Operating Instructions
Installation Instructions provided
HD Integrated Camera
AW‑HE42WP
Model No.
AW‑HE42KP
Model No.
AW‑HE42WE
Model No.
AW‑HE42KE
Model No.
Excerpted Version
ENGLISH
DVQX1917ZA
Advertisement
Table of Contents
Related Manuals for Panasonic AW‑HE42WP
Summary of Contents for Panasonic AW‑HE42WP
- Page 1 Operating Instructions. Avant d’installer et d’utiliser cet appareil, s’assurer de lire la section « Lire ces informations en premier ! » (pages 5, 35 à 39). Pour de plus amples informations, visiter le site Web de Panasonic (https://pro-av.panasonic.net/manual/en/index. FRANÇAIS html) et consulter le mode d’emploi et les instructions d’installation.
- Page 2 σας, επισκεφτείτε τον ιστότοπο που ακολουθεί. Besök följande webbplats för säkerhetsinformation Svenska och viktiga meddelanden om produkten. A termékkel kapcsolatos biztonsági információkért és fontos értesítésekért látogasson el az alábbi Magyar weboldalra. زر ﻣوﻗﻊ اﻟوﯾب اﻟﺗﺎﻟﻲ ﻟﻣﻌرﻓﺔ أﺣدث ﻣﻌﻠوﻣﺎت اﻟﺳﻼﻣﺔ واﻹﺧطﺎرات اﻟﻌرﺑﯾﺔ .اﻟﮭﺎﻣﺔ ﺑﺷﺄن اﻟﻣﻧﺗﺞ https://pro-av.panasonic.net/manual/en/index.html...
- Page 3 [Maintenance]” → “Product information tab [Product info.]” → “OSS license display” is performed. At least three (3) years from delivery of this product, Panasonic will give to any third party who contacts us at the contact information provided below, for a charge no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under GPL V2.0 or...
-
Page 4: Table Of Contents
Contents Installation Instructions Read this first! Connections Lire ces informations en premier ! Connecting an NDI|HX compatible switcher Connecting a controller (AW-RP50) (IP connection Lea esto primero example) Bitte lesen Sie zuerst diesen Hinweis! System example 1 (connection with commercially Leggere prima quanto segue! available controller, RS-232C daisy-chain connection) -
Page 5: Installation Instructions
To prevent injury, this apparatus must be securely This camera intended for use only with the Mount attached to the floor/wall in accordance with the Bracket enclosed with the unit and Panasonic Direct installation instructions. Ceiling Mount Bracket, WV-Q105A. Use with other apparatus is capable of resulting in instability causing possible injury. -
Page 6: Bitte Lesen Sie Zuerst Diesen Hinweis
Данная камера предназначена для использования быть надежно закреплен на полу/стене в соответствии с только с монтажным кронштейном, поставляемым с инструкцией по установке. устройством, и монтажным кронштейном Panasonic для непосредственного крепления к потолку WV-Q105A. Использование с другим аппаратом может привести к ОСТОРОЖНО: нарушению... -
Page 7: Installation Precautions
Installation Instructions Installation precautions Panasonic does not accept any responsibility for accident or damage during installation if procedure in this manual is not followed. To installation personnel Read the “Installation Instructions” thoroughly and then perform the operation correctly and safely. - Page 8 Installation Instructions Installation precautions (continued) Be absolutely sure to use the specified brackets and Power switch screws to install the camera. The unit does not have a power switch. The power turns ● Do not mount the unit by employing any methods other on when its power plug is connected to a power outlet.
-
Page 9: How To Install And Connect The Unit
Installation Instructions How to install and connect the unit Be absolutely sure to read through the “Read this first!” (page 5) and “Installation precautions” (pages 7 to 8). The procedure given here is for the kind of installation where the unit is suspended from an overhead surface, but the same steps are followed for a stand-alone installation. - Page 10 Installation Instructions How to install and connect the unit (continued) Mount the mount bracket onto the installation surface. ● Use the bracket mounting screws [M4, bind-head: 10 mm (13/32 inches) long] supplied with the unit. ● For proper clamping torque, securely attach the screws using the specified tools. Screw diameter Clamping torque 1.47 N ·...
