F111 (Series 3)
In Ceiling Media Air Cleaner
APPLICATION
The F111 (Series 3) Ceiling Media Air Cleaner is a media
air cleaner that uses a three-speed direct drive forward
curve blower motor with particle filter. When equipped
with CPZ™ modules (2), gases and odors are adsorbed
from the air passing through the unit. The air cleaner
removes airborne particles such as dust, soot, mold
spores, pollen and some cooking smoke from the air
circulated through the filter.
FEATURES
• Three levels of filtration:
—
99.97% High Efficiency Particulate Air (HEPA)
—
Hospital grade filter 95% efficient at 0.3 micron
(MERV 16)
—
95% ASHRAE (MERV 12)
• Circulates up to 1250 cfm.
• Designed to overcome the increase in air flow
resistance normally caused by filter loading.
• White or black color cover to complement the ceiling.
• CPZ™ module removes up to 95% of the space odors
for up to 24 months.
• 3-Speed remote wall switch.
Application .....................................................................................
Features ...........................................................................................
Specifications ...............................................................................
Ordering Information .................................................................
Planning the Installation ..........................................................
Installation .....................................................................................
Operation ........................................................................................
Service ..............................................................................................
Parts List .........................................................................................
PRODUCT DATA
Contents
1
1
2
2
3
4
7
8
9
