Page 1
• Connect to suitable USB source providing 5V D.C, 2A (10W). (USB Adaptor not included) • Light termperature: 3000K - 5000K *Ring light is 10” high as measured from mounting point to top of the ring. Think, create, innovate! CVL10TK...
Page 2
1 X 10" RING LIGHT 1 X CAMERA MOUNT BRIGHTNESS + LIGHTING MODE REMOTE BRIGHTNESS - USB CABLE SWITCH ON/OFF STABILISING BARS ASSEMBLY Assembly of the 10" Ring Light Kit is broken down into 4 sections: Tripod, ring light, phone mount and camera mount. SECTION 1: TRIPOD 1.
Page 3
SECTION 2: RING LIGHT 1. Remove the assembled ring light from packaging. 2. Loosen the bottom adjustment screw on the ring light, then attach mount to top of tripod. Tighten the adjustment screw until the ring mount is secure (Fig. 2). 3.
Page 4
SECTION 3: PHONE MOUNT 1. Screw the phone mount into the hole on the base of the ring light so that it is secure. 2. Attach the phone bracket onto the mount either in portrait or landscape position. Pull spring-loaded side of phone mount and insert your smart phone (Fig. 2). You may need to remove your phone case for secure insertion into phone mount.
