- Page 1 CONSPEC CONTROLS CS0352-MP User Manual 1/24/2017 Rev. 3...
-
Page 2: Table Of Contents
Index Purpose…………………………………………………………………………………………………..……………………………………………. 1 System Overview……………………………………………………………………………………………………….…………………..1 CS0352-MP Components……………………………………………………………………………………….....…………….…… 2 Panel View Screens…………………………………………………………………………………………………………………………..… 3 Modes……………………………………………………………………………………………………………………………....... 6 Trouble Conditions……………………………………………………………………………………………………......7 CO Sensor Calibration…………………………………………………………………………………………………………………... 9 Flow Detector Calibration………………………………………………………………………………………………………....10 See also……………………………………………………………………………………………………………………………………………..…10 Replacement Parts……………………………………………………………………………………………………………………….………10 Contact Information……………………………………………………………………………………………………………………….….…10... -
Page 3: Purpose
MillPro system and acts accordingly. The CS0352-MP performs scheduled high pressure blow backs to clear the sintered metal probes of any blockage. The system is able to detect a low flow condition if the probe becomes clogged and will perform an unscheduled blowback. -
Page 4: Cs0352-Mp Components
Figure 1: CS0352-MP Components CS0352-MP Components – Labels, Descriptions, and Part Numbers Allen Bradley 1400 1766-L32BWA Meanwell 24VDC 5A Supply SDR-120-24 500PPM CO Detector Card 900732-03 1000PPM CO Sensor P2261-3 Flow Detector Card 900724 120Vac 12 LPM Sample Pump AL-6SB... -
Page 5: Panelview Screens
Cooling Muffler Vortex 747 System Components not shown Panel view Component C600 2711C-T6T 120Vac 2 way Cooler Solenoid Vortex 747 System Vortec Cooler Vortex 747 System PanelView Screens Main screen The main screen contains a link to all the other screens. All the screens are accessible from the main screen. - Page 6 PV Config The Panel View Configuration screen is a user screen created by Allen Bradley Products to adjust screen settings such a contrast, brightness, screen time out time, etc. The date and time are also set from this screen as well as communication settings. Overview The Overview screen shows useful information all on one screen for easy viewing.
- Page 7 Alarm Log The Alarm Log screen logs alarms and error conditions. When an error occurs (such as a blocked probe during start up mode) the PLC immediately goes into alarm and energizes the trouble relay. This error is displayed on the panel view screen and needs to be cleared or acknowledged. A record of alarms and errors is kept in this screen and can be cleared if desired.
-
Page 8: Modes
Maintenance The Maintenance screen gives the options to change the Panel Setup Times and modes. Under the Panel Setup Times the user can adjust the Startup delay, High Pressure on time, number of blow backs, and the time between blowbacks. The modes available are the calibration mode, off mode, maintenance mode, and the startup mode. -
Page 9: Trouble Conditions
Normal Blow Back Mode Normal Blow Back Mode can only be accessed during Normal Mode and is an automated process which occurs every 60 minutes. The time interval is user definable but is factory defaulted to occur every 60 minutes. Normal Blow Back Mode is used to blow high pressure air through the probe to clear it of any dust or particles that could clog the sintered end of the probe and cause a low flow condition. - Page 10 Communication Error/Demoted The PLC has lost communications to the gas transmitter board. Typically caused by a loose connection or improperly configured communication settings in the Universal Transmitter. Mode Check Error The panel has been left in “Maintenance Mode” for longer than the user definable time frame. Error will clear once panel is put into startup mode.
-
Page 11: Co Sensor Calibration
CO Sensor Calibration Required parts: Zero gas (20.9% O2) Span gas (250 PPM CO) 3/16” I.D. rubber hose 3LPM regulator UP99 Universal IR programmer These parts are included in the P1879-CO-250-NC-3 Calibration Kit. To calibrate the sensor the panel door must be opened so the user can view the LCD display on the Universal Transmitter and the adjustable flow regulator. -
Page 12: Flow Detector Calibration
Verify that the flow detector indicator light turns red at approximately 1-1.5 LPM See Also Universal Transmitter Manual CS0352-MP Pneumatic Drawing (DWG2014-099 RevA) Replacement Parts Damaged or questionable parts should be replaced immediately upon detection. Damaged or inoperative parts could contribute to hazardous and/or unsafe conditions. Any consumable parts should be replaced if the reliability is questionable or within the part’s specific...
