D D M M X X S S t t r r o o b b e e A A d d a a p p t t e e r r
DMX-752
User Guide
Please read these instructions carefully befor use
World-wide Headquarters:
3000 North 29th Ct., Hollywood, Florida, USA, FL 33020
Tel: +1-954-929-1115 Fax: +1-954-929-5560
www.ChauvetLighting.com
Advertisement
Related Manuals for Chauvet DMX-752
Summary of Contents for Chauvet DMX-752
-
Page 1: User Guide
D D M M X X S S t t r r o o b b e e A A d d a a p p t t e e r r DMX-752 User Guide Please read these instructions carefully befor use World-wide Headquarters: 3000 North 29th Ct., Hollywood, Florida, USA, FL 33020... - Page 2 DMX Operation The DMX-752 is a single channel unit. To use the DMX-752 in DMX mode, switch # 9 must be in the OFF position. To set the address on the relay pack, you must check to verify the bank assignment utilized by your controller (ie. The Chauvet DMX 40 banks all fixtures in 16 channel intervals and the CX5 in 14 channel intervals.
-
Page 3: Specifications
= Sound Activated Stand Alone Mode In stand alone mode the DMX-752 allows the user the choice of either sound activation or the choice of flash rates. SW 8 and SW 9 ON - Sound Activation SW 1 and SW 9 ON - .7 Flash per Second (FPS)