- Page 11 Installation Instructions How to install and connect the unit (continued) Mount the unit. ● Align the position of the hole for checking the positioning with the status display lamp. ● Align the holes on the camera main unit used to insert the bottom panel with the protrusions on the mount bracket used for inserting the camera, push the camera to the bracket firmly, and rotate the main unit by about 15 degrees in the direction of the arrow.
- Page 12 Installation Instructions How to install and connect the unit (continued) Connect the rear panel connectors. Anchor the AC adaptor cable in place using the cable clamp. ● How to secure the AC adaptor cable A Loosely secure the cable clamp. Cable clamp AC adaptor cable LAN cable...
-
Page 13: When Using The Wv-Q105A (Optional Accessory)
Installation Instructions How to install and connect the unit (continued) ■ When using the WV-Q105A (optional accessory) It is recommended that you provide an inspection opening or other such space for access purposes in the area near where the equipment is installed in order to facilitate installation and the wiring connections work. Before mounting the mount bracket, check that the installation location is strong enough to withstand the total mass (approx. - Page 14 Installation Instructions How to install and connect the unit (continued) When installing the unit on a wall (installation example) Before proceeding, fashion an L-shaped mounting fixture, and attach the fixture securely to the wall where the unit will be installed. IMPORTANT ●...
-
Page 15: Removing The Camera
Installation Instructions Removing the camera Turn off the circuit breaker and power. Disconnect the cables. Disconnect the power cable, video cable, and control cable, etc. Remove the main unit mounting screw used to secure the unit and mount bracket. Push the unit (A). Turn it approximately 15 degrees away from the installed position (B), and remove it (C). -
Page 16: Stand-Alone Installation (When The Mount Bracket Is Going To Be Used)
Installation Instructions Stand-alone installation (when the mount bracket is going to be used) The same steps are followed as for the kind of installation where the unit is suspended from an overhead surface (pages 9 to 12). Check the mounting space. Note ●... - Page 17 Installation Instructions Stand-alone installation (when the mount bracket is going to be used) (continued) Check the mounting. Connect the rear panel connectors. ● How to secure the AC adaptor cable A Loosely secure the cable clamp. Coaxial cable (for G/L IN) Cable clamp SDI cable LAN cable...
-
Page 18: Stand-Alone Installation (When The Mount Bracket Is Not Going To Be Used)
Installation Instructions Stand-alone installation (when the mount bracket is not going to be used) ■ When installing the unit on a desktop Place the unit flat on the surface. Notes ● Install the unit in a stable location which will not be susceptible to shaking. If the unit is installed in a location which is susceptible to shaking, this will cause the unit’s images to shake in turn. -
Page 19: Connections
Installation Instructions Connections ■ Connecting an NDI|HX compatible switcher AW-HE42 AW-HE42* Supplied AC adaptor LAN cable Switching hub NDI|HX compatible switcher External DC power supply Remote Camera Controller AW-RP50 *: The AC adaptor provided with the unit is not shown Monitor Monitor in the above figure. - Page 20 Installation Instructions Connections (continued) ■ Connecting a controller (AW-RP50) (IP connection example) Pan-tilt head / camera control signal AW-HE42 Remote Camera Controller HDMI/SDI signal LAN cable AW-RP50 SIGNAL GND POWER TO PAN/TILT HEAD 12V IN TALLY/GPI BOOT Monitor Supplied AC adaptor Supplied AC adaptor ●...
- Page 21 Installation Instructions Connections (continued) ■ System example 1 (connection with commercially available controller, RS-232C daisy-chain connection) AW-HE42* Up to 7 Commercially available controller RS-232C connector RS-232C Supplied AC adaptor Supplied AC adaptor Supplied AC adaptor connector *: You can connect up to seven cameras to a single controller. ●...
