Dell S500/S500wi
Firmware Upgrade
Setup Guide
Released date: Oct 2015 Rev.D


Advertisement

loading

Related Manuals for Dell S500

Summary of Contents for Dell S500

  • Page 1 Dell S500/S500wi Firmware Upgrade Setup Guide Released date: Oct 2015 Rev.D  ...

  • Page 2: Table Of Contents

    Part A: Install the Dell Flasher Tool on Your Computer ..........2 Part B: Install the USB driver on Your Computer ............. 3 Part C: Launch the Dell Flasher Tool to Upgrade Projector Firmware ...... 4 2. Wireless Firmware Upgrade Setup ................ 7 Part A: Enable Wireless or LAN on the Projector .............

  • Page 3: Projector Firmware Upgrade Setup

    1. Projector Firmware Upgrade Setup NOTE: Projector firmware upgrades set are the same for the S500 and S500wi models. Part A: Install the Dell Flasher Tool on Your Computer 1. Please follow your computer operating system to select flasher version.

  • Page 4: Part B: Install The Usb Driver On Your Computer

    Part B: Install the USB driver on Your Computer 4. Plug in the power cord and perform following steps to enter download mode. NOTE: Please DON’T press power button to turn on the projector when entering download mode. Step A: Press the Menu button and hold it. Step B: Continuously hold the Menu button and press the Power button simultaneously.

  • Page 5: Part C: Launch The Dell Flasher Tool To Upgrade Projector Firmware

    Part C: Launch the Dell Flasher Tool to Upgrade Projector Firmware NOTE: Please keep the projector in download mode as step 4. 6. Execute the Dell Flasher: StartAll ProgramDell Flasher 2.0Flasher 7. Dell Flasher is executing and please check USB status is Connected before upgrade firmware. 4 ...
  • Page 6 NOTE: If Window 7/8/8.1 32-bit or 64-bit OS pop-up this diagram, please click Install. Windows XP does not pop-up this diagram. NOTE: You only need to install the “Jungo driver” once. 8. Follow these steps to upgrade firmware: Step A: Click “Browse” to find the firmware (*.img) from downloaded Projector FW folder. Step B: Click “DownLoad”...
  • Page 7 9. Unplug and re-plug in the power cord to turn on S500 or S500wi projector. NOTE: If you have installed Dell Flasher Tool once, you may skip step 1~ 3, and only proceed step 4~9 afterward to upgrade the projector firmware.

  • Page 8: Wireless Firmware Upgrade Setup

    Wireless/LAN Settings → Wireless Settings → Wireless → Connected. Go to Step 5. NOTE: If your want to use the wireless connection for S500 projector, need to installed the optional wireless dongle. The wireless dongle is not shipped with your S500 projector.

  • Page 9: Part B: Connect Your Computer To The Projector And Login Web Management

    Part B: Connect Your Computer to the Projector and Login Web Management 4. If you select the LAN cable for upgrade, connect the LAN cable to the projector and the computer. 5. If you select the Wireless connection for upgrade, connect your computer to the S500 or S500wi wireless network. NOTE: ...

  • Page 10: Part C: Upgrade Wireless Firmware

    Part C: Upgrade Wireless Firmware 7. The S500 or S500wi web management page opens. Click Admin. 8. Enter the administrator password (default password is admin), then click Login. 9. Click Firmware Upgrade. 10. Follow these steps to upgrade firmware: Step A: Click “Browse” to first find the firmware (*.img) from downloaded Wireless FW folder.
  • Page 11 Step B: Click “Update” to start the upgrade firmware (*.img). B  Step C: Download and upgrade firmware (*.img). Step D: Firmware (*.img) completed, click “OK”. 10 ...
