- Page 1 533AFDMTB ADAPTIVE WIFI ENABLED SURROUND INVERTER SMART CONTROL COOLING TECHNOLOGY MY FRESH CHOICE DUAL TECH BRUSH CONVERTIBLE ZONE COOLING MATT FINISH...
-
Page 2: Table Of Contents
Contents Safety and warning information Installing your new appliance Description of the appliance Display controls Using your appliance Installing Smart Wifi Module Helpful hints and tips Troubleshooting Disposal of Appliance Warranty Terms & Conditions... -
Page 3: Safety And Warning Information
For your safety and correct usage, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to make sure that all people using the appliance are thoroughly familiar with its operation and safety features. - Page 4 If you are discarding the appliance, pull the plug out of the Socket, cut the connection cable (as close to the appliance as you can) and remove the door to prevent children playing from suffering an electric shock or from closing themselves inside it. If this appliance, featuring a magnetic door seal, is to replace an older appliance having a spring lock (latch) on the Door or lid, be sure to make the spring lock unusable before you discard the...
- Page 5 compartments of the appliance, unless they are of the type recommended by the manufacturer. WARNING - The refrigerant and insulation blowing gas are flammable. When disposing of the appliance, do so only at an authorized waste disposal centre. Do not expose to flame. WARNING - When positioning the appliance, ensure the Supply cord is not trapped or damaged.
- Page 6 - Avoid opening flames and sources of ignition. - Thoroughly ventilate the room in which the appliance is situated. It is dangerous to alter the specification or modify this product in any way. Any damage to the cord may cause a short circuit, fire, and/or electric shock. Electrical safety 1.
- Page 7 pull on the cable. Do not place hot items near the plastic components of this appliance. Do not place food products directly against the air outlet on the near wall. Store pre-packed frozen food in accordance with the frozen food manufacturer’s instructions.
- Page 8 Caution! Care and cleaning Before maintenance, switch off the appliance and disconnect the mains plug from the mains socket. Do not clean the appliance with metal objects, steam cleaner, ethereal oils, organic solvents or abrasive cleansers. Do not use sharp objects to remove frost from the appliance.Use a plastic scraper.
-
Page 9: Installing Your New Appliance
This product must be serviced by an authorized Service Centre, and only genuine spare parts must be used. 1) If the appliance is Frost Free. 2) If the appliance contains freezer compartment. Installing your new appliance Before using the appliance for the first time, you should be informed of the following tips. - Page 10 Climate Class Ambient temperature +16 C to +43 C Stand your appliance in a dry place to avoid high moisture. Keep the appliance out of direct sunlight, rain or frost. Stand the appliance away from heat sources such as stoves, fires or heaters. Levelling of appliance For sufficient levelling and air circulating in the lower rear section of the appliance, the bottom feet may need to be adjusted.
-
Page 11: Description Of The Appliance
Description of the appliance WIFI module connection position... -
Page 12: Display Controls
Note: Due to unceasing modification of our products, your refrigerator may be slightly different from this instruction manual, but its functions and using methods remain the same. To get more space in the freezer, you can remove drawers (except lower freezer drawer). Display controls Use your appliance according to the following control regulations, your appliance has the corresponding functions and modes as the control panels... - Page 13 indicator will display the corresponding value according to the following sequence. 2. My Fresh Choice Press “ZONE” repeatedly until “My Fresh Choice” icon lights up and then press “TEMP.” repeatedly to set temperature between -20 C and +5 C to suit your desired temperature and the temperature indicator will display corresponding value according to the following sequence.
- Page 14 temperature, and the freezer temperature indicator will display corresponding value according to the following sequence. 4.Super Cool Super Cool can refrigerate the food quicker and keep food fresh for longer period of time. Press “MODE” to activate this function. The super cool icon will be illuminated and the fridge temperature will indicate 2 C.
- Page 15 Important! Do not store any food in the fridge during this time. When holiday function is on you can switch it off by pressing “MODE” and the refrigerator temperature setting will revert to its previous setting. 7. Drinks This function is used to cool drinks quickly. 1.
-
Page 16: Using Your Appliance
please set it on the EZ SmartHome App When you enter the Drinks Mode setting, the default is 45 minutes. However, while managing the refrigerator from the mobile APP, you can (1) Press confirm icon ( for default 45min) or (2) change the time between 5 –... - Page 17 When you remove the shelves, gently pull them forward until the shelf comes clear of the shelf guides. When you return the shelves, make sure there is no obstacle behind and gently push the shelf back into the position. Crispers The crisper, mounted on telescopic extension slides, is for storing vegetables and fruits.
-
Page 18: Installing Smart Wifi Module
frozen, such as meat, ice cream and others. Caution! Ensure that bottles or cans are not stored in the freezer as freezing may cause the bottle or can to burst. Installing the Smart WiFi Module Find the upper hand hinge cover of the refrigerator. Open the groove cover on the left side of the upper right hinge cover and insert the Wifi module into the USB port in the groove. - Page 19 Note: Actual product may have some structural differences, this instruction is only served as reference. Downloading the EZ SmartHome Open Android Play Store or IOS App Store in your smart phone, then enter "EZ SmartHome" in the Search bar to find the latest version. Download and install it. You can also scan the QR code below to download the latest version.
