Chauvet Ch-160 User Manual

Package Contains:
1 x Duo Moons
2 x BRL Bulbs
1 x
1 x Colored Moonflower
Troubleshooting
• If the unit is not functional – check main power supply is 'on' and check fuses.
• If the unit is functional but lamp does not light - lamp may require replacing.
• If the unit is not moving to the music check the sound-activation adjustment (when applicable)
• If after trying this solution you still have a problem contact your dealer or CHAUVET.
Contact Chauvet
USA
Tecnical Assistance: 1-800-762-1084 (954) 929-1115
E-Mail tech@chauvetlighting.com
Europe
Technical Assistance: (0113) 276-0755
E-Mail eurosales@chauvetlighting.com
Caution
Do not obstruct the air vents.
Do not touch unit or lamps while hot.
Never put any objects through the air grill on the top of the unit.
No user serviceable parts inside, please refer to CHAUVET for service.
Power Connections
The unit is supplied with a power plug appropriate to its voltage and destination. Should any other
connections be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.
Technical Specifications
Power
120V~60Hz AC
Fuse
20mm Glass 1A Fast Blow
2 x 12V 50W
Lamps
Part No BRL 12V 50W
Dimensions
279 x 279 x 160mm / 11 x 11 x 6.3in
Weight
5kg / 11lbs
User Informtion
(Please complete for your records)
Date Purchased: / /
Dealer Stamp
White Moonflower
230V~50Hz AC
20mm Glass 0.5A Fast Blow
2 x 12V 50W
Part No BRL 12V 50W
279 x 279 x 160mm / 11 x 11 x 6.3in
5kg / 11lbs
Serial No: ________________
Model: CH-160 DUO MOONS
D D u u o o M M o o o o n n s s
CH-160
User Guide
Please read these instructions carefully befor use
World-wide Headquarters:
3000 North 29th Ct., Hollywood, Florida, USA, FL 33020
Tel: +1-954-929-1115 Fax: +1-954-929-5560
European Office:
Unit 18, Hunslet Trading Estate, Leeds, UK
LS10 1BL
Tel: (0113) 276-0755 Fax: (0113) 277-6675
www.ChauvetLighting.com
