Summary of Contents for CDA DK1151
- Page 1 Double Oven Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu...
-
Page 2: Appliance Information
The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance. -
Page 3: Important Safety Precautions And Recommendations
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. - Page 4 • Do not touch the appliance with wet or damp hands (or feet). • Do not use the appliance whilst in barefoot. • If you should decide not to use this appliance any longer (or decide to substitute another model), before disposing of it, it is recommended that it be made inoperative in an appropriate manner in accordance to health and environmental protection regulations, ensuring in particular that all potentially hazardous...
- Page 5 • WARNING: Take care NOT to lift the appliance by the door handle. • CDA does not supply handles for grill pans because all grilling must be done with the door shut and a handle could get in the way...
- Page 6 ENERGY LABELLING/ECODESIGN Commission delegated regulation (EU) No 65/2014 (supplementing Directive 2010/30/EU • of the European Parliament and of the Council). Commission regulation (EU) No 66/2014 (implementing Directive 2009/125/EC of the • European Parliament and of the Council). Reference to the measurement and calculation methods used to establish compliance with the above requirements: Standard EN 60350-1 (electric ovens).
-
Page 7: Control Panel
Control Panel Fig. 1 Controls Description Oven temperature knob (Top oven) Oven function selector knob (Top oven) Clock and timer with “touch control” keys (Top main oven only) Oven function selector knob (Bottom oven) Oven temperature knob (Bottom oven) Bottom oven temperature indicator lamp Top oven temperature indicator lamp... -
Page 8: Multifunction Oven
Multifunction Oven General Features As its name indicates, this is an oven that presents particular features from an operational point of view. In fact, it is possible to use 7 different programmes to satisfy every cooking need. The 7 positions, thermostatically controlled, are obtained by 4 heating elements which are: •... -
Page 9: How To Use The Oven
How to Use the Oven WARNING: The door is hot, use the handle. ATTENTION - MOST IMPORTANT Pay special attention not to touch the hot heating element inside the oven cavity. Fig. 3 Fig. 2 Thermostat Knob (Fig. 2) To turn on the heating elements of the oven, set function selector knob to the required position and the thermostat knob to the desired temperature. - Page 10 Traditional Grilling The infrared grill element comes on. The heat is dispersed by radiation. Use with the oven door closed. The temperature can be regulated via the thermostat knob to between 50 °C and 225 °C. For cooking hints, see the chapter “USE OF THE GRILL”. Recommended for: Intense grilling, browning, cooking au gratin and toasting etc.
-
Page 11: Cooking Advice
Maintaining Temperature After Cooking or Slowly Heating Foods The upper heating element, the circular element and the fan come on. The heat is dispersed by forced convection with greater intensity in the upper part. The temperature can be set to between 50 °C and 140 °C via the thermostat knob. Recommended for: Keeping food warm after any type of cooking. - Page 12 Grilling and “Au Gratin” Grilling may be done by selecting grill+fan setting with the function selector knob, because the hot air completely envelops the food that is to be cooked. After having preheated the oven, simply place the food on the grid. Close the door and let the oven operate until grilling is done.
-
Page 13: Clock And Timer With "Touch-Control" Keys
Clock and Timer with “Touch-Control” Keys (Lower Main Oven only) Keys: Touched simultaneously (for more than 2 seconds): • setting the clock; • setting the timer volume (by touching once, along with the “ ” key); • to cancel automatic cooking at any time. - Page 14 “TOUCH-CONTROL” KEYS The “touch-control” keys shall be operated by the fingers (just by touching the key). When using touch controls it is best to use the ball of your finger rather than the tip. The keys are automatically deactivated: • 8 seconds after the last selection;...
- Page 15 SETTING THE TIMER VOLUME You can select from three volume levels. • Touch the “ ” and “ ” keys simultaneously for more than 2 seconds. • Touch the “ ” key; you can read on the display the current timer volume (“ton1”, “ton2” or “ton3”). •...
