- Page 3 OSXL160 Infrared Camera User Manual Please read carefully before first use...
- Page 5 WARNING DO NOT USE WHEN RAINING! DO NOT OPEN OR EXCHANGE PARTS! REPAIR ONLY CAN BE CONDUCTED BY STUFF! N O T I C E In order not to cause malfunction or even damage the device please do not direct the lens towards strong high-temperature radiation source (such as the sun) whether the power is on or off! Avoid violent shock and impact during operation or transport.
-
Page 7: Table Of Contents
Table of Contents Product Summary ..........1 1.1 Standard Item List ..........2 Battery and Charger..........3 2.1 Charging Battery ..........4 2.2 Direct Charging ............ 4 2.3 Attention for Using Battery Charger...... 4 Panel Function Summary ........5 3.1 Main Control Panel..........5 3.2 Rear Interface Panel .......... - Page 8 Adjust Temp.......... 23 Save Setting ..........24 5.2.3 Image ............24 Image Setup ..........25 Alarm Switch ......... 25 Alarm Temp .......... 25 Alarm Color ........... 26 Isotherm Color ........26 Isotherm Temp........26 Isotherm Width........26 Screen Display........26 Analysis Setup ..........
-
Page 9: Product Summary
OSXL160 Infrared Camera the new standard in Infrared imaging industry! Typical Application: Power Plant: Monitor and diagnose the condition of electrical wire and equipment, detect power leak, and... -
Page 10: Standard Item List
1.1 Standard Item List OSXL160 Infrared Camera comes with the following standard items and accessories: Item Quantity OSXL160 Infrared Camera Li-Ion Battery Battery Charger USB Cable Video Cable User Manual IR See Software CD Suitcase... -
Page 11: Battery And Charger
2. Battery and Charger It is recommended to charge battery immediately when device indicates low power. By press and move in the indicated direction, user can easily insert and remove battery. Battery Insertion Battery Removal Device comes with two sets of Li-Ion battery and one battery charger. -
Page 12: Charging Battery
2.1 Charging Battery Following the direction indicated on battery charger, insert the Li-Ion battery, press firmly and push all the way in. During charging, the red LED will be on, and when charging is completed, the green LED will be on instead. : Normally it takes 3 hours to completely charge one battery. -
Page 13: Panel Function Summary
3. Panel Function Summary In this manual, “long press” means Long press button down for about 2 seconds, and “press” or “short press” means press and release. 3.1 Main Control Panel 1. Power ON/OFF Button Long press this button to turn on or off the device. 2. - Page 14 Long press to save current Infrared image Press to switch between normal view and 2X zoom After press Hotkey button (refer page 8, 3.3) and in area measure mode: Select the measure spot; press , and to move the spot in the same direction. Select the measure line and sampling line;...
-
Page 15: Rear Interface Panel
3.2 Rear Interface Panel 10. Video Output CVBS standard video output. 11. Audio Output Audio output playbacks recorded voice annotation. 12. USB 2.0 Interface USB2.0 interface transfers data between device and PC. 13. External DC In External DC requirement is 12V. 3.3 Side View 14. -
Page 16: Quick Start Reference
Press Hotkey button to switch between Color Palette, area measurement rectangle, temperature limits, and long press Hotkey button to turn on/off laser sight. 15. Sound Alarm Buzzer Signal sound alarm when reaches temperature limit. 4. Quick Start Reference 4.1 Infrared Image Insert Li-Ion battery correctly. -
Page 17: Infrared Image And Voice Annotation
4.3 Infrared Image and Voice Annotation Each thermal image can save up to 40 seconds voice annotation data. Image and voice annotation can later be reviewed on PC by bundled IRSee software. To save Infrared image, first press button to freeze image, and then long press button again to open the voice recording menu. -
Page 18: Connect To Pc
4.3 and 4.4 hereinabove. 4.6 Connect to PC Connect device to PC using included USB cable. Refer OSXL160 software manual for additional PC operation instruction. It is recommended to format device periodically. 5. Operation Menu 5.1 Display Summary All items can be selected by short pressing the Hotkey button (Note: Long press Hotkey button will turn on/off laser sight). - Page 19 selected item is flashing in yellow color. If no operation in 2 seconds after selection, Hotkey mode will exit automatically. Real Time Thermal Image Interface Symbol for 2X zoom: symbol 2X denotes enlarge twice in size; press button to realize the function. 2, 4 Area measure box: 3 areas can be selected in area measure mode.
