PowerDisc DVD Quick Start Guide
The PowerDisc DVD is a high performance
CD R one to one disc duplicator designed
for both the novice and professional user. The
PowerDisc DVD is designed for a variety of
applications that require the exchange of audio,
video or data content. The following is a Quick
Start Guide that outlines the menu commands
of the unit and immediate out-of-the box
functionality. For additional technical support
please call (952) 294-4900.

Installation and Setup:

1. Unpack the PowerDisc DVD and keep the external packaging for future storage and
transportation.
2. Place the PowerDisc DVD on a flat, clean and dust free surface. Check to confirm the
power switch on the front is "Off".
3. Connect the power cord from the back of the unit to an electrical outlet. Do not bypass
the Ground.
1. Copy Disc
a. Power on the systems by pressing the button on the lower right front of the unit. You will then
see the system initializing and performing a self test on the front panel LED. The LED will show
"System Check", and then switch to "1. Copy Disc" mode automatically
b. To begin the duplication operation, load the top drive (reader) with the master disc. Load the
lower drive (writer) with high quality DVD R media.
c. Press "OK" button to begin duplicating process. The system will automatically analyze the
master disc, and begin duplicating at the maximum recording speed.
d. LCD will display progress meter (see below) and eject the duplicated disc when completed.
Writing: MM:SS (Total disc length)
MM:SS (Actual progress)
e. To continue the same duplication job, reload the writer with blank DVD R media and system
will start duplicating process automatically again. To start a new job, replace the original
master with a new master disc and follow steps b. to d. above.
2. Test Copy Disc
a. The "Test Copy Disc" function performs the same operation as "Copy" except that the data is
not actually written onto the DVD R media. DVD R disc will remain blank when this operation is
performed. This operation is used to confirm the status of the target Master Disc. It is also used
to test the system during setup or after being transported.
Functions
UP OK
Down Cancel
