We hope that you’ll enjoy your Toyotomi appliance for years to come! We invite you to read this instruction manual first, to ensure the maximum lifetime for this appliance. Get to know us better… visit us at www.toyotomi.eu for our full line of products. 1 Read the diRections foR Use fiRst.
GENERAL DIRECTIONS FOR USE Below you will find the main steps to be taken for using your heater. For more details, please refer to the MANUAL. Remove all packaging materials (refer to Section A, Fig. A). Fill the removable tank 6 (refer to Section B, Fig. C). Insert the plug into the wall-socket.
WHAT YOU NEED TO KNOW IN ADVANCE ventilate sufficiently Read this user manual carefully before using the appliance and keep it for future reference. Install this device only when it complies with local/national legislation, ordinances and standards. This product is intended to be used as a heater in residential houses and is only suitable for use in dry locations, in normal household conditions, indoors in living room, kitchen and garage.
14 tiPs fOR safe use 1 Children should be supervised to ensure that they do not play with the appliance. 2 DO NOT move the heater when it is burning or still hot. DO NOT refill nor service the heater when it is burning or still hot.
MANUAL installinG tHe HeateR Carefully remove your heater from the box and check the contents. In addition to the heater you also need to have: a manual fuel pump a transportation cap these directions for use Keep the box and the packaging materials (Fig. A) for storage and/or transportation.
Page 7
Check the removable tank fuel gauge while filling the tank (Fig. E). Stop filling once the gauge indicates that the tank is full. Never overfill the tank, especially not when the fuel is very cold (fuel expands when it heats up). 5 Let the remaining fuel in the pump flow back into the jerrycan and carefully remove the pump.
The available temperature settings range from 6°C minimum to 28°C maximum. When the heater has been unplugged (or after a power failure), the temperature will reset to the factory setting of 20°C. usinG tHe tiMeR The timer allows you to switch on the heater automatically at a preset time. In order to switch on the timer, the correct time must have been set (refer to Section C) and the heater should be off.
cODe infORMatiOn WHat tO DO e - 0 Temperature within the heater too high. Cool-down and re-ignite. f - 0 Power interrupted. Re-ignite the heater. e - 1 Faulty thermostat. Contact your dealer. f - 1 Faulty burner thermistor. Contact your dealer. e - 2 Starting problems.
Page 10
tHe cORRect use Of ‘save’ The ‘SAVE’ function allows you to limit the temperature. When this function is activated, the heater will automatically switch off, when the room temperature exceeds the set temperature by 3°C. Subsequently, when the room temperature has dropped again to the set temperature, the heater will automatically switch on again.
Page 11
3 Reinstall the fuel filter into the heater. We recommend that you remove dust and stains from time to time with a damp cloth, because otherwise these may cause stains that are hard to remove. Do not remove any heater components yourself. Always contact your dealer for repairs.
Page 12
sPecificatiOns Ignition electrical Dimensions (mm) width Fuel paraffin including base plate: depth Capacity (kW) max. 4.00 height Capacity (kW) min. 1.05 Accessories: - manual fuel pump Suitable space (m 62-170 - transportation cap Fuel consumption (l/hr) 0.417 Mains 230 V -- AC / 50 Hz Fuel consumption (g/hr) Electrical consumption:...
Main cOMPOnents front plate Grid Base plate lid for removable tank Operation panel Removable tank air filter vent filter thermostat Plug + cord information display childproof lock adjustment keys (time and temperature) timer save key Handle extension ...
Page 14
Caso necessite de mais informações ou se ocorrerem problemas específicos que não constem neste manual de instruções, por favor, visite nosso website www .toyotomi .eu ou entre em contato com o nosso Suporte de Vendas (encontrará o número de telefone em www .toyotomi .eu) .
