Summary of Contents for Sony Xperia M5 Dual E5633
- Page 1 White paper August 2016 Xperia™ M5 Dual E5633/E5643/E5663...
- Page 2 White paper | Xperia™ M5 dual Purpose of this document Sony Mobile Communications product White papers are intended to give an overview of a product and provide details in relevant areas of technology. NOTE: All illustrations, screen images, and elements are for reference only and subject to change at any time without prior notice.
-
Page 3: Table Of Contents
White paper | Xperia™ M5 dual Table of contents Product overview ......................2 Highlights .......................2 Product specifications ...................3 Categorised feature list ..................6 Technologies in detail ....................8 Accessibility and Usability ..................8 Device-to-device communications (local) .............9 Bluetooth® wireless technology .................9 DLNA Certified™ (Digital Living Network Alliance) ...........11 Messaging ......................12 MMS (Multimedia Messaging Service)..............12 Email .........................12... -
Page 4: Product Overview
White paper | Xperia™ M5 dual Product overview Highlights • Camera: 21.5 MP Exmor RS™ Hybrid Autofocus main camera and a 13 MP Exmor RS™ front camera • Battery: Extended standby and Ultra STAMINA Mode • Design: IP65/68 • Connectivity: 4G LTE Cat 4 (up to 150 Mbps) Hybrid Autofocus The Xperia™... -
Page 5: Product Specifications
White paper | Xperia™ M5 dual Product specifications Operating system Google™ Android™ 6.0 (Marshmallow) Processor 2.0 GHz MediaTek Helio X10 Octa Core IMG Rogue G6200 Size 145 x 72 x 7.6 mm Weight 142.6 grams Available colours Black White Gold SIM card Nano dual SIMs Main screen... - Page 6 White paper | Xperia™ M5 dual Auto Focus Photo Flash ISO 3200 in manual mode Minimum focus distance 100 mm 2nd Camera Camera resolution 13 MP Exmor Yes – Exmor RS™ Video recording Yes – Full HD 1080p Auto Focus Sensors Accelerometer Ambient light sensor...
- Page 7 White paper | Xperia™ M5 dual EDGE Up to 236.8 kbps (download). Up to 236.8 kbps (upload). (upload and download) HSUPA (upload) Cat. 6, up to 5.76 Mbps HSDPA (download) Cat. 24, up to 42.2 Mbps LTE (upload and download) Cat.
-
Page 8: Categorised Feature List
White paper | Xperia™ M5 dual Categorised feature list Internet Music Camera Google Chrome™* Album art Auto Focus Google Play™* Bluetooth® stereo (aptX®, A2DP) AR effect Google™ search* ClearAudio+ AR Mask Google Voice™ Search* Clear Bass™ Burst mode Google Maps™ with Street view* Clear Phase™... - Page 9 White paper | Xperia™ M5 dual Connectivity Organiser Entertainment 3.5 mm audio jack (CTIA) Airplane mode Radio (FM radio with RDS*) aGPS* Alarm/Clock/Stopwatch/Timer Sony Entertainment Network* Bluetooth® 4.1 wireless Battery STAMINA mode YouTube™* technology Calculator Device connection Calendar DLNA Certified™...
-
Page 10: Technologies In Detail
The information presented in this section is a general overview of the technology incorporated into the product. However, hardware and software levels of compliance to standards and specifications vary between products and markets. For more information, contact Sony Mobile Developer World or the relevant Sony representative. -
Page 11: Device-To-Device Communications (Local)
White paper | Xperia™ M5 dual Device-to-device communications (local) Bluetooth® wireless technology Bluetooth® profiles supported Advanced Audio Distribution Profile v1.2 Audio/Video Control Transport Protocol Profiles v1.4 Audio/Visual Distribution Profile v1.3 Audio/Video Remote Control Profile v1.3 Bluetooth Network Encapsulation Protocol v1.0 Device ID Profile v1.3 Generic Access Profile General Audio/Video Distribution Profile v1.2... - Page 12 White paper | Xperia™ M5 dual Wi-Fi® Supported standards IEEE 802.11a/b/g/n and Wi-Fi® Wi-Fi Direct®, Wi-Fi CERTIFIED Miracast™ Connectable devices Wi-Fi® access points Wi-Fi Direct compatible devices Frequency band 2.4 GHz / 5 GHz Data transfer rate Up to 150 Mbit/s Security Open Authentication Shared Authentication...
