420 ESP
Installation Guide
12/99 to 11/01
Bitwriter™, Code Hopping™, DEI®, Doubleguard®, ESP™, FailSafe®, Ghost Switch™, Learn
Routine™, Nite-Lite®, Nuisance Prevention Circuitry®, NPC®, Revenger®, Silent Mode™, Soft Chirp®,
Stinger®, Valet®, Vehicle Recovery System®, VRS®, and Warn Away® are all Trademarks or Registered
Trademarks of Directed Electronics, Inc.
®
© 2000 Directed Electronics, Inc. (Canada)
Advertisement
Table of Contents
Related Manuals for Viper 420 ESP
Summary of Contents for Viper 420 ESP
- Page 1 ® 420 ESP Installation Guide 12/99 to 11/01 Bitwriter™, Code Hopping™, DEI®, Doubleguard®, ESP™, FailSafe®, Ghost Switch™, Learn Routine™, Nite-Lite®, Nuisance Prevention Circuitry®, NPC®, Revenger®, Silent Mode™, Soft Chirp®, Stinger®, Valet®, Vehicle Recovery System®, VRS®, and Warn Away® are all Trademarks or Registered Trademarks of Directed Electronics, Inc.
-
Page 2: Primary Harness (H1), 12-Pin Connector
primary harness (H1), 12-pin connector primary harness wiring diagram ______ ORANGE (-) 500 mA ARMED OUTPUT H1/1 ______ WHITE (+)/(-) SELECTABLE LIGHT FLASH OUTPUT H1/2 ______ WHITE/BLUE (-) 200 mA CHANNEL 3 PROGRAMMABLE OUTPUT H1/3 ______ BLACK/WHITE (-) 200 mA DOMELIGHT SUPERVISION OUTPUT H1/4 ______ H1/5... - Page 3 door lock harness (H2), 3-pin connector ______ H2/A GREEN (-) LOCK, (+) UNLOCK OUTPUT ______ H2/B EMPTY UNLESS USING 451M ______ H2/C BLUE (-) UNLOCK, (+) LOCK OUTPUT This system can control two common power door lock types without any additional parts! With certain vehicles, or if an actuator is to be installed, either a p/n 451M Door Lock Relay Satellite or two relays will be required.
-
Page 4: Plug-In Harnesses
plug-in harnesses super bright LED, 2-pin white plug The super bright LED operates at 2V DC. Make sure the LED wires are not shorted to ground as the LED will be damaged. Multiple LED’s can be used, but they must be wired in series. The LED fits into a 9/32 inch mounting hole. -
Page 5: On-Board Dual Stage Shock Sensor
on-board dual stage shock sensor There is a dual-stage shock sensor inside the control unit. Adjustments are made via the rotary control as indi- cated in the diagram. Since the shock sensor does not work well when mounted firmly to metal, we do not recommend screwing down the control module. -
Page 6: Internal Programming Jumper
internal programming jumper light flash jumper This jumper is used to determine the light flash output. In the (+) position, the on-board relay is enabled and the unit will output (+)12V on the WHITE wire, H1/2. In the (-) position, the on-board relay is disabled. The WHITE wire, H1/2, will supply a 200 mA (-) output suitable for driving factory parking light relays. -
Page 7: System Features Learn Routine
system features learn routine ™ The System Features Learn Routine ™ dictates how the unit operates. Due to the number of steps, they have been broken up into two menus. It is possible to access and change any of the feature settings using the Valet ®... - Page 8 Release the Valet ® /Program button. once a feature is programmed Other features can be programmed within the same menu. Another menu can be selected. The learn routine can be exited if programming is complete. to access another feature in the same menu 1.
- Page 9 system features menus Items in bold text have been programmed to the two chirps setting at the factory. menu #1 - basic features FEATURE NUMBER ONE-CHIRP SETTING (DEFAULT) TWO-CHIRP SETTING Active arming Passive arming Chirps on Chirps off Ignition-controlled door locks on Ignition-controlled door locks off Active locking only Passive locking...
-
Page 10: Feature Descriptions
feature descriptions The features of the system are described below. Features that have additional settings that can be selected only when programming with the PC interface or Bitwriter are indicated by the following icon: menu #1 - basic features 1-1 ACTIVE/PASSIVE ARMING: When active arming is selected, the system will only arm when the transmitter is used. - Page 11 1-8 AUTOMATIC ENGINE DISABLE (AED) ON/OFF: AED is a full-time, passive starter disable that works independently of the security system. When turned on, the orange, ground-when-armed output (H1/1) will go active 30 seconds after the ignition is turned off. The LED will flash at half its normal rate when the ignition is turned off to indicate that AED is active and will interrupt the starter in 30 seconds.
- Page 12 2-4 PROGRESSIVE DOOR TRIGGER ON/OFF: The system responds to a door trigger input with a progressive response. When the door is opened with the system armed, the siren will chirp 10 times prior to the full trig- gered sequence. The door trigger is still treated as an instant trigger and closing the door quickly will not prevent a full triggered sequence from occurring.
-
Page 13: Transmitter/Receiver Learn Routine
transmitter/receiver learn routine ™ The system comes with two transmitters that have been taught to the receiver. The receiver can store up to four different transmitter codes in memory. Use the following learn routine to add transmitters to the system or to change button assignments if desired. - Page 14 Press the transmitter button: While HOLDING the Valet ® /Program switch, press the button from the transmitter that you wish to assign to the selected channel. The unit will chirp indicating successful programming. It is not possible to teach a transmitter button to the system more than once.
-
Page 15: Transmitter Configurations
transmitter configurations Using the Auto Learn functions in the Transmitter/Receiver Learn Routine, the transmitters can be programmed either with the standard single button arm/disarm configuration (default) or with the expanded configuration, which requires an optional 4-button transmitter. Standard expanded 4-buttons configuration Your system has an expanded configuration that can be fully utilized from your four-button transmitter. - Page 16 wiring quick reference guide © 2000 Directed Electronics, Inc. Vista, CA...