- Page 22 Installation Instructions Connections (continued) ■ System example 2 (connection with commercially available controller, RS-422 connection) AW-HE42 RS-422 communication connector Commercially available controller Supplied AC adaptor ● Configure the service switches at the bottom of the unit. For details on the service switches, see “Service switch settings” (page 64). Camera address Set to AUTO or 1 to 7.
-
Page 23: System Example 3 (Serial Control)
Installation Instructions Connections (continued) ■ System example 3 (serial control) AW-HE42 AW-HE42* RS-422 connector Supplied AC adaptor Pan-tilt head / camera control signal (LAN cable (straight cable)) Monitor 1 Monitor 2 Monitor Monitor Supplied AC System tally adaptor Compact Live Switcher AW-HS50 External DC power supply... -
Page 24: System Example 4 (Ip Control)
Installation Instructions Connections (continued) ■ System example 4 (IP control) AW-HE42 AW-HE42* IP video display Mobile terminal Supplied AC adaptor Wireless access point LAN cable IP video display Monitor 2 Switching hub Monitor 1 LAN cable (straight cable) Personal computer Monitor Monitor Supplied AC... -
Page 25: System Example 5 (Infrared Output Connection)
Installation Instructions Connections (continued) ■ System example 5 (infrared output connection) You can point the infrared remote control of a commercially available controller toward the camera to operate it. Remote camera control signal Commercially RS-232C cable (including infrared remote available controller control signals) AW-HE42 RS-232C... -
Page 26: System Example 7 (Usb Connection, Web Camera)
Installation Instructions Connections (continued) ■ System example 7 (USB connection, Web camera) AW-HE42 Communication software (optional accessory) Supplied AC Microphone adaptor USB cable (A-mini B type) Personal computer ● Use a USB cable that is compatible with the USB 2.0 specification. Connect a mini B connector to the unit. -
Page 27: Appearance
Installation Instructions Appearance Unit: mm (inch) 66 (2-19/32) 62 (2-7/16) 160 (6-5/16) 99 (3-29/32) 179 (7-3/64) 80 (3-5/32) 77 (3-1/32) 166 (6-17/32) -
Page 28: Operating Instructions
Operation at a voltage other than 120 V AC may require the use of a different AC plug. Please contact either a local or foreign Panasonic authorized service center for assistance in selecting an alternate AC plug. - Page 29 FCC NOTICE (USA) Supplier’s Declaration of Conformity Model Number: AW-HE42WP/AW-HE42KP Trade Name: Panasonic Responsible Party: Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102 Support contact: 1-800-524-1448 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 30 Operating Instructions Read this first! (For AW-HE42WP, AW-HE42KP) (continued) ENGLISH Information on Disposal in other Countries outside the European Union These symbols are only valid in the European Union. If you wish to discard the item(s), please contact your local authorities or dealer and ask for the correct method of disposal.
-
Page 31: Read This First! (For Aw-He42We, Aw-He42Ke)
Operating Instructions Read this first! (For AW-HE42WE, AW-HE42KE) ENGLISH WARNING: CAUTION: • To reduce the risk of fire or electric shock, do not In order to maintain adequate ventilation, do not expose this equipment to rain or moisture. install or place this unit in a bookcase, built-in cabinet •... - Page 32 Operating Instructions Read this first! (For AW-HE42WE, AW-HE42KE) (continued) ENGLISH EMC NOTICE FOR THE PURCHASER/USER OF THE APPARATUS 1. Pre-requisite conditions to achieving compliance with the above standards <1> Peripheral equipment to be connected to the apparatus and special connecting cables •...
- Page 33 Operating Instructions Read this first! (For AW-HE42WE, AW-HE42KE) (continued) ENGLISH For the AC mains plug of three pins Before use ■ Caution for AC mains lead Remove the connector cover. How to replace the fuse For your safety, please read the following text carefully. The location of the fuse differ according to the type of AC This appliance is supplied with a moulded three pin mains plug (figures A and B).
