PD1631
PD1631T
Pen Display
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website.
Model No. VS18289
P/N: PD1631 | PD1631T
Advertisement
Table of Contents
Related Manuals for ViewSonic VS18289
Summary of Contents for ViewSonic VS18289
- Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
- Page 2 As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.
-
Page 3: Safety Precautions
• Do not place any heavy objects on the device or connection cables. • If smoke, an abnormal noise, or a strange odor is present, immediately turn the device off and call your dealer or ViewSonic®. It is dangerous to continue using the device. -
Page 4: Table Of Contents
Contents Safety Precautions ............3 Introduction ..............6 Package Contents ....................6 Product Overview ....................7 Initial Setup ..............8 Making Connections ............ 9 Installing Drivers and Software ................9 Pen Display Driver ....................9 Connecting to Power ....................10 Connecting External Devices ................11 HDMI Connection .................... - Page 5 Appendix ..............27 Specifications ......................27 Pen ........................28 Product Dimensions .....................29 Troubleshooting ....................30 Pen ........................30 Maintenance......................31 General Precautions ....................31 Cleaning the Screen ....................31 Cleaning the Case ....................31 Replacing a Pen Nib ....................32 Regulatory and Service Information ......33 Compliance Information ..................33 FCC Compliance Statement ...................
-
Page 6: Introduction
Introduction Package Contents Replacement Pen Pen Display HDMI cable (1.5 m) nib x 3 AC/DC Power Power Cord Nib removal tool USB Cable (1.8 m) Adapter PD1631T Pen Display Quick Start Guide Przewodnik Szybki start Guia de Início Rápido クイックスタートガイド Aan de slag Pika-aloitusopas Guía de inicio rápido... -
Page 7: Product Overview
Product Overview Front View Display Screen Rear View Wall Mounting Points Security Lock Slot Adjustable Stand LINE HDMI DC IN Audio In Audio Out 6. USB Upstream HDMI For more information about the 1/2/ key and its functions, refer to “Hot Keys” ▲... -
Page 8: Initial Setup
Refer to the table below for the standard dimensions for wall mount kits. NOTE: For use only with a UL certified wall mount kit/bracket. To obtain a wall- mounting kit or height adjustment base, contact ViewSonic® or your local dealer. -
Page 9: Making Connections
The software can be downloaded at: http://www.viewsonicglobal.com/q/PD1631 Pen Display Driver 1. Open the ViewSign Console installation file and install the driver. 2. After the installation completes, you will need to restart the computer. NOTE: For further ViewSign Console information, please visit: https://manuals.viewsonic.com/ViewSign_Software... -
Page 10: Connecting To Power
Connecting to Power 1. Connect the power cord to the power adapter. 2. Connect the power adapter to the DC IN jack at the rear of the display. 3. Connect the power cord to a power outlet. 10 10... -
Page 11: Connecting External Devices
Connecting External Devices HDMI Connection Connect one end of an HDMI cable to the HDMI port of the display. Then connect the other end of the cable to the HDMI port of your computer. HDMI HDMI... -
Page 12: Audio Connection
Audio Connection Plug an audio cable into the Audio In/Audio Out port of the display. Plug the other end into your computer (Audio In) or ear-/headphones (Audio Out). NOTE: The display is also equipped with dual speakers. LINE... -
Page 13: Vga Connection
VGA Connection Connect one end of a VGA cable to the VGA port of the display. Then connect the other end of the cable to the VGA port of your computer. -
Page 14: Usb Connection
USB Connection Connect one end of a USB cable to the USB port of the display. Then connect the other end of the cable to a USB port of your computer. NOTE: The display supports one (1) type of USB port. When making the connection, observe the following guideline: •... -
Page 15: Touch Function Control
Touch Function Control (PD1631T only) Before using the touch function, ensure the USB Type B to Type A cable is connected to your computer and the Windows operating system is running. When using the touch function, please note: • The touch function may need about five (5) seconds to resume if the USB cable is removed and plugged in again, or the computer resumes from Sleep Mode. -
Page 16: Using The Pen Display
Using the Pen Display Adjusting the Viewing Angle Tilt Angle Adjustment Tilt the monitor stand forwards or backwards to the desired viewing angle (0˚/42˚ to 80˚). -
Page 17: Turning The Device On/Off
Turning the Device On/Off 1. Plug the power cord into a power outlet. 2. Press the Power key to turn on the display. 3. To turn the display off, press the Power key again. NOTE: The display will still consume some power as long as the power cord is connected to the power outlet. -
Page 18: On-Screen Display (Osd) Menu
Select one of the preset color settings. Displays the timing mode coming from the graphics card in the computer, the LCD model Information number, the serial number, and the ViewSonic® website URL. Manually set a variety of image quality Manual Image Adjust adjustments. -
Page 19: Hot Keys
Hot Keys When the On-Screen Display (OSD) Menu is off, you can quickly access special functions by using the control panel keys. Description Press and hold the keys to lock/unlock the OSD Menu. When the menu appears on the screen, continue holding both keys for 10 seconds to lock/unlock the OSD Menu. - Page 20 Description Press the keys to toggle between DDC/CI and DDC/2B NOTE: DDC/CI is the default setting. Press the key to enter ViewMode. Press the key to activate the Blue Light Filter. Press the key to toggle between input sources.
