Control 4 C4-4SF120 Installation Manual

Fan Speed Controller
Installation Guide
Supported model
• C4-4SF120 Fan Speed Controller
Introduction
The Control4® Fan Speed Controller operates independently or as part of a
Control4 home automation system to provide four quiet speeds plus an Off
setting for standard paddle-type ceiling fans. It installs in a standard back box
using typical wiring standards and communicates to the Control4 system using a
wireless connection.
Box contents
• Fan Speed Controller
• Wire nuts
• Warranty card
• Fan Speed Controller Installation Guide (this document)
Specifications and supported load types
The specifications are described below.
Model number
Power requirements
Power consumption
Load types and ratings
Supported load types
Maximum load
Operational temperature
Humidity
Storage
Control communications
Wallbox volume
Weight
Shipping weight
™
C4-4SF120-xx
120V AC +/-10%, 50/60 Hz
This device requires a neutral connection. See
the "Sample Wiring Configurations" later in this
guide.
500mW
Single, paddle-type ceiling fan
2A
Environmental
0 to 40 ˚C (32 to 104 ˚F)
5% to 95% non-condensing
-20 to 70 ˚C (-4 to 158 ˚F)
Miscellaneous
Zigbee, IEEE 802.15.4, 2.4 GHz, 15-channel
spread spectrum radio
5.75 cubic inches
0.05 kg (0.12 lb.)
0.08 kg (0.18 lb.)
Warnings and considerations
WARNING! Turn OFF electrical power before installing or servicing this
product. Improper use or installation can cause SERIOUS INJURY, DEATH
or LOSS/DAMAGE OF PROPERTY.
ATTENTION! Coupez l'alimentation électrique avant d'installer ou de
réparer ce produit. Une mauvaise installation ou utilisation peut entraîner
des blessures graves, décès ou perte / dommages à la propriété.
WARNING! This device must be protected by a circuit breaker (20A max).
Cet appareil doit être protégé par un disjoncteur (20A max.)
ATTENTION!
WARNING! Ground this device in accordance with the National Electric
Code (NEC) requirements. DO NOT rely solely upon the yoke plate's
contact with a metal back box for adequate grounding. Use the device's
ground wire to make a secure connection to the safety ground of the
electrical system.
ATTENTION! Cet appareil doit être en conformité avec le Code national de
l'électricité (NEC). Ne comptez pas uniquement au contact de la plaque
avant avec un boîtier mural métallique pour la mise à la terre adéquate.
Utilisez cet appareil à la terre de l'appareil pour établir une connexion
sécurisée au système électrique.
IMPORTANT! This device must be installed by a licensed electrician in
accordance with all national and local electrical codes.
IMPORTANT! If you are unsure about any part of these instructions,
consult a qualified electrician.
IMPORTANT! Use this device only with copper or copper-clad wire. Do
not use aluminum wiring. This product has not been approved for use with
aluminum wiring.
IMPORTANT! Using this product in a manner other than outlined in this
document voids your warranty. Further, Control4 is NOT liable for any
damage incurred with the misuse of this product. See "Troubleshooting."
Do NOT use a power screwdriver to install this device. If you
IMPORTANT!
do, you may overtighten the screws and strip them. Also, overtightening
the screws may interfere with proper button operation.
IMPORTANT! This is an electronic device with intricate components.
Handle and install with care!
This device must not be connected to a bathroom exhaust
IMPORTANT!
fan. This type of motor is not compatible.
IMPORTANT! When used in conjunction with an Auxiliary Keypad
(C4-KA-xx), the wire connecting the Auxiliary Keypad to the Fan Speed
Controller must not exceed 150 feet (45 m) at 120VAC, and 100 feet (30
m) at 277VAC.
Installation instructions
1 Ensure that the location and intended use meet the following criteria:
• If the ceiling fan being controlled is a fan/light combination, there must
be separate load wires for the fan and light from the control location. A
separate Control4 dimmer or switch must be used if the light is to be
controlled. Do not use the Fan Speed Controller to control the light.
• Do not exceed the load capacity requirements of the Fan Speed
Controller. Refer to the load ratings in the specifications above for details.
• Install in accordance with all national and local electrical codes.
• The range and performance of the wireless control system is highly
dependent on the following: (1) distance between devices; (2) layout
of the home; (3) walls separating devices; and (4) electrical equipment
located near devices.
