ASME A112.18.1 / CSA B125.1
ASME A112.18.2 / CSA B125.2
ICC/ANSI A117.1
Model/Modelo/Modèle
35996LF
Series/Series/Seria
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
For easy installation of your Delta
faucet you will need:
To READ ALL the instructions completely
before beginning.
To READ ALL warnings, care, and maintenance
information.
To purchase the correct water supply hook-up.
Para instalación fácil de su llave Delta
usted necesitará:
LEER TODAS las instrucciones completamente
antes de empezar.
LEER TODOS los avisos, cuidados, e
información de mantenimiento.
Comprar las conexiones correctas para el
suministro de agua.
Pour installer votre robinet Delta
facilement, vous devez:
LIRE TOUTES les instructions avant de
débuter;
LIRE TOUS les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
Acheter le bon nécessaire de raccordement.
59630
TWO HANDLE WIDESPREAD LAVATORY FAUCET
LLAVE DE LAVAMANOS EXTENDIDAS DE DOS
MANIJAS
ROBINETÀENTRAXELONGÀDEUXPOIGNÉES
POURLAVABO
You may need/Usted puede necesitar/
Articles dont vous pouvez avoir besoin:
59630
1
?
11/30/10 Rev. E
Advertisement
Related Manuals for Delta 35996LF
Summary of Contents for Delta 35996LF
- Page 1 To READ ALL warnings, care, and maintenance information. To purchase the correct water supply hook-up. Para instalación fácil de su llave Delta usted necesitará: LEER TODAS las instrucciones completamente antes de empezar. LEER TODOS los avisos, cuidados, e información de mantenimiento.
- Page 2 If your faucet code is 413763 in page 7. Secure end valves with gaskets (1), washers (2) & threaded brackets (3). Shut Off Water Supplies - Remove old faucet. Slide hot and cold end Hand tighten brackets (3) onto shank (4). Lock brackets into position by valves (1) with gaskets (2) through sink mounting holes.
- Page 3 If your faucet code is 449918 in page 7. Shut Off Water Supplies - Remove old faucet. Slide hot and cold end Secure end valves with gaskets (1), washers (2) & threaded brackets (3). valves (1) with gaskets (2) through sink mounting holes. Note: If sink is Hand tighten brackets (3) onto shank (4).
- Page 4 Pop-Up Installation Remove stopper (1) and flange (2). Screw nut (3) all the way down. Apply silicone to underside of flange (1). Insert body (2) into sink. Screw Push black gasket (4) down. flange onto body. Pivot hole (3) must face back of sink. Tighten nut/gasket, clean excess silicone.
- Page 5 FLUSH SYSTEM/CHECK FOR LEAKS. CONNECT TO WATER SUPPLIES. Remove aerator(1) and turn faucet handles (2) all theway on. (HOOK-UPS NOTPROVIDED). Turn on hot and cold water supplies and flush water lines for one minute. Check for leaks at arrows. Replace aerator. DEJE CORRER EL AGUA POR EL SISTEMA/ EXAMINE POR SI HAY FILTRACIONES.
- Page 6 If faucet exhibits very low flow: Maintenance A. Remove and clean Aerator (3) (page 7), or SHUT OFF WATER SUPPLIES B. Clean Seats and Springs (2) of any debris When replacing a parts, follow the illustrated instructions * Install stems (1) correctly for proper handle rotation: provided on the back of the Repair Part Kit.
- Page 7 RP41679 Specify Finish Hot & Cold Lever Handles Especifíque el Acabado w/Buttons & Screws Précisez le Fini Manijas en Palanca con Botones y Tornillos de agua fría y caliente Manettes-leviers d’eau chaude et d’eau froide avec boutons et vis RP35746 The faucet code is found on the Lift Rod back of the spout .
-
Page 8: Cleaning And Care
MAKE ANY OTHER WARRANTY OF ANY KIND, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY. Delta will replace, FREE OF CHARGE, during the warranty period, any part or finish that proves defective in material and/or workmanship under normal installation, use & service. Replacement This warranty excludes all industrial, commercial &...
