Bluetooth
Access Controllers
No Codes to Remember
Intuitive, visual, app-based programming and management, 1,000
users, device options, etc.
No Could, No Internet Exposure
All data secured on device, set and monitored by the administrator
More Than Access
Can control doors, gates, lighting, machinery, etc.
Multiple User Types
Permanent, scheduled, temporary, number of times
Output Modes
Timed relock (1~1,800s), remain unlocked, remain locked, toggle,
customizable for each users
Individual User Customization
Individually customizable output mode and time
Authorized User Monitor
Displays total number of users to guard against unauthorized
additions
®
Complete Installation Manual
Multiple Ways to Open a Door or Device
Keypad, proximity card/fob*, or app
Hold Open
Hold door open with code, card, or app (customizable)
Secure, Integrated Bluetooth
Passcode protected, AES128 encryption
Unlimited Devices
Access/manage an unlimited number of devices with one app
Easy Backup and Restore
For off-device storage, restoration, and replication of devices
Intuitive Device and User Names
Front Door, Finance Office, John Smith, Jane Doe, etc.
Downloadable Audit Trail
Last 1,000 events, searchable by user and event type
Multilingual App Interface
English, Spanish, French, Portuguese, German, Russian,
Vietnamese, and Chinese (Traditional or Simplified)
and Administrator Guide
™
SL Access

Advertisement

Table of Contents
loading

Related Manuals for SECO-LARM ENFORCER SK-B241-PQ

Summary of Contents for SECO-LARM ENFORCER SK-B241-PQ

  • Page 1 ™ ® Bluetooth SL Access Complete Installation Manual Access Controllers and Administrator Guide Multiple Ways to Open a Door or Device No Codes to Remember Intuitive, visual, app-based programming and management, 1,000 Keypad, proximity card/fob*, or app Hold Open users, device options, etc. No Could, No Internet Exposure Hold door open with code, card, or app (customizable) Secure, Integrated Bluetooth...

  • Page 2: Table Of Contents

    Instructions to Users: ..........50 Select the Tamper Alarm Sensitivity ....20 Firmware Version Updates: ........50 Auto Proximity Unlock: ......... 21 Troubleshooting:............ 51 Setting the Auto Proximity Range ......21 Accessories Available from SECO-LARM: ..52 SECO-LARM U.S.A., Inc.

  • Page 3: Getting Started

    French, Portuguese, Russian, German, Vietnamese, and Traditional and Simplified Chinese), otherwise, it will default to English. c. Page references within the text of this manual are all clickable links which will take you to the page indicated. SECO-LARM U.S.A., Inc.

  • Page 4: Installation

    Failure to use these as directed will void the warranty. † Use the blue wire for fail-secure applications and the yellow wire for fail-safe applications. Use electrical tape to insulate the end of any unused wire. SECO-LARM U.S.A., Inc.

  • Page 5: Led Indicators And Device Sounds

    4. All wiring and programming should be done by a professional installer to reduce the risk of improper installation. 5. The SL Access App User Manual for this keypad is downloadable from the product page at www.seco-larm.com. 6. Be sure to store this manual in a safe place for future reference.

  • Page 6: Understanding The Sl Access Home Screen

    Bluetooth has a limited range of about 60 feet (20m) under ideal conditions, but will be much less in practice. Move closer to the device, but if "Searching…," continues to show you may need to exit and reopen the app. SECO-LARM U.S.A., Inc.

  • Page 7: Logging In To Your Device

    However, if you log in using another phone, the first phone will have to log in again. Only one phone can be remembered at a time. g. You cannot "log out" because Bluetooth LE only connects briefly when a signal is sent. Only logging in from another phone will cause the first to be "forgotten." SECO-LARM U.S.A., Inc.

