- Page 1 S-MOVER Stage Mover™ Chauvet, 3000 N 29 USER MANUAL Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com Snapshot Ok on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Duty Cycle...
-
Page 2: Table Of Contents
ABLE OF ONTENTS 1. BEFORE YOU BEGIN... 3 ... 3 HAT IS INCLUDED ... 3 NPACKING NSTRUCTIONS AC P ... 3 OWER ... 3 ONTACT ... 4 AFETY NSTRUCTIONS 2. INTRODUCTION ... 5 ... 5 EATURES DMX C ... 5 HANNEL UMMARY ... -
Page 3: Before You Begin
Earth Ground. Contact Us W o r l d W i d e General Information Technical Support World Wide Web Stage Mover Manual EGIN Chauvet Lighting 3000 North 29 Court Hollywood, FL 33020 voice: 954.929.1115 fax: 954.929.5560 toll free: 800.762.1084... -
Page 4: Safety Instructions
The protective screen should always be installed. Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. Stage Mover Manual 2007-04-13/09:39... -
Page 5: Introduction
2. I NTRODUCTION Features • 8-channel DMX-512 stage mover • Pan: 540° / tilt: 270° • Variable electronic dimmer (0 – 100%) • Remote fixture reset, lamp on/off & vector speed channel Ad d i t i o n a l F e a t u r e s •... -
Page 6: Product Overview
Product Overview Head Yoke Control Panel Voltage Selector Switch AC Power Input & Fuse Holder Stage Mover Manual Housing & Protective Screen Carrying Handle Base Rear of Base DMX Input Connector DMX Output Connector 2007-04-13/09:39... -
Page 7: Setup
3. S ETUP Lamp Optional 500W or 1000W lamps may be purchased from any Chauvet dealer. Warning! When replacing the lamp, please wait 15 minutes after powering down to allow the unit to cool down! Always disconnect from main power prior to lamp replacement. -
Page 8: Fixture Linking
Maximum recommended number of fixtures on a serial data link: 32 fixtures Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET-certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 9: 3-Pin To 5-Pin Conversion Chart
If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter. Note! CHAUVET Model No: DMX5M, or DMX5F. The chart below details a proper cable conversion: IN TO... -
Page 10: Mounting
Mounting ORIENTATION This fixture may be mounted in any position provided there is adequate room for ventilation. R IG G IN G It is important never to obstruct the fan or vents pathway. Mount the fixture using, a suitable “C” or “O” type clamp. Adjust the angle of the fixture by loosening both knobs and tilting the fixture. -
Page 11: Menu Map
Menu Map enu Functions PTION ESCRIPTION DMX: The fixture will be controlled by a DMX signal coming from a DMX controller. The starting addr buttons. Stand Alone – Automatic: The built in programs will trigger automatically to a pre- programmed speed time. Sound Active –... -
Page 12: To Set The Tilt To Inverting Or Non-Inverting
T O SET THE T I LT TO I N V ERTING OR NON- IN VERTING: Press <MODE/ESC> until Use the <UP> and <DOWN> buttons to scroll through the two o inverting; T O R EV ER S E T H E D IS P L A Y: Press <MO DE/ESC>... -
Page 13: Master/Slave Mode (Master Sound, Master Auto)
Master/Slave Mode (Master Sound, Master Auto): This mode will allow you to link up to 32 units together without a controller. Use standard DMX cables to daisy chain your units together via the DMX connector on the rear of the units. For longer cable runs we suggest a terminator at the last fixture. For more information about terminators, see page 8. -
Page 14: General Troubleshooting
Remote does not work Make sure connector is firmly connected to device Stand alone mode All Chauvet lighting fixtures featuring stand-alone functions do not require additional settings, simply power the fixture and it will automatically enter into this mode Stage Mover Manual... -
Page 15: Technical Support
XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’) -
Page 16: General Maintenance
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 17: Technical Specifications
Data output ... locking 3-pin XLR female socket Data pin configuration ...pin 1 shield, pin 2 (-), pin 3 (+) Protocols... DMX-512 USITT DMX Channels ...8 ORDERING INFORMATION Stage Mover ... S-MOVER WARRANTY INFORMATION Warranty ... 2-year limited warranty Stage Mover Manual 2007-04-13/09:39...