-
Page 16: Do's And Do Not's
Do’s and do not’s • Do always grill with the oven door closed. • Do read the user instructions carefully before using the double oven for first time. • Do allow the double oven to heat as indicated in the specific sections, before using for the first time, in order to expel any smell from the new oven insulation, without the introduction of food. -
Page 17: Care And Maintenance
Care and Maintenance IMPORTANT: It is advisable to clean when the appliance is cold and especially for Before any operation cleaning the enamelled parts. cleaning Avoid leaving alkaline or acidic substances (lemon juice, vinegar, etc.) on m a i n t e n a n c e the surfaces. - Page 18 Replacing the Halogen Oven Lights WARNING: Ensure the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. • Allow the oven cavity and the heating elements to cool down. • Switch off the electrical supply. Top Right Lamp: •...
- Page 19 Assembling and Dismantling of the Side Runner Frames • Assemble the wire racks to the oven walls using the 2 screws (Fig. 6). • Slide into the guides, the shelf and the tray (fig. 7). The rack must be fitted so that the safety notch, which stops it sliding out, faces the inside of the oven;...
- Page 20 Oven Doors Removing the Oven Doors Fig. 8a The oven door can easily be removed as follows: • Open the door to the full extent (fig. 8a). Open the lever A completely on the left and right • hinges (fig. 8b). •...
- Page 21 Top and Lower Oven Door Removable Inner Pane of Glass Cleaning the Panes of Glass The oven door is fitted with no. 2 panes: • no. 1 outside; • no. 1 inner; To clean the panes on both sides it is necessary to remove the inner pane as follows.
- Page 22 Replacing the Inner Pane of Glass 1. Make sure the door is locked open (see fig. 12). 2. Replace the inner pane: • Check that the four rubber pads are in place (D in Fig. 14). • Check that you are holding the pane the correct way. You should be able to read the wording on it as it fa- ces you.
-
Page 23: Advice For The Installer
ADVICE FOR THE INSTALLER Important Appliance installation and maintenance must only be carried out by QUALIFIED TECHNICIANS and in compliance with the local safety standards. • Failure to observe this rule will invalidate the warranty. • Always disconnect the appliance from the electrical supply before carrying out any maintenance operations or repairs. -
Page 24: Installation
Installation Important • You need the following housing area to fit your oven correctly. • The double oven is designed to fit into a cabinet of 600 mm width. • The double oven can be built in the kitchen units, but you must ensure that it is properly ventilated. •... - Page 25 Installation diagrams for illustration purposes only J J' 16 - 20 mm 2.5 mm Fig. 19...
-
Page 26: Fixing The Oven
Fixing the oven Introduce the oven into the furniture opening and fix it with screws (not supplied) as figure 20. It is essential that the oven rests on a surface which will support its weight, as the screw fixing is only complementary. - Page 27 IMPORTANT: • To avoid damage to the lower trim please note the following instructions. • The lower trim is designed to allow for good air circulation and the correct opening of the oven door. • To ensure the trim is not damaged due to the appliance being placed on the floor, the appliance should be suitably supported as in below illustrations.
-
Page 28: Electrical Installation
Electrical Installation For your safety please read the following information: WARNING! Before effecting any intervention on the electrical parts the appliance must be disconnected from the network. IMPORTANT: The oven must be installed in accordance with the manufacturer’s instructions. Incorrect installation, for which the manufacturer accepts no responsibility, may cause damage to persons, animals and things. - Page 29 Connection the Double Oven Mains Cable Important! This oven must be connected to the mains power supply only by a suitably qualified person. • Unscrew the screw A securing the cover plate B behind the oven (fig. 22). • Remove the cover plate B. •...
-
Page 30: Appliance Servicing
Appliance Servicing CDA provide a quality and effective after-sales service to cover all your servicing needs. Please attach your receipt to this page for safekeeping. Please help us to help you by having the following information available when booking a service-call: Model type, make and model –... - Page 32 T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu Copyright © CDA 2015...