  • Page 8: Understanding The Admin Setup Screen

    If you close the app before leaving the Settings screen, it may remain connected to the device rendering it inaccessible to users via app until it automatically disconnects (around 2 minutes). SECO-LARM U.S.A., Inc.
  • Page 9 View the device's date and time Key Sounds (pg. 13 ‡ Enable/disable the key sounds Help (pg. 23) Go to the SECO-LARM help page Legal and Privacy (pg. 23) Visit the SECO-LARM website for legal notices and our privacy policy About (pg. 23) About this app Firmware Version (pg.

  • Page 10: Changing The Admin Passcode

    The passcode should be something you can easily remember but which is unlikely to be guessed by others. If you forget your password, see pg. 44 for reset instructions. b. The ADMIN passcode can also be used like a common user to trigger the access device. SECO-LARM U.S.A., Inc.

  • Page 11: Adding An Admin Proximity Card

    Confirm NOTES: a. Like the ADMIN passcode, the proximity card/fob can also be used to trigger the access control device. b. To delete a card/fob, click ADMIN Car/Fob and then delete the number from the popup box. SECO-LARM U.S.A., Inc.

  • Page 12: Changing The Device Name

    Select the Device Name's Click on Device Name Type the new name and entry box click Confirm NOTE: The device name can be up to 16 characters including spaces (or 16 bytes for some other languages). SECO-LARM U.S.A., Inc.

  • Page 13: Settings To Enable/Disable

    Enable/Disable the Key Sounds Enable the key sounds for an audible indicator when the keys are pressed. † Disable them for a quieter environment. Disabling the key sounds does not disable other warning sounds. † For keypads only SECO-LARM U.S.A., Inc.

  • Page 14: Global Output Mode

    (see pg. 30). b. Remain Unlocked and Remain Locked will only affect the ADMIN and will immediately unlock or lock the door. Other users will be unaffected and will not override this setting. SECO-LARM U.S.A., Inc.

  • Page 15: Setting The Time For Timed Relock Mode

    3. If the device is later locked using Toggle Output Mode (whether set globally or individually), other users will be granted or denied access depending on their individual settings. 4. The Toggle Output Mode is also useful for turning machinery or other devices on or off for a longer, undetermined period of time. SECO-LARM U.S.A., Inc.

  • Page 16: Door Hold Open

    (maybe called Toggle or Business Hours) with the Output Mode set to Toggle to unlock the door for business and relock it again at closing time. Other employees set to Timed Relock could still enter the business before business hours to prepare for opening. SECO-LARM U.S.A., Inc.

  • Page 17: Wrong Code/Card Lockout

    The ADMIN can set the number of wrong codes/cards before lockout and the length of time the device will locked out. Setting the Number of Wrong Codes/Cards Click on Number of Wrong Enter the number of wrong Codes codes (3~10) for lockout and click Confirm SECO-LARM U.S.A., Inc.

  • Page 18: Setting The Wrong-Code/Card Lockout Time

    Enter the desired time (1~5 Click Wrong-Code Lockout minutes) for the device to Time lockout and click Confirm NOTE: During the lockout time, the ADMIN can interrupt the lockout with the app, but not with the keypad or card. SECO-LARM U.S.A., Inc.

  • Page 19: Tamper Alarm

    The tamper alarm will sound an internal buzzer and will output to an external alarm if connected. It will continue until the time expires or until the ADMIN disables the tamper alarm in the app. The tamper alarm can be immediately re-enabled for continued protection. SECO-LARM U.S.A., Inc.

  • Page 20: Select The Tamper Alarm Sensitivity

    Low Sensitivity means that the level of vibration or movement must be much greater to set off the alarm. b. Vibration can vary depending on the mounting surface. You may need to experiment with different settings if you find that there are too many false alarms. SECO-LARM U.S.A., Inc.

  • Page 21: Auto Proximity Unlock

    Distance is also shown on this you wish to the device to be screen. Use the slider to adjust triggered. Click on the your Auto Proximity Range to Settings icon. a number that closely matches the Current Device Distance. SECO-LARM U.S.A., Inc.

  • Page 22: Enable Auto Proximity Unlock

    Enable Auto Proximity Unlock Click the radio button next to Auto to enable or to disable. NOTE: You cannot open the Settings screen when Auto is enabled. You must first disable Auto on the home screen to enter Settings. SECO-LARM U.S.A., Inc.