- Page 34 The symbols on this product (including the accessories) represent the following. Class II equipment (The construction of the product is double-insulated.) Manufactured by: Panasonic Corporation, Osaka, Japan Importer’s name and address of pursuant to EU rules: Panasonic Marketing Europe GmbH...
-
Page 35: Lire Ces Informations En Premier
Canada ou aux États-Unis d’Amérique. L’utilisation d’une tension de secteur autre que à 120 V C.A. peut exiger une fiche différente. Consulter un centre de service Panasonic authrisé local ou à l’etranger pour le choix de l’adaptateur approprié. Informations concernant la sécurité. - Page 36 Operating Instructions Lire ces informations en premier ! (Pour AW-HE42WP, AW-HE42KP) (suite) FRANÇAIS NOTIFICATION (Canada) CAN ICES-3 (A)/NMB-3(A) IMPORTANTES MISES EN GARDE 1) Lire ces instructions. 2) Conserver ces instructions. 3) Respecter ces instructions. 4) Suivre toutes les instructions. 5) Ne pas utiliser cet appareil près de l’eau. 6) Nettoyer avec un chiffon sec seulement.
-
Page 37: Lire Ces Informations En Premier ! (Pour Aw-He42We, Aw-He42Ke)
Operating Instructions Lire ces informations en premier ! (Pour AW-HE42WE, AW-HE42KE) FRANÇAIS AVERTISSEMENT: ATTENTION: • Pour réduire les risques d’incendie ou de choc Pour maintenir une bonne ventilation, ne pas installer électrique, évitez d’exposer cet appareil à la pluie ni placer l’appareil dans une étagère, un meuble ou à... - Page 38 Operating Instructions Lire ces informations en premier ! (Pour AW-HE42WE, AW-HE42KE) (suite) FRANÇAIS NOTE D’INFORMATION SUR LA CEM POUR L’ACHETEUR/UTILISATEUR DE L’APPAREIL 1. Conditions requises pour obtenir la conformité aux normes ci-dessus <1> Equipements périphériques à connecter à l’appareil et câbles de connexion spéciaux •...
- Page 39 Les symboles présents sur ce produit (y compris sur les accessoires) signifient les choses suivantes. Équipement de Classe II (Le produit a été fabriqué avec une double isolation.) Fabriqué par : Panasonic Corporation, Osaka, Japon Nom et adresse de l’importateur en accord avec les règlements de l’Union Européenne :...
-
Page 40: Lea Esto Primero (Para Aw-He42Wp, Aw-He42Kp)
CA puede requerir la utilización de una clavija de CA diferente. Póngase en contacto con un centro de servicio autorizado por Panasonic, bien sea local o del extranjero, para que le ayude en la selección de una clavija de CA alternativa. - Page 41 Operating Instructions Lea esto primero (Para AW-HE42WP, AW-HE42KP) (continuación) ESPAÑOL INSTRUCCIONES IMPORTANTES DE SEGURIDAD 1) Lea estas instrucciones. 2) Guarde estas instrucciones. 3) Tenga en cuenta todas las advertencias. 4) Siga todas las instrucciones. 5) No utilice este aparato cerca del agua. 6) Limpie únicamente con un paño seco.
-
Page 42: Lea Esto Primero (Para Aw-He42We, Aw-He42Ke)
Operating Instructions Lea esto primero (Para AW-HE42WE, AW-HE42KE) ESPAÑOL ADVERTENCIA: PRECAUCIÓN: • Para reducir el riesgo de producir un incendio o Para mantener unas buenas condiciones de recibir una descarga eléctrica, no exponga este ventilación, no instale ni ponga este aparato en equipo a la lluvia ni a la humedad. - Page 43 Operating Instructions Lea esto primero (Para AW-HE42WE, AW-HE42KE) (continuación) ESPAÑOL AVISO SOBRE CEM PARA EL COMPRADOR/USUARIO DEL APARATO 1. Condiciones previas para conseguir la conformidad con las normas mencionadas <1> Equipo periférico por conectar al aparato y cables de conexión especiales •...