-
Page 20: Main Menu
13, 15 Lower limit temperature, upper limit temperature: the lower and upper limit temperature of the color code at the same time. Color code: color palette. Any kind of color code is available in the palette. 5.2 Main Menu Menu and sub-menu items: Press OK button (when not in Hotkey mode) to enter main menu. -
Page 21: File
Main Menu Using button to select menu item, and selected item is highlighted with white background. Press OK or button to enter sub-menu. Press button to return to previous menu or exit. 5.2.1 File Using File menu to save, playback, delete thermal image and voice annotation. -
Page 22: Manage
Manage Select Manage to preview thermal image, add or edit voice annotation, or delete thermal image. File Manage Folder is automatically created if not exist when saving thermal image. Folder name is MYYMMDD, and YYMMDD is year, month, and date. For example, Jan 2 , 2009 folder is M090102. - Page 23 Thermal Image preview Press button to switch saved thermal image in the same folder. The icon indicates voice annotation data with current thermal image. Long press button to enter Voice Annotation menu. If voice annotation already exists, press Record will record new voice annotation and erase previously saved one.
-
Page 24: Save
Delete Saved Thermal Image To exit thermal image playback, long press OK button. Save Save current thermal image. Freeze image first before saving. Format Format the internal FLASH memory. Press OK to confirm or cancel to exit. Format will erase all saved thermal images. It is recommended to transfer data to PC before format. -
Page 25: Spot Measure
Measure Sub-menu Spot Measure Press button to select or deselect. Selected spot is check marked. Up to 4 spots can be selected at the same time. Spot Target Selection... - Page 26 Spot Measure Measure result on upper-right LCD corner is temperature reading at location marked with . Up to 4 spots can be selected. Spot Measure Attribute Press Hotkey button until spot marker is flashing in yellow, and then use buttons to move spot location to different directions.
-
Page 27: Line Measure
Emissivity: Refer to Appendix Emissivity of raw materials. Set Reference: Set current spot as reference point. If selected, all measure result will be relative value to this spot temperature. Line Measure There are 2 line measure options: vertical and horizontal. Horizontal Line Measure Horizontal Line Measure Horizontal line is temperature sampling line, and upper-right LCD... -
Page 28: Vertical Line Measure
Vertical Line Measure Vertical Line Measure Vertical line is temperature sampling line, and upper-right LCD corner displays temperature measurement reading on horizontal cursor line intersection. After using Hotkey button select line measure, press button to adjust sampling line position, and press button to adjust cursor line position. - Page 29 Area (Rect) Target Selection Area (Rect) Measure Measure result on upper-right LCD corner is the temperature measurement result within the corresponding rectangle. There are 3 measure types: max, min, and average temperature.
-
Page 30: Parameters
Area (Rect) Measure Attribute: Press Hotkey button until area rectangle is flashing in yellow. Press OK button to enter Attribute Menu in which four parameters can be adjusted namely: emissivity, set reference, measure type, move /size. Emissivity: Refer to Appendix: Emissivity of raw materials. Set Reference: Set current area as reference. -
Page 31: Emissivity
Emissivity Emissivity varies based on target subject material, surface temperature, surface roughness, measurement angle, and etc. Press once to change Emissivity by 0.01. Long press will change Emissivity in 0.1 intervals. Distance This value can be omitted if target subject is close to device (less than 10m). -
Page 32: Save Setting
Save Setting All parameter changes must be saved before power off device. Otherwise, changes will not be saved for next power on. 5.2.3 Image There are 5 items: Image Setup, Analysis Setup, Image Reverse, Clear Screen, and Auto/Manual (L&S) in Image menu. Image Sub-menu... -
Page 33: Image Setup
Image Setup Image Setup Sub-menu Alarm Switch Press turns on or off the alarm function. If the Alarm Switch is on, when target subject within area box has surface temperature exceeding Alarm Temp, device will alarm with buzzer sound and mark the high temperature location as Alarm Color if Alarm Color is set. -
