CNET CWR-854 Specification Sheet

TOTAL NETWORK SOLUTIONS
The CWR-854 Wireless-G Router delivers robust performance, advanced security, and ease of use for small office/home office
environments. Using CWR-854, both wired and wireless devices securely share a single broadband Internet connection. Wireless
LAN users can connect at speeds up to 54 Mbps and interoperate with existing popular Wireless-B equipment. To protect data and
privacy, CWR-854 can encrypt all transmissions with advanced security and firewall features of a full-scale router at a fraction of the
price.
KEY FEATURES
=
Built-in Stateful Packet Inspection (SPI) firewall security
=
Investment Protection: 5 times faster and interoperate
with existing Wireless-B equipment seamlessly
=
Ease of Use: Simple Installation, Intuitive Web based
management, DHCP Server and Clients
=
Access control based on IP address filtering, MAC
address filtering, date and time of the day.
=
40/64/128 bit WEP and WPA encryption provides
maximum wireless security
=
Support WDS function to extend the Wireless coverage
=
Four 10/100Mbps Switch ports with Auto MDI/MDI-X
provide wired LAN connectivity; up to 253 (45 wireless)
users
SPECIFICATIONS
Product Name
Model
Standards
Channels
Ports
Media Support
Data Rate
LED Indicators
Modulation
WAN Connection
Network Protocols
Configuration Interface
Power Adapter
Environment
Certifications
Dimensions
ORDERING INFORMATION
Model
CWR-854(D)
CWR-854(D)
Specifications are subject to change without notice
CWR-854
IEEE 802.3, 3u, IEE 802.11b, IEEE 802.11g
1-11 (U.S.), 1-13 (Elsewhere in the Worldwide), 1-13,14 (Japan)
WAN: One 10/100 RJ45 Port for Cable/DSL Modem
LAN: Four 10/100 RJ-45 Switched Ports
CAT 5 Ethernet Cabling or Better
Up to 54Mbps (Wireless)
10/100 Mbps (Ethernet)
Power: Green
WLAN: Green
WAN: Link/Speed: Green
LAN: Link/Speed: Green
802.11b: CCK, DQPSK, DBPSK
802.11g: OFDM
DHCP Client, Fixed IP, PPPoE, PPTP
TCP/IP, NetBEUI, IPX/SPX
MS IE, Netscape, FireFox, and Mozilla Web browser
External, 5V DC, 2.5A
Operating Temperature: 0° ~ 40° C (32° ~ 104° F)
Storage Temperature: -20° ~ 70° C (-4° ~ 158° F)
Humidity: 10% ~ 85% Non-condensing
CE, FCC
180 x 110 x 13 mm (7.09 x 4.33 x 1.18 inches)
Wireless-G Router with 4-port Switch
CWR-854 –W
IRELESS
www.cnetusa.com
Wireless-G Router with 4-port Switch
Description
Trademarks & Trade Names belong to their owners
-G R
OUTER
April 2005
