- Page 1 PDA29BU Wireless BT Stereo Power Amplifier Blue Series Compact and Audio Streaming Amp with RCA & Speaker Terminals...
- Page 2 WARNING! CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER OF THIS UNIT. THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO A QUALIFIED TECHNICIAN. The lighting ash with arrow head symbol within an equilateral triangle is intended to alert the user to the presence of “DANGEROUS”...
-
Page 3: Important Safety Instructions
14. Before placing, installing, rigging, or suspending any product, inspect all hardware, suspension, cabinets, transducers, brackets and associated equipment for damage. Any missing, corroded, deformed, or non-load rated component could signi cantly reduce the strength of the installation, placement or array. Any such condition severely reduces the safety of the installation and should be immediately corrected. - Page 4 • When unplugging the power cord, do not pull on the cord itself but pull on the plug. • Do not install this equipment in a con ned or a built-in space. Only install the equipment in a well ventilated and open location. The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains etc.
- Page 5 1. AC 220V Power switch 2. SD card slot 3. Treble adjustment knob 4. The USB socket 5. Bass control knob 6. Function display window 7. Microphone volume control 8. Microphone 1 input jack 9. Microphone 2 input jack 10. Volume adjustment knob 11.
- Page 6 WIRELESS BT CONNECTION A. Press MODE button and enter into Wireless BT mode. Blue light will ash on the screen. B. Search for the Wireless BT device and nd the bluetooth name “PYLEUSA” or “BT”. C. Select the “PYLEUSA” or “BT” Wireless BT name and wait for the device to pair. D.
- Page 7 MP3 PLAYER REMOTE CONTROL FUNCTIONS 1. Press this button to turn ON or OFF the MP3 2. When in the FM mode, press this two buttons to select previous or next channel. 3. Press these two buttons to select the previous or next track in USB or SD or Wireless BT mode 4.
-
Page 8: What's In The Box
FEATURES: • Compact and Powerful Mini Amp System • BT Receiver for Wireless Audio Streaming Ability • RCA (L/R) Audio Input • USB/SD/FM playing • Connect & Stream Audio from External Devices • Push-Type Speaker L/R Terminals • Front Panel Rotary Controls •... -
Page 9: Technical Specs
TECHNICAL SPECS: • Power Supply: 100WX2 Max • 10% RMS at 8-Ohm Impedance: 8WX2 • Signal-to-Noise Ratio: 75dB • Frequency Response: 20Hz - 20kHz • Input Sensitivity: 200mV • T.H.D.: 0.1% • Signal-to-Noise Ratio: 75dB • Power Cable Length: 4.9’ ft. •... - Page 10 Questions? Issues? We are here to help! Phone: (1) 718-535-1800 Email: support@pyleusa.com...
