2.13 TECHNICAL SPECIFICATIONS
Accuracy:
2.13.3.1 AC CURRENT
Secondary Rated Current:
2
Frequency:
Consumption:
Maximum permissible current:
2.13.3.2 AC VOLTAGE
Secondary Rated Voltage:
Frequency:
Consumption:
Maximum permissible current:
2.13.3.3 DIGITAL INPUTS
Voltage Level:
Recognition Time:
2.13.4.1 LOW RANGE
Rated DC Voltage:
Min./Max. DC Voltage:
2.13.4.2 HIGH RANGE
Rated DC Voltage:
Min./Max. DC Voltage:
Rated AC Voltage:
Min./Max. AV Voltage:
Power Consumption:
Proper backup time (date, time and log
memory) without power supply voltage
2-22
±5% in the complete range
Terminals C1-C2. Rated current: 5A
50/60 Hz (selectable by setting)
< 0.2 VA at secondary In
100 In during 1 second
4 In continuously
VI, VII and VIII channels: 110/120 Vac.
Terminals C3-C4, C5-C6, C7-C8 50/60 Hz (C3-C4 in MIWII2000)
50/60 Hz (selectable by setting)
< 0.2 VA at 120V
440 Vac in permanence
300 Vdc maximum(for HI power supply)
75 Vdc maximun in permanence (for LO power supply)
< ¼ of cycle.
For pulse inputs: 1 cycle.
24 to 48 Vdc
19 / 58 Vdc
110 to 250 Vdc
88 / 300 Vdc
110 to 230 Vac @ 48-62 Hz
88 / 264 Vac @ 48-62 Hz
Max. = 10 W
> 1 week
MIWII Directional Power Protection System
2 PRODUCT DESCRIPTION

2.13.2 METERING FUNCTIONS

2.13.3 INPUTS

2.13.4 POWER SUPPLY

GEK-113308