  • Page 23: Settings Screen Miscellaneous Items

    Settings page, which will automatically set the device to the correct date and time.   Help – Selecting Help will take you to the SECO-LARM  website. Use the search box to find the product page for ...

  • Page 24: Managing Users

    Passcodes must be 4~8 digits and are used to allow a user to log in to the app and also as their keypad code. e. Each passcode must be unique. f. Each device supports up to 1,000 users plus the ADMIN. SECO-LARM U.S.A., Inc.
  • Page 25 (if known) or… fob on the device. *Devices with a proximity reader only. NOTE: After a user has been added, any changes made on the User Info screen will take effect immediately without needing to "save." SECO-LARM U.S.A., Inc.

  • Page 26: Viewing, Changing Settings, And Deleting A User

    A popup will open to show the progress as it opens the user list. If you have a very large number of users, it may take several minutes to completely download. To start viewing the list while it is processing, click Hide to remove the popup. SECO-LARM U.S.A., Inc.

  • Page 27: Setting User Access Type

    The device time is synchronized to the ADMIN phone each time they connect to the device and open the settings page. To adjust to Daylight Savings Time, the ADMIN must log in and open the Settings page after their phone adjusts to the new time which will then adjust the device time. SECO-LARM U.S.A., Inc.

  • Page 28: Setting User Access Type - Visitors

    For the Temporary access type: a. The ending date/time must be later than the starting date/time. b. The time between starting and ending is continuous, so if the ending date is different, the access will include the overnight time between. SECO-LARM U.S.A., Inc.

  • Page 29: Setting User Access Type - Scheduled

    Scheduled and choose which days you wish to give arrow or back button the time period you wish to give the user access. (Android). the user access by clicking on and setting the Starting Time and Ending Time. SECO-LARM U.S.A., Inc.

  • Page 30: Setting A Custom Output Mode For A User

    (and timing, if the global mode unlocked. is set to Timed Relock) will follow the settings in Output Mode (Global). NOTE: For a better understanding of the Toggle mode, please see pg. 15. SECO-LARM U.S.A., Inc.
  • Page 31 Info screen, you will see an and click Confirm. Output Time setting if the additional line for Output Time. global mode is Timed Relock. Click on this to set the time before relock. SECO-LARM U.S.A., Inc.

  • Page 32: Searching/Filtering Users

    SECO-LARM U.S.A., Inc.

  • Page 33: Other User Management

    Export allows you to export these users as a backup or to replicate (import) to another device. c. Delete All will delete all users from this device. d. To delete individual users, you must open that user's User Info screen (see pg. 26). SECO-LARM U.S.A., Inc.

  • Page 34: Exporting Users

    For longer lists the user list file can be edited in a computer spreadsheet and reimported, however great care must be taken in the process to avoid data corruption (see pg. 45). e. For more information on user files, see pg. 37. SECO-LARM U.S.A., Inc.

  • Page 35: Importing Users

    Importing a user file will not overwrite existing users. It will only add any users that do not exist in the current file. To replace all users, first Delete All (see pg. 33) and then import. SECO-LARM U.S.A., Inc.

  • Page 36: User Import Error Message

    View the names on the file you were trying to import and make sure that no passcodes or proximity cards are the same as already existing users (see Understanding User Files, pg. 37). SECO-LARM U.S.A., Inc.

  • Page 37: Understanding User Files

    For more information, visit the device product page at www.seco-larm.com for more information. 6. File names for devices named in a right-to-left language (such as Arabic) will not display correctly onscreen unless the phone's language setting is also a right-to-left language. SECO-LARM U.S.A., Inc.

  • Page 38: The Audit Trail

    Click the Audit Trail button on A popup shows the download Click the circular Refresh icon progress. Click Hide to view to reload the audit trail. the ADMIN settings screen. the more recent records while the download is in progress SECO-LARM U.S.A., Inc.

