Brother P-Touch 2700 Technical Information

P-touch 2700
Brother P-touch labels have been subjected to a series of rigorous
tests which prove that even when they're exposed to extreme condi-
tions our labels have been designed to last.
Laminated – our unique laminated tape technology ensures
that a layer of super-clear polyethylene laminate protects your
text.
Temperature Resistant – P-touch labels can withstand
extreme temperatures, from -80°C to 150°C.
Strong Adhesion – specially developed adhesive means P-
touch labels will stay firmly affixed to a wide range of sur-
faces.
Abrasion Resistant – In the P-touch abrasion test using a 1kg
sanding device, lettering remained completely intact, only the
protective layer was slightly scratched.
Chemical Resistant – after being submerged for 2 hours in a
variety of chemical substances, no change in appearance or
structure of P-touch labels occurred and the labels remained
affixed.
Water Resistant – after submersion in water over a long peri-
od, the tape structure and adhesive strength of P-touch labels
remained unchanged.
Fade Resistant – after a year in a simulated sunny climate P-
touch labels showed very little change visible to the naked
eye.
Easy Peel – enables convenient removal of the tape backing
before applying the label.
P-touch 2700
Why do Brother P-touch labels last longer ?
Unlike ordinary labels, Brother's patented laminated tape technology
ensures that a layer of super clear polyethylene laminate protects your
text. Our laminated tapes consist of six layers of materials, resulting in a
thin, extremely strong label.
Characters formed with thermal transfer ink are actually printed on the
underside of the laminate and sandwiched between layers of PET (poly-
ester film). This lets you create characters that are virtually indestructi-
ble on labels that stand the test of time.
protective coating (PET) 38µm
lettering
adhesive (Acryl)
base film (PET)
colour layer for the base film
adhesive (acrylic)
backing paper
Brother Laminate Tape Construction
Tape Widths
18mm
Contact:
Brother International (Aust) Pty Ltd
Web-site: www.brother.com.au Technical Help Web-site:http://solutions.brother.com
NSW/ACT 7 Khartoum Rd. North Ryde NSW 2113 Phone: (02) 9887 4344 Fax: (02) 9870 7234
VIC 1/733 Whitehorse Rd. Mont Albert VIC 3127 Phone: (03) 9899 4844 Fax: (03) 9899 4833
QLD/NT 245 Riverside Drive. West End QLD 4101 Phone: (07) 3255 1211 Fax: (07) 3255 1911
SA/TAS Unit 4, 13 King William Rd. Unley SA 5061 Phone: (08) 8272 1300 Fax: (08) 8272 1199
WA 117 Great Eastern Highway. Belmont WA 6104 Phone: (08) 9478 1955 Fax: (08) 9277 2177
All specifications subject to change without notice
2700 2700
Professional Labelling Solution
18mm
<
Always at your side
P-touch 2700
Technical Information
Hardware
Housing Dimensions 179.5 mm (W) x 247.9 mm (D) x 71.8 mm (H)
Housing Weight 850g
Housing Design Desktop
Housing Colour Silver & Black
Keyboard QWERTY
Number of Keys 67
Cutter Automatic
Power AA Alkaline Batteries x 8 or AC Adapter (Model AD-3000 included)
LCD 16 chr x 3 line (Graphical display), 128 dots x 48 dots, Back Light
Included Items User Guide, Software Installation Guide (Windows/Mac), CD-ROM- Printer driver,
P-touch Editor 4.2 (Win) & 3.2.9 (Mac), P-touch Quick Editor 2.0 (Win) & 1.2.9
(Mac), 24 mm Black on White Tape (5m), AC adapter (Model AD-3000), USB cable
Tape Type TZ-tape
Tape Size 3.5 / 6 / 9 / 12 /18 / 24 mm
Print Head 180 dpi
Print Speed 10mm / sec.
Built-In Software
Fonts 8 fonts (Helsinki, Brussels, US, Florida, Belgium, San Diego, Los Angeles, Calgary )
Characters 329
Symbols 120
Max. Print Height 18.1mm
Character Size (Pts) 8 sizes (6, 9, 12, 18, 24, 36, 42 and extra BIG)
Label Length Setting 30mm - 300mm
Multi - Line 7 lines
Multi - Block Yes
Tab Function Yes
Text Buffer 280
Memory 2800 chrs ( 99 areas )
Type Style Normal / Bold / Outline /Shadow / Solid / Italic / Italic Bold / Italic Outline / Italic Solid /
Italic Shadow
Framing & Fill Pattern 17 Frames, 3 Patterns
Barcode CODE39, CODE128, EAN8, EAN13, EAN128, UPC-A, UPC-E,
I-2/5(ITF), CODABAR
Copy Printing 1 ~ 99
Mirror Printing Yes
Vertical Printing Yes
Numbering 99
Auto Formats Block Layouts ( 24 layouts ), Templates ( 17 formats)
Battery Weak Display Yes
Unit Change Yes (cm / inch)
Auto Power Off Yes
Print Image Preview Yes
Minimum System Requirements (for computer connection)
Interface USB 1.1 or 2.0
Computer OS PC installed with Microsoft® Windows® 98SE/Me/2000 Professional/XP
Macintosh series with USB port installed with Mac OS 9.1x, Mac OS X 10.1- 10.4.4
Display SVGA High colour graphics support or higher
