Crestron CNWM-LT9 Contents ® LiteTouch Keypad: CNWM-LT9 Description Functional Description Physical Description Leading Specifications Setup Network Wiring Keypad Installation Identity Code Programming with SIMPL™ Windows CNWM-LT9 Symbol How the Example Program Works Problem Solving Troubleshooting Further Inquiries Return and Warranty Policies... -
Page 5: Litetouch Keypad: Cnwm-Lt9
LiteTouch control stations. The CNWM-LT9 is a standard Crestron network (Cresnet) device and may be programmed using SIMPL™ Windows . The CNWM-LT9 is used instead of large banks of switches and/or dimmers and is designed for wall-mounting into a 1-gang electrical box (recommended 2.5” depth). The removable, magnetic faceplate of the keypad can be customized to match a home’s paint colors, wall... - Page 6 ® LiteTouch Keypad CNWM-LT9 Physical Views BUTTONS FRONT VIEW MAGNETIC FACEPLATE FRAME FACEPLATE ATTACHED TO BUTTON ASSEMBLY EXPANDED SIDE VIEW LiteTouch® Keypad: CNWM-LT9 LED 1 BUTTON LED 4 BUTTON LEDs 1-9 LED 7 BUTTON DEPTH = 1.15 in (2.92 cm)
-
Page 7: Leading Specifications
Crestron CNWM-LT9 Leading Specifications The table below provides a summary of leading specifications for the CNWM-LT9. Dimensions and weight are rounded to the nearest hundredth unit. Leading Specifications of the CNWM-LT9 SPECIFICATION Power Requirements Default Network ID SIMPL Windows CNMXS-AV/Pro Upgrade File CNRACKX/-DP Upgrade File Dimensions &... -
Page 8: Keypad Installation
If the unit is a home-run from a Crestron system power supply network port, the load factor of that unit is the load factor of the entire run. The length of the run in feet and the load factor of the run should be used in the following resistance equation to calculate the value on the right side of the equation. -
Page 9: Identity Code
ID of the keypad must match an ID code specified in the SIMPL Windows program. The NET ID of the CNWM-LT9 is factory set to 4D. The NET IDs of multiple keypads must all be unique and changed from a personal computer (PC) via VisionTools™ Pro-e (VT Pro-e) or SIMPL Windows. -
Page 10: Programming With Simpl™ Windows
Crestron control system. The next two sections describe a CNWM-LT9 within a SIMPL Windows program. The first section details the SIMPL symbol and the second section describes how an example program works by using a textual description and a block diagram. - Page 11 Crestron CNWM-LT9 The example SIMPL program for the CNWM-LT9 is shown below as a block diagram. Signal lamp 1 is sent to a toggle of a Crestron Electrical Control Interface (CNECI-4A) for lighting control and feedback (signal A) is provided to the CNWM-LT9. The press2 through press9 outputs are used for by similar equipment.
-
Page 12: Problem Solving
Further Inquiries If after reviewing this Operations & Installation Guide, you cannot locate specific information or have questions, please take advantage of Crestron's award winning technical support team by calling: In the US and Canada, call Crestron’s corporate headquarters at 1-888-CRESTRON [1-888-273-7876] or 1-201-767-3400. -
Page 13: Return And Warranty Policies
CRESTRON shall not be liable to honor warranty terms if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures.
