Cateye AMPP200 Manual

RECHARGEABLE HEADLIGHT
HL-EL042RC
Before using the light, read this manual thoroughly and keep
it for future reference. Do not use the light in any way other
than as described in this manual.
Design Pat. Pending
Copyright© 2021 CATEYE Co., Ltd.
1
HLEL042RC-210305
Included Items
Light unit + Rubber band
(AMPP200)
WARNING!!!
(Risk of death; Prevention of accidents)
• Do not look directly at the light source. In addition, when mounting the
light unit, ensure that the light will not dazzle other road users.
• Before riding, make sure the light unit is securely attached to the handlebar
and that the light turns on. Do not use a damaged rubber band.
• Always attention to the remaining battery power by checking the indicator
periodically while using.
• Do not disassemble or modify the light or any of the included items.
CAUTION!
(Prevention of injury, damage, or property damage)
• Operating the light while riding is dangerous. Always ride safely.
• Note that the light becomes hot while illuminated. Do not block the lens or
cover the light.
• Do not place it within children' s reach.
• Carrying a spare headlight is recommended in case the battery runs out.
• When used with a cyclocomputer, attach the headlight as far away from
the cyclocomputer as possible, as it may affect measurement.
• This device is rated IPX4 based on JIS C0920. Do not immerse the device
in water. Doing so may cause a malfunction. Wipe off any moisture after
using the device in rainy weather.
• Do not subject the light to strong vibrations, impacts, or excessive force.
Discontinue use if any abnormality occurs.
• Do not charge the battery in any way or at any voltage other than that
specified. Do not short-circuit the battery.
• Do not drop the light into a fire or heat the light.
• If the light unit or parts become dirty with mud, etc., clean with a soft cloth
which is moistened with mild soap. Never apply paint thinner, benzine or
alcohol; damage will result.
LITHIUM-ION BATTERIES
Recharge the battery for first time use or after long period of storage:
The voltage of the battery may drop due to self-discharge during long
period of storage. Always fully charge the battery before use.
Cautions for charging and usage:
• Using a PC or USB battery charger with an output current of 500 mA or
more is recommended for charging.
• Be sure that no dust or other foreign objects are attached to the plug of
the USB cable before charging.
• Do not subject the light to vibrations while charging.
• When your PC is in sleep state, the unit cannot be charged.
• Once charging is completed, be sure to disconnect the USB cable from
the charging port.
• Charging and lighting times are approximate values, and will vary by
environmental and user conditions.
• Charging, discharging, and storing in high temperatures will cause the
rechargeable battery to deteriorate faster. Do not place the light inside a
vehicle or near a heater. Make sure to charge only when the ambient
temperature is between 41˚F and 104˚F (5°C and 40°C).
• If the illumination time is significantly reduced even after proper charging,
the rechargeable battery may be nearing the end of its service life.
Cautions on storage:
• If the device will not be used for a long period of time, store it in a
location that is not too hot or too humid.
• Charge the battery for about 30 minutes every 6 months.
Cautions for dispose:
When disposing the light unit, please do so in accordance with your
local regulations.
ENG
Manual
USB cable
(MICRO USB)
1
CHARGING / SWITCH OPERATION
USB cable
To PC or USB
Charging port cover
battery charger
Switching the lighting mode
OFF
Press and hold Press and hold
Flashing Flashing
CAUTION!:
• Always charge the product before use.
• Once charging is completed, securely close the charging port cover.
*1: When turning the light on, it lights up in the mode that was used the last time.
(Mode memory function)
Remaining battery capacity:
If the switch (indicator) turns red, charge the product as soon as possible.
2
HOW TO MOUNT TO A BICYCLE
Ø22 – 35 mm
Fold back
1
Rubber band
*2
360°
1
Turn the light unit 90 degrees (perpendicular to rubber band), and attach the headlight to
the handlebar.
2
Pull the rubber band tight and secure it to the hook on the bracket spacer so that the light
unit is not loose.
3
Turn the light unit back toward the direction of travel.
*2: The light unit can be turned 360 degrees.
*3: When mounting the light unit, ensure that the light will not dazzle other road users.
Switch (Indicator)
Charging
* A flashing light indicates a charging error.
Remove the USB cable and try again.
Standard charging time
Approx.
ON
*1
Press and hold
High High
Double-click Click
Click
Low Low
2
3
Bracket spacer (hook)
*3
Adjusting the lighting angle
Charging is completed
2.5 h
(0.5A)
NO!
OK
