Husky 31748 Installation Instructions Manual

"KIT, SERVICE, HUSKY 10-16K,
PASSENGER SIDE HOUSING AND RAIL
ASSEMBLY.
Dealer / Installer: Provide a copy of these Instructions to the end user of this product.
These Instructions provide important operating and safety information
for proper usage of this product. Demonstrate the proper use of the
product with the end user. Have the end user demonstrate that they
understand the proper use of the product.
End User: Read and follow all instructions included in this manual. Ask your
Dealer / Installer for assistance if you do not understand the proper use
of the product. Never remove any decals from the product.
APPLICATION: For use on short bed pickup applications no less than 6-1/2 feet long.
NOTE : The "HUSKY 10-16K" is to be used only with 5th wheel trailers which weigh 16,000 lbs. or
less. Never use with heavier trailers. You will need to disassemble the uprights from your current
5th wheel to install the "HUSKY 10-16K". The "HUSKY 10-16K" takes the place of those uprights.
Caution:
The "HUSKY 10-16K" will reposition your 5th wheel 10" rearward. HOWEVER
this will NOT guarantee complete truck cab/trailer clearance when towing & making sharp
turns. See page 2, "Truck Cab and 5th Wheel Trailer Clearance".
Husky Fastener Torque Specification
All "Husky 10" fasteners are grade 5
See www.huskytow.com
Installation Instructions
All Products limited to Vehicle Tow Rating; see Vehicle Owners Manual
for Warranty Information / Tech Support ©2012 Husky Towing Products
Revision: February 12, 2013-REV 1
Page 1 of 11
Patent Pending
TOOLS REQUIRED:
DRILL*
5/8" DRILL BIT*
NEEDLE NOSE PLIERS
7/16" WRENCH & SOCKET
9/16" WRENCH & SOCKET
16mm WRENCH
3/4" WRENCH & SOCKET
TORQUE WRENCH (150 LBS.-FT. MIN.)
*These tools only required if you do not have
a center bolt kit installed in your base rails.
The "HUSKY 10-16K" will only work
in the base rail slots spaced 20-5/8"
apart. Only use Husky 5th Wheel
Hitches with this product.
Part # 31748
