Enter the username (admin) in the Login field and the password you specified in the Password field, then click the Enter button.
  • Page 15 DIR-615S Quick Installation Guide After successful registration the Home / Information page opens. The page displays general information on the router and its software.
  • Page 16 DIR-615S Quick Installation Guide The web-based interface of the router is multilingual. If you need to select another language for the web-based interface, place the mouse pointer over the English caption in the top part of the page and select a language from the menu displayed.

  • Page 17: Configuring Connection To The Internet

    DIR-615S Quick Installation Guide Configuring Connection to the Internet You should configure your WAN connection in accordance with data provided by your Internet service provider (ISP). Make sure that you have obtained all necessary information prior to configuring your connection. Otherwise contact your ISP.
  • Page 18 DIR-615S Quick Installation Guide 6. If your ISP uses MAC address binding, in the Ethernet section, in the MAC field, enter the MAC address registered by your ISP upon concluding the agreement. To set the MAC address of the network...
  • Page 19 DIR-615S Quick Installation Guide 7. For connection of PPPoE type: in the PPP section, enter authorization data provided by your ISP (the username (login) in the Username field and the password in the Password and Password confirmation fields), or select the Without authorization checkbox if authorization is not required.
  • Page 20 DIR-615S Quick Installation Guide 9. For connection of Static IP type: in the IP section, fill in the IP Address, Netmask, Gateway IP address, and Primary DNS server fields. 10. For connection of Dynamic IP type: if your ISP has provided the address...
  • Page 21 DIR-615S Quick Installation Guide For connection of Static IPv6 type: in the IP section, fill in the IPv6 address and Gateway IPv6 address fields. 12. For connection of Dynamic IPv6 type: if your ISP has provided the address of the DNS server, in the IP section, deselect the Obtain DNS server addresses automatically checkbox and fill in the Static primary DNS server field.
  • Page 22 DIR-615S Quick Installation Guide 13. For connection of PPPoE + Static IP type: in the IP section, fill in the IP Address, Netmask, Gateway IP address, and Primary DNS server fields. Then in the PPP section, enter authorization data provided...
  • Page 23 DIR-615S Quick Installation Guide 14. For connection of PPPoE + Dynamic IP type: if your ISP has provided the address of the DNS server, in the IP section, deselect the Obtain DNS server addresses automatically checkbox and fill in the Primary DNS server field.
  • Page 24 DIR-615S Quick Installation Guide 15. For connection of PPTP + Static IP or L2TP + Static IP type: in the IP section, fill in the IP Address, Netmask, Gateway IP address, and Primary DNS server fields. Then in the VPN section, enter...
  • Page 25 DIR-615S Quick Installation Guide 16. For connection of PPTP + Dynamic IP or L2TP + Dynamic IP type: if your ISP has provided the address of the DNS server, in the IP section, deselect the Obtain DNS server addresses automatically checkbox and fill in the Primary DNS server field.
  • Page 26 DIR-615S Quick Installation Guide Example of Connection via VLANs If your ISP provides: access to the Internet via the VLAN with the tag (VLAN ID) 2, the • PPPoE connection type, login user, password user_password, access to IPTV service via the VLAN with the tag (VLAN ID) 10, •...
  • Page 27 DIR-615S Quick Installation Guide 14. Click the Add button. 15. In the Name field, enter a name for the new group (IPTV). 16. From the Type drop-down list, select the Bridge value. 17. From the Tagged port drop-down list, select the internet value.
  • Page 28 DIR-615S Quick Installation Guide 29. Click the Add button. 30. On the opened page, select the PPPoE value from the Connection Type drop-down list. From the Interface drop-down list, select the Internet.2 value. 32. In the Username field, enter user.

  • Page 29: Configuring Local Area Network

    DIR-615S Quick Installation Guide Configuring Local Area Network Go to the Net / LAN page. If needed, change the IP address of the router's LAN interface and the mask of the local subnet in the IP Address and Netmask fields. To change the IPv6 address of the router's LAN interface, deselect the DHCP PD checkbox in the IPv6 address assignment section.

  • Page 30: Saving Settings To Non-Volatile Memory

    DIR-615S Quick Installation Guide Saving Settings to Non-volatile Memory In order to avoid losing the new settings upon hardware reboot (accidental or intentional power-off of the device), it is recommended to save the settings to the non-volatile memory of the router.

  • Page 31: Technical Support

    Quick Installation Guide TECHNICAL SUPPORT You can find software updates and user documentation on our website. D-Link provides its customers with free support within the product's warranty period. Customers can contact the technical support group by phone or by e- mail/Internet.