-
Page 21: Configuring The Settings
Configuring the Settings General Operations 1. Press the 1 key to display the On-Screen Display (OSD) Menu. A U T O I M A G E A D J U S T A S T / B R I G H T N E S S L E C T J U S T J U S T... - Page 22 3. Press the ‚ or key to select the desired menu option. Then press the 2 key to enter the sub-menu. M A N U A L I M A G E A D J U S T E C O M O D E S T A N D A R D O P T I M I Z E C O N S E R V E...
-
Page 23: On-Screen Display (Osd) Menu Tree
On-Screen Display (OSD) Menu Tree Main Menu Sub-menu Menu Option Auto Image Adjust Contrast/Brightness Contrast (-/+, 0~100) Brightness (-/+, 0~100) Input Select D-SUB HDMI Audio Adjust Volume (-/+, 0~100) Mute HDMI Audio Input Audio In Color Adjust sRGB Bluish Cool Native Warm (-/+, 0~100) - Page 24 Main Menu Sub-menu Menu Option Setup Menu Language Select English Français Deutsch Español Italiano Suomi Русский Türkçe 日本語 한국어 繁體中文 简体中文 Česká Svenska Resolution Notice H. Position (-/+, 0~100) OSD Position V. Position (-/+, 0~100) OSD Timeout (-/+, 5/15/30/60) Background Auto Power Off Sleep 30 Minutes...
-
Page 25: Pen Input Area Mapping
Pen Input Area Mapping To set the proper pen input area, 1. Open Pen Display Manager either by going to: Start > Pen Display Manager or selecting the Pen Display Manager icon from the System Tray. Additionally, the driver can also be accessed from ViewSign Console - either the widget or by right-clicking the ViewSign Console icon in the system tray and selecting Pen Display Driver. - Page 26 4. Further adjustments can be made by selecting the Pen tab.
-
Page 27: Appendix
Appendix Specifications Item Category Specifications Type a-si, TFT Active Matrix 1920 x 1080 LCD, 0.17925 mm x 0.17925 mm pixel pitch Display Size 40.6 cm, 16” (15.6” viewable) Surface Treatment Anti-Glare type (Haze 25%), Hard-coating (3H) Input Signal Video Sync RGB Analog (75 Ω) VGA: f :30-61 kHz, f... -
Page 28: Pen
Do not set the graphics card in your computer to exceed these timing modes; doing so may result in permanent damage to the display. ² For PD1631T only. Please use the power adapter from ViewSonic® or an authorized source only. Item Specifications Model... -
Page 29: Product Dimensions
Product Dimensions 39.05 mm 379.24 mm 248.61 mm 9.2 mm 129.95 mm... -
Page 30: Troubleshooting
Troubleshooting This section describes some common problems that you may experience when using the monitor. Problem or Issue Possible Solutions • Ensure the display is connected properly.. • Try another port on the computer. No picture on the • Ensure the computer is powered on. display •... -
Page 31: Maintenance
• ViewSonic® does not recommend the use of any ammonia or alcohol-based cleaners on the display screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the monitor. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. -
Page 32: Replacing A Pen Nib
Replacing a Pen Nib When the pen nib gets too short or develops a sharp edge, it can be replaced with spare nibs. To replace a pen nib: 1. Use the nib removal tool to pull the old nib straight out of the pen. 2. -
Page 33: Regulatory And Service Information
Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 34: Declaration Of Rohs2 Compliance
The following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law. -
Page 35: Indian Restriction Of Hazardous Substances
Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®... -
Page 36: Copyright Information
ENERGY STAR® is a registered trademark of the U.S. Environmental Protection Agency (EPA). Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 37: Customer Service
For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia www.viewsonic.com/au/ Bangladesh www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn www.viewsonic.com/hk/ 香港 (繁體中文) Hong Kong (English) www.viewsonic.com/hk-en/ India www.viewsonic.com/in/... -
Page 38: Limited Warranty
“What the warranty excludes and does not cover” section). How long the warranty is effective: ViewSonic® displays are warranted for between 1 and 3 years, depending on your country of purchase, for all parts including the light source and for all labor from the date of the first consumer purchase. - Page 39 (e) the serial number of the product. • Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. • For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warranties:...
- Page 40 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of...
-
Page 41: Mexico Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &... - Page 42 Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages...
- Page 43 Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Distribuciones y Servicios Computacionales SA de CV.
- Page 44 C0 M91 Y72 K24 Process Color C0 M0 Y0 K100 Process Color C0 M91 Y72 K24 Process Color Pantone Black C Spot Color Pantone 187 C Spot Color...