- Page 20 Never close doors while the shelves, crisper and/or telescopic slides are extended. It may damage the unit. Follow these simple instructions to remove the crisper chamber, or freezer drawer, for cleaning. Empty the crisper chamber; pull it out to fully open position.
- Page 21 Assembling After cleaning, please assemble the parts including the head, water tank and lids as follows: 1. Put the seal ring in order first (the seal ring cannot turn up), then insert the head into the hole. 2. Hold the two sides of the water tank tightly, fit the water tank along the guides on the door.
- Page 22 Receiving Water You should use the correct cups to receive water underneath the water dispenser. Warning! Don’t push the dispenser lever forward without a cup, it may cause water leakage from the dispenser. Cleaning 1. Put the water tank out of the door carefully and then wash the tank, lid, and head lightly with water.
-
Page 23: Helpful Hints And Tips
3. Place the filled ice tray back to the freezer compartment. 4. Wait for around 3 hours, twist the knobs clockwise and the ice will drop into the ice box below. 5. Ice cubes can be stored in the ice box, if you need them, you can pull out the ice box and take them out. - Page 24 Place the appliance in a well ventilated, humidity free, room. Please refer to Installing your new appliance chapter. If the diagram shows the correct combination for the drawers, crisper and shelves, do not adjust the combination as this is designed to be the most energy efficient configuration.
- Page 25 Hints for the storage of frozen food Ensure that frozen food has been stored correctly by the food retailer Once defrosted, food will deteriorate rapidly and should not be re-frozen. Do not exceed the storage period indicated by the food manufacturer.
- Page 26 You should clean the appliance interiors regularly. It will be easier to clean when food stocks are low. Wipe the inside of the fridge/ freezer with a weak solution of bicarbonate of soda, and then rinse with warm water using a wrung-out sponge or cloth.
-
Page 27: Troubleshooting
Defrosting Water contained in the food or getting into air inside the fridge by opening doors may form a layer of frost inside. It will weaken the refrigeration when the frost is thick. This appliance is a frost-free refrigerator, Automatic defrosts itself regularly, without manual defrost. - Page 28 Some food, containers or wrapping may cause odours. Noise from the The sounds below are quite normal: appliance Compressor running noises. Air movement noise from the small fan motor in the freezer compartment or other compartments. Gurgling sound similar to water boiling. Popping noise during automatic defrosting.
- Page 29 Temperature You may have left the doors open too long or opened too inside is too frequently; or the doors are kept open by some obstacle; or warm the appliance is located with insufficient clearance at the sides, back and top Temperature Increase the temperature by following the “Display controls”...
-
Page 30: Disposal Of Appliance
Disposal of the appliance It is prohibited to dispose of this appliance in domestic household waste. For disposal there are several possibilities: a) The municipality has established collection systems, where electronic waste can be disposed of at least free of charge to the user.. b) As old products contain valuable resources, they can be sold to scrap metal dealers. - Page 31 Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or making ice-cream and making ice cubes. One-, two- and three-star compartments are not suitable for the freezing of fresh food. Compartment Target storage Order Appropriate food Type temp. [ ] Eggs, cooked food, packaged food, fruits and vegetables, dairy products, cakes, Fridge...
- Page 32 Seafood (fish, shrimp, shellfish), freshwater aquatic products and meat products (recommended for 3 months, ***-Freezer the longer the storage time, the worse the taste and nutrition), are not suitable for frozen fresh food. Seafood (fish, shrimp, shellfish), freshwater aquatic products and meat products (recommended for 2 months, **-Freezer the longer the storage time, the worse...
- Page 33 Fresh pork, beef, fish, chicken, some packaged processed foods, etc. (Recommended to eat within the same 0-star -6~0 day, preferably no more than 3 days). Partially encapsulated processed foods (non-freezable foods) Fresh/frozen pork, beef, chicken, freshwater aquatic products, etc. (7 days below 0 and above 0 Chill...
-
Page 34: Warranty Terms & Conditions
Water dispenser cleaning (special for water dispenser products): Clean water tanks if they have not been used for 48 h; flush the water system connected to a water supply if water has not been drawn for 5 days. WARNING! Food needs to be packed in bags before putting into the refrigerator, and liquids need to be packed in bottles or capped containers to avoid spillages. - Page 35 defects and does not cover damages to the product resulting from unautho- rised adaptations/ adjustments/ tampering/ repair , improper installation or placement, mishandling, improper use, deviation from the instructions set out in the user manual (if applicable) normal wear and tear caused due to use of the product.
- Page 36 For any warranty claim requested by the Customer from the region beyond municipal limits of the jurisdiction of the ASC, a visit by an authorised service personnel may be arranged by the Company through its ASC, on a case to case basis, at its sole discretion and the charges towards such visit will be borne by the Customer.
- Page 37 Customer agrees that the courts at Bangalore shall have the exclusive jurisdiction to settle any dispute that may arise in relation to this Warranty or these terms and conditions. COMPANY SHALL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, PUNITIVE, EXEMPLARY, SPECULATIVE OR CONSEQUENTIAL DAMAG- ES, INCLUDING, BUT NOT LIMITED TO, ANY LOSS OF USE, BUSINESS INTERRUPTION, AND LOSS OF INCOME OR PROFITS, IRRESPECTIVE OF WHETHER IT HAD AN ADVANCE NOTICE OF THE POSSIBILITY OF ANY SUCH...
