- Page 1 FIXED universal tv wall mount Support mural universel FIXE pour tv FIJO soporte de pared universal para tv Installation Manual Manuel d’installation Manual de instalación 70” 200x200 / 300x300 40kg 400x200 / 400x400 (88lbs) 600x400 RATED MC3770F...
-
Page 2: Des Questions
Questions? Please call us at 1-800-645-7750 or visit RCAAudioVideo.com DISCLAIMER Voxx Accessories Corp. has extended every effort to ensure to accuracy and completeness of this manual. However, Voxx Accessories Corp. does not claim that the information covers all installation or operational variables. The information contained in this document is subject to change without notice or obligation of any kind. - Page 3 Si le produit est endommagé ou que des fixations sont manquantes ou endommagées, n’installez pas le produit. Si vous avez besoin de pièces ou de quincaillerie de rechange, veuillez contacter le Service à la clientèle au 1-800-645-7750. Pour les clients internationaux, contactez le détaillant auprès duquel vous avez acheté le produit. La quincaillerie fournie est conçue pour servir sur des parois verticales en bois ou en béton massif.
- Page 4 Tools Required (Not Included) Outils nécessaires (non inclus) Herramientas requeridas (no incluidas) For drywall installation Pour une installation sur une cloison sèche Para la instalación en mampostería 4.5mm (3/16”) For solid wall installation Pour une installation sur un mur plein Para la instalación en pared maciza 10mm (3/8”)
-
Page 5: Package Contents
Package Contents Contenu de l’emballage / Contenido del embalaje TV Wall Mount Support mural pour TV Soporte de pared para TV Level Niveau Mounting Arms Nivel B (x2) Bras de montage Brazos de montaje Mounting Hardware Bags Sacs de matériel de montage / Bolsas de tornillería de montaje M-A (x4) M-C (x4) W-A (x5) - Page 6 Attach the mount arms to your TV Fixation des bras de montage au téléviseur Sujete los brazos de montaje a la TV IMPORTANT! Use extra care during this part of the installation. If possible, avoid placing your display facedown as it may damage the viewing surface. NOTE: This mount comes with a selection of different bolt diameters and lengths to accommodate a wide variety of display models.
- Page 7 Determine if you need to use spacers. If the back of your display is flat and the mounting holes are flush with the surface, you probably won’t need to use the spacers. If the back of your display is curved, has a protrusion, or if the mounting holes are recessed, you probably will need to use the spacers.
- Page 8 Installation on wood stud Installation sur un montant en bois Instalación en montante de madera Use a stud finder to locate two wood studs where you wish to install your mount. Mark both edges of each stud to help identify the exact center.
- Page 9 Place the base of the mount against the wall over the marked studs. Use the included bubble level (C) to make sure the base is level and mark where the four mounting screws will go. Placer la base du support contre le mur à l’endroit des montants marqués. Utiliser le niveau à bulle (C) fourni pour s’assurer que la base est de niveau et marquer l’emplacement des quatre vis de fixation.
- Page 10 Place the base against the wall over the pilot holes. Placer la base contre le mur sur les avant-trous. Coloque la base contra la pared sobre los orificios guía. 10mm Attach the wall mount base and arm to the wall using four of the mounting screws (W-A) and mounting washers (W-C) provided.
- Page 11 Installation on concrete Installation sur béton Instalación en hormigón IMPORTANT! For safety reasons, the concrete wall must be capable of supporting the combined weight of the mount and the display. The manufacturer takes no responsibility for failure caused by walls of insufficient strength. IMPORTANT! Pour des raisons de sécurité, le béton doit être capable de supporter le poids total du support et de l’écran.
- Page 12 65mm Drill five 10 mm (3/8”) holes in the wall 10mm (2.56”) where you marked, 2.56” deep. Remove (3/8”) any excess dust from the hole. Percer cinq trous de 10 mm (3/8 po) de diamètre et de 65 mm (2,56 po) de profondeur dans le mur aux emplacements marqués.
- Page 13 Place the wall plate against the wall over the inserted anchors and attach it using the mounting screws (W-A) and mounting washers (W-C) provided. Do not over-tighten these screws and do not release the wall plate until all screws are in place. Ensure that the wall plate remains level after the screws are secured.
- Page 14 Place your TV on the mount Placer le téléviseur sur la plaque murale Coloque la TV en el soporte With the help of another person, carefully lift your TV with mounting arms attached and place it on the wall plate. Do not release the display until the mounting arms have securely hooked onto the wall plate.
- Page 15 12-Month Limited Warranty Voxx Accessories Corporation (the “Company”) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company’s option) without charge for parts and repair labor.
- Page 16 MC3770F IB 02...
