Shark S3601W Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
WWW.SHARKCLEAN.COM
PRO
STEAM POCKET
MOP
®
S3601W
OWNER'S GUIDE

Advertisement

loading

Related Manuals for Shark S3601W

Summary of Contents for Shark S3601W

  • Page 1 WWW.SHARKCLEAN.COM STEAM POCKET ® S3601W OWNER’S GUIDE...
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS For Household Use Only WHEN USING YOUR SHARK ® Use the system only for its intended use. STEAM MOP, BASIC SAFETY 2. DO NOT use outdoors. PRECAUTIONS SHOULD 3. DO NOT leave the appliance ALWAYS BE FOLLOWED, unattended when plugged in.
  • Page 3 11. DO NOT unplug by pulling on 21. Extreme caution should be power cord. To unplug, grasp the exercised when using this plug not the power cord. Do not appliance to clean stairs. use extension cords or outlets 22. Never use steam mop without with inadequate current carrying micro-fiber cleaning pad attached.
  • Page 4 This manual covers model number: S3601W 11 TECHNICAL SPECIFICATIONS Voltage: 120V., 60Hz. Power: 1550 Watts Water Capacity: 500ml (16.9 oz.) TOLL FREE: 1-800-798-7398...

  • Page 5: Table Of Contents

    Contents Thank you for Getting Started ..............2 purchasing Using Your Steam Mop ............5 the Shark Using Your Carpet Glider ...........9 ® Steam Pocket ® Using the Accessories ............10 Mop. Care of Your Steam Mop ............11 Troubleshooting Guide ............13 Warranty ...................17...

  • Page 6: Getting Started

    When assembling your steam mop there may be a little water in or around the water tank. This is because we test all our steam mops 100% before you buy them, so you get a quality Shark ® Steam Pocket Mop.
  • Page 7 Phillips or a flat plugged into the wall. To prolong head screwdriver (screwdriver not the life of your Shark Pro Steam ® included). (fig. 1) Pocket Mop, we recommend using ®...
  • Page 8 Getting Started - cont’d fig. 2 fig. 4 fig. 5 fig. 3 IMPORTANT: Don’t use on unsealed Use the lavender loop on the side of wood or unglazed ceramic floors. the micro-fiber cleaning pad to slide On surfaces that have been treated mop head into pad pocket.

  • Page 9: Using Your Steam Mop

    If the light does not turn Visit www.sharkclean.com for other on, reference the troubleshooting great quick cleaning products to section on page 13. (fig. 7) complement your Steam Mop, such as the Shark Navigator™ ® (model NV350). www.sharkclean.com...
  • Page 10 Using Your Steam Mop - cont’d fig. 9 fig. 10 fig. 8 Press the ON/STANDBY button once Press the ON/STANDBY button for dust setting (DUST lighted setting a third time to activate the SCRUB indicator will illuminate). DUST setting setting. SCRUB setting is for heavy is light steam for a quick dusting and cleaning and will leave floors damp.

  • Page 11: The Shark

    The Shark Pro Steam Pocket Mop has three unique steam settings so ® ® you can use the perfect amount of steam for the cleaning task at hand. See below for tips on when to use each setting. Setting Ideal for These Surfaces...
  • Page 12 Using Your Steam Mop - cont’d fig. 11 NOTE: Please wait 2-3 minutes for When one side of the micro-fiber the Steam Mop to cool off before cleaning pad gets dirty, just flip the removing the mop head or the mop head and you can quickly start micro-fiber cleaning pad.

  • Page 13: Using Your Carpet Glider

    Using Your Carpet Glider The Steam Mop is great for grooming and freshening though it won’t clean your carpet or area rugs. fig. 12 fig. 13 THE CARPET GLIDER Move the steam mop back and The Carpet Glider can be used with forth across a section of the carpet.

  • Page 14: Using The Accessories

    Using the Accessories The Steam Concentrator is designed for use on floors only. Do not use on countertops, walls or other vertical surfaces. fig. 14 fig. 15 USING THE STEAM CONCENTRATOR Remove the mop head from the base. The Steam Concentrator nozzle will help loosen dirt and debris from Snap the Steam Concentrator nozzle crevices and tight areas that are...

  • Page 15: Mop. Care Of Your Steam Mop

    BLUE. This stops the unit Replace the water cap. (fig. 17) from steaming. Unplug the cord from To store the Shark Pro Steam ® the outlet and place the mop into the...
  • Page 16 To extend the life of your product from other fabrics to avoid picking we recommend that you use up lint. Only use liquid detergent distilled water or Shark ’s ® (no powder detergent). Don’t use Water Filtration Bottle.

  • Page 17: Troubleshooting Guide

    Troubleshooting Guide PROBLEM POSSIBLE REASONS & SOLUTIONS Your steam mop should be securely plugged into a The Pro Steam 120V AC electrical outlet only. Pocket Mop will ® Check your fuse or breaker. not turn-on. If your unit still does not work, call 1-800-798-7398. Is there water in the water tank? If not, add water to your steam The unit will not mop following instructions on page 4.
  • Page 18 Notes TOLL FREE: 1-800-798-7398...
  • Page 19 Notes www.sharkclean.com...
  • Page 20 Notes TOLL FREE: 1-800-798-7398...

  • Page 21: Warranty

    RETURN TO: EURO-PRO Operating LLC, 4400 Bois Franc, St. Laurent, Quebec H4S 1A7 PURCHASER: ……………………………………………………………………………………......……….... ADDRESS: ………………………………………………………………………………………………........... S3601W 11 DATE OF PURCHASE: …………………..….. MODEL: ………………............. NAME AND ADDRESS OF STORE: …………………………………......……………………………….. www.sharkclean.com...
  • Page 22 Newton, MA 02459 Canada: EURO-PRO Operating LLC 4400 Bois Franc Ville St. Laurent, Québec H4S 1A7 1-800-798-7398 www.sharkclean.com COPYRIGHT© EURO-PRO OPERATING LLC 2011 PRINTED IN CHINA S3601W.E.110415 Illustrations may differ from actual product. US Patent Nos. 7669280, 7600401, D611214, D626711, D599518, D599517...