- Page 44 Los símbolos en este producto (incluidos los accesorios) representan lo siguiente. Equipamiento de Clase II (Producto fabricado con aislamiento doble.) Fabricado por: Panasonic Corporation, Osaka, Japón Nombre y dirección del importador conforme a las normas de la UE: Panasonic Marketing Europe GmbH...
-
Page 45: Bitte Lesen Sie Zuerst Diesen Hinweis! (Für Aw-He42We, Aw-He42Ke)
Operating Instructions Bitte lesen Sie zuerst diesen Hinweis! (Für AW-HE42WE, AW-HE42KE) DEUTSCH WARNUNG: VORSICHT: • Zur Reduzierung der Gefahr von Brand und Um eine ausreichende Belüftung zu gewährleisten, elektrischem Schlag dieses Gerät weder Nässe dieses Gerät nicht in einem Bücherregal, noch Feuchtigkeit aussetzen. - Page 46 Operating Instructions Bitte lesen Sie zuerst diesen Hinweis! (Für AW-HE42WE, AW-HE42KE) (Fortsetzung) DEUTSCH EMV-HINWEIS FÜR DEN KÄUFER/ANWENDER DES GERÄTS 1. Erforderliche Bedingungen zur Einhaltung der oben genannten Standards <1> An das Gerät angeschlossene Geräte und spezielle Verbindungskabel • Der Käufer/Anwender sollte nur Geräte verwenden, die von uns als Zusatzgeräte für den Anschluss an das Gerät empfohlen wurden.
- Page 47 Die Symbole an diesem Produkt (einschließlich Zubehör) haben die folgenden Bedeutungen. Wechselstrom Gleichstrom Geräte der Klasse II (das Produkt wurde mit doppelter Isolierung konstruiert.) Hergestellt von: Panasonic Corporation, Osaka, Japan Name und Adresse des Importeurs gemäß EU-Bestimmungen: Panasonic Marketing Europe GmbH Panasonic Testing Centre...
-
Page 48: Leggere Prima Quanto Segue! (Per Aw-He42We, Aw-He42Ke)
Operating Instructions Leggere prima quanto segue! (Per AW-HE42WE, AW-HE42KE) ITALIANO AVVISO: PRECAUZIONE: • Per ridurre il rischio d’incendio o di scosse, non Per assicurare una buona ventilazione, non installare esporre questo prodotto alla pioggia o all’umidità. o sistemare questo apparecchio in uno scaffale, •... - Page 49 Operating Instructions Leggere prima quanto segue! (Per AW-HE42WE, AW-HE42KE) (continua) ITALIANO AVVISO EMC PER L’ACQUIRENTE/UTENTE DELL’APPARATO 1. Prerequisiti essenziali per la conformità agli standard sopra menzionati <1> Periferiche da collegare all’apparato e cavi di collegamento speciali • Si raccomanda all’acquirente/utente di collegare l’apparato esclusivamente con periferiche da noi approvate. •...
- Page 50 I simboli su questo prodotto (compresi gli accessori) rappresentano quanto segue. Apparecchiatura di classe II (il prodotto dispone di doppio isolamento.) Fabbricato da: Panasonic Corporation, Osaka, Giappone Nome e indirizzo dell'importatore in conformità con le normative UE: Panasonic Marketing Europe GmbH...
