NETGEAR JNR3210 Installation Manual

Installation Guide
N300 Wireless Gigabit Router with USB
JNR3210
Package Contents
N300 Wireless Gigabit Router
with USB
Power adapter
Step 1:
Unplug the power
to turn off your modem.
Internet
Step 4:
Connect the power adapter to the
router, then plug it into an outlet.
Wait until the wireless LED turns
solid blue.
Ethernet cable
If none of the LEDs light, make sure that
the Power On/Off button is in the on position
(pushed in).
Step 2:
Connect one end of the blue
Ethernet cable to your modem,
and the other end to the Internet port
on your router.
DSL
or Cable
N300 Wireless Gigabit
Router with USB
Modem
Step 5:
Connect the router
to your computer.
Use another Ethernet cable to establish
a wired connection as shown in this diagram.
Optionally, connect wirelessly by using the
preset wireless security settings
located on the product label.
Step 3:
Plug in, then turn on your modem.
Wait approximately two minutes
until your modem turns on.
If your modem has a battery backup,
first remove and reinsert the battery
before connecting your
modem to power.
Laptop or Desktop
Computer
(not included)
Step 6:
Open a browser.
If the web page does not display,
close and re-open the browser
and enter http://routerlogin.net
the address bar.
The user name and password
are on the product label.
in
