INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
NOTICE: DO NOT discard this manual!
Models:
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certifi ed kit is used.
Owner's Manual
Care and Operation
Heatilator • ION-V7, ION-S7, ION-H7 Owner's Manual • 2276-981 Rev. E • 5/17
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See appliance installation manual for additional
Commonwealth of Massachusetts requirements.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
1

Advertisement

Table of Contents
loading

Related Manuals for Heatilator ION-V7

Summary of Contents for Heatilator ION-V7

  • Page 1 fi tter. appliance is not convertible for use with other See appliance installation manual for additional gases, unless a certifi ed kit is used. Commonwealth of Massachusetts requirements. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 2: Welcome

    00,000 00,000 00,000 MIN. MIN. INPUT INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 Serial Serial XXXXXXXX XXXXXXXX ORIFICE ORIFICE SIZE: SIZE: #XXXXX #XXXXX #XXXXX #XXXXX (Serie): (Serie): Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 3: Table Of Contents

    C. Contact Information ......25  = Contains updated information. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 4: Limited Lifetime Warranty

    Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645G 2/15 Page 1 of 2 Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...
  • Page 5 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645G 2/15 Page 2 of 2 Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 6: Product Specifi C And Important Safety Information

    B. Glass Specifi cations (Ceramic) This appliance is equipped with 5 mm ceramic glass. Re- place glass only with 5 mm ceramic glass. Please contact your dealer for replacement glass. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 7: General Information

    fi rebox. Call a qualifi ed • Install a switch lock or a wall/remote control with child service technician to service the appliance protection lockout feature. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 8: General Operating Parts

    • Conversions must be made by a qualified service technician using Hearth & Home Technologies specifi ed and approved parts. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 9: Wall Surface/Tv Guidelines

    OF APPLIANCE OUTER WRAP APPLIANCE FRONT Figure 3.3. Maximum Wall Surface Temperatures Above Appliance NOTICE: Placement of a TV above the ION is NOT recommended by Hearth & Home Technologies. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 10: Lighting Instructions (Ipi Plus)

    Keep burner and control compartment clean. See installation and operating instruc- Propane Installation code, CSA B149.1. tions accompanying appliance. For additional information on operating your 593-913i Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 11: Appliance Break-In

    • Adjust the height of the fl ame by varying the input using the remote control. For more information, see the instructions that accompany the remote control. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 12: Operation During A Power Outage

    See Figure 3.4. NOTICE: Some functionality will be lost when using battery backup including remote control or any other auxiliary functions that require household 110-120 VAC power. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 13: Detailed Component Operating Instructions

    The appliance has a safety feature that automatically shuts down the fi replace after nine hours of continuous operation without receiving a command from the wall switch or optional remote. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 14: Maintenance And Service

    Place the front on the two bottom hooks and then tilt inward and onto the top two hooks. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...
  • Page 15 Place the front on the two bottom hooks and then tilt inward and onto the top two hooks. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 16: Maintenance Tasks - Qualifi Ed Service Technician

    • Verify burner is properly secured and aligned with pilot or igniter. • Clean off burner top, inspect for plugged ports, corrosion or deterioration. Replace burner if necessary. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 17: Frequently Asked Questions And Troubleshooting

    fi cations of the attached non-combustible material are listed in the Installer’s Manual for this the touch. (In-Wall installations only) appliance. Contact your dealer for additional information regarding operation and troubleshooting. Visit www.heatnglo.com to locate a dealer. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 18: Troubleshooting - Intellifire™ Plus Ignition System

    D. Pilot valve solenoid. Verify that 1.5 to 1.8 VDC is supplied to pilot solenoid from module. If below 1.5 volts, replace module. If 1.5 volts or greater, replace valve. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...
  • Page 19 fl ame sensing rod. Verify continuity with a multi-meter with ohms set at lowest range. Replace pilot if any damage is detected. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 20: Reference Materials

    For more information refer to the instructions supplied with your decorative door or front. Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...

  • Page 21: Service Parts

    5941237, 6006743, 6019099, 6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7098269, 7258116, 7470729, 8147240 or other U.S. and foreign patents pending. 2000-945C Printed in U.S.A. - Copyright 2017 Heatilator • ION-V7, ION-S7, ION-H7 Owner’s Manual • 2276-981 Rev. E • 5/17...