-
Page 51: Прочитайте Нижеследующее До Начала Эксплуатации! (Для Aw-He42We, Aw-He42Ke)
Operating Instructions Прочитайте нижеследующее до начала эксплуатации! (Для AW-HE42WE, AW-HE42KE) РУССКИЙ ОСТОРОЖНО: ПРЕДОСТЕРЕЖЕНИЕ: • Для снижения риска возникновения пожара или Для обеспечения надлежащей вентиляции не удара электрическим током не подвергайте данное устанавливайте и не размещайте данное устройство оборудование воздействию дождя или влаги. на... - Page 52 Operating Instructions Прочитайте нижеследующее до начала эксплуатации! (Для AW-HE42WE, AW-HE42KE) (продолжение) РУССКИЙ ПРИМЕЧАНИЕ EMC ДЛЯ ПОКУПАТЕЛЯ/ПОЛЬЗОВАТЕЛЯ 1. Условия, которые необходимо соблюдать для достижения соответствия указанным стандартам <1> Периферийное оборудование, которое подключается к устройству, и специальные соединительные кабели • Настоятельно рекомендуется использовать только то оборудование, которое поставляется как периферийные устройства...
- Page 53 Operating Instructions Прочитайте нижеследующее до начала эксплуатации! (Для AW-HE42WE, AW-HE42KE) (продолжение) РУССКИЙ Інформація для покупця Виробник: Панасонік Корпорейшн Panasonic Corporation Адреса виробника: Kadoma, Osaka, Japan Кадома, Осака, Японія Країна походження: Китай China Імпортер: ТОВ "ПАНАСОНІК УКРАЇНА ЛТД" Адреса імпортера: провулок Охтирський, будинок 7, місто Київ, 03022, Україна...
-
Page 54: Before Use
10.0 * viewing the camera images on the screen. Microsoft ® Windows ® 7 Professional SP1 ● Connection with a Panasonic camera controller is also 64-bit/32-bit * ® ® Windows Internet Explorer 8.0 / 9.0 / possible via Panasonic’s proprietary serial communication 10.0 / 11.0 *... -
Page 55: Disclaimer Of Warranty
IN NO EVENT SHALL Panasonic Corporation BE LIABLE ● After accessing the unit as an administrator, be sure to TO ANY PARTY OR ANY PERSON, EXCEPT FOR close all web browsers. -
Page 56: Characteristics
Panasonic Corporation so that an existing system can be applications, such as high dynamic range (HDR) and used to advantage to put together a system that is even dynamic range stretch (DRS) functions that compensate more flexible. - Page 57 (Scene), you can select ND filter auto selection ● Up to a hundred units can be operated by IP connection function according to ambient light conditions. from a Panasonic controller (AW-RP50). (The maximum length of the LAN cables is 100 meters Equipped with optical image stabilization (OIS) [328 ft].)
-
Page 58: Accessories
Operating Instructions Accessories Check that the following accessories are present and accounted for. ● After removing the product from its container, dispose of the power cable cap and packing materials in an appropriate manner. ■ ■ ■ ■ Mount bracket for installation Main unit mounting screw Drop-prevention wire ... -
Page 59: Operating Precautions
Operating Instructions Operating precautions Shoot under the proper lighting conditions. When using the automatic functions ● If “Full Auto” has been selected as the setting for Scene To produce pictures with eye-pleasing colors, shoot under the proper lighting conditions. on the camera menu, for example, all the auto settings The pictures may not appear with their proper colors when will be turned on, and manual operations will no longer be shooting under fluorescent lights. - Page 60 Operating Instructions Operating precautions (continued) Color bars Do not point the camera directly at the sun or a laser beam no matter whether it is turned on or not. Color bars are used to adjust the color phase, and the widths and positions of these bars may differ from other models.
-
Page 61: Concerning The Wireless Remote Control (Optional Accessory)
Operating Instructions Concerning the wireless remote control (optional accessory) ● If the unit is installed near fluorescent lights, plasma The unit can be operated by remote control using a wireless remote control (model number: AW-RM50G) monitors or other such products or if the unit is purchased separately. -
Page 62: Parts And Their Functions
Operating Instructions Parts and their functions ■ Camera unit Mount bracket for installation surface (supplied accessory) Mount this bracket onto the installation surface, and then attach the camera main unit to the bracket. Drop-prevention wire Pull out the wire from the bottom panel of the camera main unit, and attach it to the hook of the mount bracket. - Page 63 Operating Instructions Parts and their functions (continued) LAN connector for IP control [LINK/ACT] RS-422 connector [RS-422] This LAN connector (RJ-45) is connected when exercising This RS-422 connector (RJ-45) is connected when exercising serial control over the unit from an external IP control over the unit from an external device.