-
Page 13: Dlna Certified™ (Digital Living Network Alliance)
White paper | Xperia™ M5 dual DLNA Certified™ (Digital Living Network Alliance) Supported Device Classes M-DMS – Mobile Digital Media Server Media Types: images, music and video Summary: The digital media server exposes the media files in your device to a Wi-Fi® network. The files can then be accessed from other DLNA Certified™... -
Page 14: Messaging
White paper | Xperia™ M5 dual Messaging MMS (Multimedia Messaging Service) According to OMA Multimedia Messaging Service v1.0 + SMIL Email Bearer type (IP) GPRS, EGPRS, UMTS, LTE, Wi-Fi® Character sets BIG5 Traditional Chinese GB2312 Simplified Chinese GB18030 ISO-2022-JP Japanese ISO-8859-1 ISO-8859-2 Eastern Europe ISO-8859-5 Cyrillic... -
Page 15: Positioning - Location Based Services
White paper | Xperia™ M5 dual Positioning – location based services Supported standards: • OMA Secure User Plane Location (SUPL) v1.0, v2.0 • 3GPP™ Control Plane location (incl. Emergency location) Supported satellite systems: • GPS • GLONASS NOTE: When needed, the device automatically uses a combination of all available satellite systems to accurately provide location information. -
Page 16: Multimedia (Audio, Image And Video)
White paper | Xperia™ M5 dual Multimedia (audio, image and video) Audio Playback Decoder format Supported in file format Audio decoding MPEG-1/2/2.5, MP3 (.mp3) audio layer 3 AAC, AAC+, eAAC+ 3GPP (.3gp), MP4 (.mp4) AMR-NB, AMR-WB 3GPP (.3gp), MP4 (.mp4) General MIDI (GM) SMF (.mid) Linear PCM 16 bit... - Page 17 White paper | Xperia™ M5 dual Image Playback Decoder format Supported in file format 1, 4, 8, 16, 24 and 32 bpp and RLE BMP (.bmp) encoded formats Single and multi-frame, bitmap GIF (.gif) mask support (GIF87a format and GIF89a format) Joint Photographic Experts Group JPEG (.jpg, .jpeg) Portable Network Graphics Bitmap...
-
Page 18: Synchronisation (Oma Ds, Eas, Google Sync™)
White paper | Xperia™ M5 dual Synchronisation (OMA DS, EAS, Google Sync™) OMA Data Synchronisation protocol versions 1.1.2 and 1.2 OMA Data Formats: vCard 2.1, vCalendar 1.0 Microsoft® Exchange ActiveSync® protocol version 2.5 Microsoft® Exchange ActiveSync® protocol version 12 Microsoft® Exchange ActiveSync® protocol version 12.1 Microsoft®... -
Page 19: Memory In Android™ Devices
Paper is noted as such. Types of memory The types of memory described and numbered below are consistent with the terminology used in Sony mobile device menus and in other content relating to 2015 Xperia™ devices: 1. Dynamic Memory (also known as RAM) is used by applications that run when the device is turned on. - Page 20 9.1 GB of Internal Storage available out of the box. Please note that in Sony Mobile 2015 products, “Internal Storage” is now the combination of what was previously known as “Device Memory” or “Phone Memory” (for applications and their data – also previously known as “/data”) and “Internal Storage”...
- Page 21 4. SD Card (known as “/sdcard1” from a programmer’s point of view, or by other names in other Android products) is the name for the removable SD memory card in all 2015 Sony Mobile products. As described in the previous section, this External Card memory is generally more limited in that any application can read from it, but many applications cannot save to this card.
- Page 22 White paper | Xperia™ M5 dual Note 3: For a developer, it is important to note that from a programming point of view the location names used to refer to the different memory areas described in Note 1 are still valid, i.e., the area used for applications (“/ data”) is still present, as is the area used for content (“/sdcard”).
-
Page 23: Trademarks And Acknowledgements
White paper | Xperia™ M5 dual Trademarks and acknowledgements All product and company names mentioned herein are the trademarks or registered trademarks of their respective owners. Any rights not expressly granted herein are reserved. All other trademarks are property of their respective owners. Visit www.sonymobile.com for more information.
