Controls and accessories part number nomenclature

V
K B
A--- Original Series
B--- Second Series
V--- Heat
Recovery
Ventilator
K--- Accessory Kit
Kit Number
KVBCN0101BBS Basic HRV Control
KVBCN0101BST Standard HRV Control
KVBCN0101BLT Bryant OneTouch Control
KVAAC0101HCO Intake and Exhaust Hood
KVAAC0101HOD Exterior Intake and Exhaust Hood
KVATM010120B
20 Minute Push Button Timer
KVATM010160M
60 Minute Timer
KVAAC0101KIT
Start---Up Balancing Kit
KVAAC01016FM 6 in. Flow Meter Collar
KVAAC01017FM 7 in. Flow Meter Collar
KVAAC01018FM 8 in. Flow Meter Collar
KVAFK0101100 Internal Filter
KVAFK0201150 Internal Filter
CN
01
01--- Part Number
AC--- Accessory
CN--- Control
FL--- Filter Media
TM--- Timer
Description
Used with all HRVs
Used with all HRVs
Used with all HRVs as a main wall control
Used as a single intake/exhaust for HRVBBSVA1100, HRVBBSHA1100 only.
2 Required
Used with all HRVs when 20 minute manual operation is required
Used with all HRVs, time is adjustable between 10 and 60 minutes
Start up Balancing Kit, includes (2) 6 in. Flow Meter Collars & Magnehelic Gage
At start up, when 6 in. duct work is connected to HRV
At start up, when 7 in. duct work is connected to HRV
At start up, when 8 in. duct work is connected to HRV
Used with HRVBBSHA1100, HRVBBSVA1100 Unit 10 1/2 in. x 6 3/4 in. x 1/2 in.
Used with HRVBBLHA1150, HRVBBLHA1250 Unit 15 1/2 in. x 7 in. x 5/8 in.
01
BAU
CONTROL DESCRIPTION
BAU--- Bryant Automatic Control
BBS--- Bryant Basic Control
BST--- Bryant Standard Control
ACCESSORY DESCRIPTION
6FM--- 6 in. Flowmeters (2)
7FM--- 7 in. Flowmeters (2)
01--- Single Pack
8FM--- 8 in. Flowmeters (2)
EXH--- Exhaust Hood
HOD--- Intake Hood
KIT--- Balancing Kit
TIMER DESCRIPTION
20C--- 20-Minute Timer Kit
60M--- 60-Minute Adjustable Timer Kit
FILTER DESCRIPTION (in.)
112--- 11-1/2 x 12-3/4
116--- 11-7/8 x 16-5/8
123--- 12-15/16 x 13-1/2
145--- 14-3/8 x 15-1/2
713--- 7-13/16 x 13-1/2
810--- 8-1/8 x 10-3/4
812--- 8-7/8 x 12-3/4
916--- 9 x 16-5/8
Where Used
3