- Page 64 When this is set to ON, standard serial communication is 1080/25p 576/50i — enabled. 1080/50i 576/50i 1080/50i When this is set to OFF, Panasonic’s proprietary serial 1080/25PsF 576/50i 1080/50i 720/50p 576/50i 720/50p communication is enabled. ● External synchronization is performed using the SDI video (3) SW5: Maintenance switch signal.
-
Page 65: Wireless Remote Controller (Optional Accessory)
Operating Instructions Parts and their functions (continued) ■ Wireless remote controller MENU button Each time this is pressed for 2 seconds, operation (optional accessory) switches between displaying the unit’s camera menu and exiting the camera menu. When it is pressed quickly (for less than 2 seconds) while a menu is displayed, the setting change is canceled. - Page 66 Operating Instructions Parts and their functions (continued) PRESET/LIMIT button M/FOCUS button This is used to register the settings in the preset This is used when manually adjusting the lens focus. The FOCUS buttons ([F] and [N]) are used when memories or set or release the limiters. When a preset memory call button is pressed while the performing the actual adjustment.
-
Page 67: Setting The Remote Control Ids
Operating Instructions Setting the remote control IDs The wireless remote control (optional accessory) is capable of operating up to four units. IDs are used to set which units are selected when the [CAM1], [CAM2], [CAM3] and [CAM4] buttons on the wireless remote control have been pressed. -
Page 68: Network Settings [When Using Windows]
Easy IP Setup Software supplied. You can obtain Easy IP Setup Software (EasyIPSetup.exe) by downloading it from the following website. https://pro-av.panasonic.net/ To establish the settings for a multiple number of units, the settings must be selected for each camera involved. -
Page 69: Installing The Plug-In Viewer Software
Operating Instructions Network settings [When using Windows] (continued) ■ Input the network items, and click the [Save] Installing the plug-in viewer button. software To view IP images from the unit on a web browser, the “Network Camera View 4S” plug-in viewer software (ActiveX ®... -
Page 70: User Authentication
Operating Instructions Network settings [When using Windows] (continued) ■ User authentication User name and password management • Use a combination of characters and numbers that is The unit can be configured to allow access from the difficult to guess. internet. To prevent infringement of privacy and personality Avoid using a string of the same characters, such as rights, information leaks, and other issues concerning “11111”, birth dates, or telephone numbers. -
Page 71: Troubleshooting
Operating Instructions Troubleshooting ● Operation Symptom Cause and remedial action Reference pages ● Is the AC adaptor securely connected to the AC outlet? ––– ● Is the power plug of the AC adaptor connected properly? ––– ● Is the network cable for the PoE+ (IEEE802.3at compliant) P.25 compatible power supply device and the unit connected properly? No power... -
Page 72: Specifications
Operating Instructions Specifications For details on specifications, visit the Panasonic website (https://pro-av.panasonic.net/manual/en/index.html) and refer to the Operating Instructions. ■ AC adaptor Power requirements: 12 V (Supplied AC adaptor) Input: 100 V to 240 V, 1.2 A, 50/60 Hz 42 V to 57 V (PoE+ power supply) -
Page 73: Index
Operating Instructions Index AC adaptor (Supplied) ..........58, 72 Screw for mounting tripod ..........18 AC adaptor cable ............12, 17 SDI cable ..............12, 17 AW-HS50 ..............23, 24 AW-RM50G ..............58, 61 AW-RP50 ............19, 20, 23, 24 Tripod ................ - Page 74 Memo...
- Page 75 Memo...
- Page 76 Web Site: http://www.panasonic.com © Panasonic Corporation 2019...