  • Page 39: Searching / Filtering The Audit Trail

    A popup will appear allowing you to share or send it to an additional location in addition to the SL Access folder on your phone. If you don't wish to do so, simply click anywhere above the popup. SECO-LARM U.S.A., Inc.

  • Page 40: Deleting The Audit Trail

    The method used to gain entry will be shown in the By column (APP, Keypad, Card/Fob). When a user with Output Mode set to Toggle (see pg. 30) accesses the device, the toggle will be recorded along with the action, "unlocked" or "locked." SECO-LARM U.S.A., Inc.
  • Page 41 Each time you download the audit trail, a new file is created on the phone. These files cannot be deleted from within the SL Access app. To delete old files, use a file manager on Android or connect your iOS phone to your computer and use the MacOS Finder. SECO-LARM U.S.A., Inc.

  • Page 42: Backing Up Device Settings

    The backup file will be stored in the phone's SL Access folder on Android devices. On iOS devices, it is saved in the app's program folder which is not user accessible. d. The filename format is "Device Name_Backup.bp" so for the Main Entrance, the filename would be Main Entrance_Backup.bp. SECO-LARM U.S.A., Inc.

  • Page 43: Restoring Device Settings Or Replicating To Another Device

    Another option for replication is to give the second device the same name as the first, then use Restore Device on the second device. After the restore is complete, rename the second device to a more suitable name. SECO-LARM U.S.A., Inc.

  • Page 44: Resetting The Device

    9. Remove power, restore the jumper to pins 1 and 2, reinstall, and power on the device. Jumper Pin Locations Jumper Pins SK-B141-DQ PR-B1124-SPQ SK-B241-PQ SK-B141-PQ 1 2 3 Normal (default) Pins 1 and 2 1 2 3 Reset 1 2 3 Pins 2 and 3 SECO-LARM U.S.A., Inc.

  • Page 45: Editing An Exported User File On A Computer

    3. From the dialog box that opens, navigate to the correct folder, choose your user file, and click on "Import." 4. In the next dialog, choose "Delimited," "Start at row 1," and for the "File origin," choose "65001 : Unicode (UTF-8)" and click "Next." SECO-LARM U.S.A., Inc.
  • Page 46 6. In the next dialog box, click on the horizontal scroll button and drag to the right so that the last field is showing. Holding down the shift key, click on the last field. All the fields should now be highlighted. Choose "Text" as the "Column data format" and click the "Finish" button. SECO-LARM U.S.A., Inc.
  • Page 47 Type" column, it is best to find another user with the same setting and copy from that user. c. Make sure that you use the same time (24-hour military time) and date (YYYY-MM-DD) format as you see already used for existing users and that the end date/time is after the start date/time. SECO-LARM U.S.A., Inc.
  • Page 48 Editing an Exported User File on a Computer: (Continued) 9. When finished, use the "File, Save As" to save to the correct folder. In the popup dialog, first change the file format to "CSV UTF-8 (Comma delimited) (*.csv)" format. SECO-LARM U.S.A., Inc.
  • Page 49 11. Email or save that file back to your phone and move it to the "SL Access" folder. It will then appear in your import list when you attempt to import a user file to the device (or any ENFORCER Bluetooth Access Control device). SECO-LARM U.S.A., Inc.

  • Page 50: Instructions To Users

    ADMIN. For the ADMIN's convenience, we have placed a User Instruction file on each product page on SECO-LARM's website. It is a fillable PDF that you can give to users, providing them with basic instructions for downloading what they need to get started.

  • Page 51: Troubleshooting

     If scheduled or temporary, make sure that the time setting for AM and PM are correct. I can't find the backup file on my  The settings backup file is not accessible to users on iOS. iOS phone SECO-LARM U.S.A., Inc.

  • Page 52: Accessories Available From Seco-Larm

    IMPORTANT: Users and installers of this product are responsible for ensuring that the installation and configuration of this product complies with all national, state, and local laws and codes related to locking and egress devices. SECO-LARM will not be held responsible for the use of this product in violation of any current laws or codes.