Page 34: Alarm Color
Alarm Color Alarm Color can select from Auto, Black, White, Red, Orange, Yellow, Green, Blue, Gray, and Purple. Default setting is Auto, which is no color alarm. Isotherm Color When this option is Auto, there is no Isothermal display. Otherwise, target subject Infrared image will change to selected color when temperature is within the range of (Isothermal Temp ±... -
Page 35: Analysis Setup
Analysis Setup Analysis Setup Sub-menu Temp Range Select Temperature range base on measure target temperature from 2 options: standard grade ( -20/120 ) and medium grade (0/350 ). Extra grade (300/1200 ) which is customized high temperature measurement. Temp Unit Press to select Temperature Unit from , and K. -
Page 36: Ref Temp
Set reference spot or area to display measure results as relative value. Ref Temp Press once to change Ref Temp 0.1 . Long press will change Ref Temp in 1 interval. This option is only active when set Ref Temp as reference. Image Reverse Press OK button to reverse palette for thermal image display. -
Page 37: System Setup
Setup Sub-menu System Setup System Setup includes: Language, Auto Rectify, Auto Save, Video, Transparence, Display Device, Screen Save, and Power Save. Press button to switch selection, and press button to adjust value. Active item is highlighted with red background. System Setup Sub-menu... -
Page 38: Language
Language There are 11 different language options: Simplified Chinese, Traditional Chinese, English, Korean, Japanese, German, French, Russian, Italian, Portuguese and Spanish. Auto Rectify Set the number of seconds to perform next auto-rectify. Set value between 1 and 3000 seconds. Value 0 means disabling auto-rectify feature. -
Page 39: Time & Date
Set the number of minutes without operation to trigger power off completely. Select between 10min, 20min, 30min, and None. Time & Date Set system date and time. Press button to select an item, press button to change its value and press OK button to confirm. -
Page 40: Building Thermal Imaging Summary
6. Building Thermal Imaging Summary As the quality of life improves and the low-carbon life style becomes known, higher demands are being set on buildings. The features of our TI series IR camera make it possible to detect slight temperature difference and to analyze indoor humidity and leakage. - Page 41 The effect drawing of indoor water leakage The effect drawing of indoor corner air leakage...
- Page 42 The effect drawing of outdoor corner air leakage...
-
Page 43: Technical Specification
7. Technical Specification Type New UFPA micro-bolometer Resolution 160×120 Detector Pixel Spacing 25 m Standard Lens 21°×16°/0.15m Wide-angle 35°×27°/0.05m Optional Lens Telephoto lens 4°×3°/0.8m Spatial Resolution 1mrad/f=25mm Infrared Thermal Image Sensitivity Quality Frame-frequency 50/60Hz Focusing Manual Digital Zoom Spectral Range 8~14 m Display 3.5"... - Page 44 Date, Time, Temperature Unit / /K 10 Languages available, namely: Chinese (simplified & System Setup traditional), English, Italian, Japanese, Russian, French, German, Korean, Spanish and Portuguese. Emissivity Adjustable from 0.01 to 1.0 Rectification Ambient Temp Auto, according to background Rectification temperature input Atmospheric Trans Auto, according to distance, relative...
- Page 45 Continued table: Technical Specification Storage Media (Built-in Up to over 1500 images Memory) Storage Mode Auto/Manual single frame image storage Storage File Type JPEG, with 14 bits measure data Voice 40 Seconds voice recording Annotation per image (built-in microphone) Laser Director Class 2, 1mW/635nm Red Battery Type...
-
Page 46: Technical Support
8. Technical Support For common mistakes and issues during operation, please refer the following form. If issue cannot be resolved, please contact our technical support department. For simple problems arising during operation, please refer to the following table. If the problem cannot be settled, please cut off the power and contact our technical department. -
Page 47: Appendix: Emissivity Of Raw Material
9. Appendix: Emissivity of Raw Material For reference purpose only Material Surface Temp ( ) Emissivity ( ) inoxidized 0.20 Aluminum Oxidized 0.55 Brown polished 0.40 Brass Unpolished 0.22 Oxidized 0.61 Copper Oxidized badly 0.78 Oxidized 0.74 Iron Rusted 0.65 Oxidized 0.64 Cast Iron... - Page 49 Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification.
