R O O M
Room placement is one of the most important factors in determining sound quality. Taking a few minutes to try different
placements ensures that your speakers will sound best in your listening environment.
For a realistic soundstage, place the speakers 6 to 12 feet (2-4m) apart so they form a triangle with your favorite
listening position, and are near ear level when you are in a seated position. The speakers should be at least 2 feet (.6m)
from the corners of the room. Putting the speakers too close to a corner can produce an unnatural bass reinforcement that
detracts from their balanced, uncolored sound. If a speaker must be placed near a corner, move it away from the wall
behind it to preserve its natural tonal balance.
The CR Series will work well on bookshelves or stands. For best results, avoid placing the speaker's back flush against
a wall, since this will restrict the air flow from the port and reduce the bass response. Clearance of
is sufficient to maintain proper bass response.
Four self-adhesive rubber feet are provided to protect the mounting surface finish and prevent vibration.
W A L L
You may wall-mount the CR6 and CR7 with either the keyhole built into the back
panel or the optional CRB bracket.
Using the keyhole– Consult a knowledgeable installer regarding the proper
hardware to use on your wall surface. Make certain there is at least a
(12mm) gap between the top rear of the speaker cabinet and the wall behind it.
This will ensure the speaker is the proper distance from the wall to maintain
unrestricted air flow from the woofer port.
Using the optional CRB bracket– Wall mounting brackets (model "CRB")
are available for the CR6 and CR7. The brackets provide greater mounting
flexibility than the keyhole and will position the speaker the proper distance from
the wall. For more information, contact your dealer or Boston Acoustics directly.
L I S T E N I N G
The power recommendation for the Compact Reference Series assumes you will operate the amplifier in a way that will not
produce distortion. Even these rugged systems can be damaged by an amplifier if it is producing distortion.
If you hear a harsh, gritty noise, turn the volume down. Prolonged or repeated operation of your speaker with a
distorted signal from the amplifier can cause damage that is not covered by the warranty.
Frequency Response (±3 dB)
Recommended Amplifier Power 15-100 watts
Nominal Impedance
Sensitivity [1 watt (2.83V) at 1m]
Bass Unit
Tweeter
Crossover Frequency
Dimensions
Weight
P L A C E M E N T
M O U N T I N G
S P E A K E R S
L E V E L S
S P E C I F I C A T I O N S
CR6
CR6
65-20,000 Hz
8 ohms
88 dB
5 " (135mm)
1
/
4
" (19mm) dome
3
/
4
3500 Hz
10 1 x 5 7 x 7 7 "
/ / /
8 8 8
(257 x 149 x 200mm) (311 x 191 x 232mm) (381 x 216 x 267mm)
7 1 lbs (3.4kg)
/
2
F O R B E S T
Y O U R
- inch
1
/
2
A N D P O W E R
CR7 CR8 CR9
CR7
52-20,000 Hz
15-100 watts
8 ohms
88 dB
6 " (165mm)
1
/
2
" (19mm) dome 1" (25mm) soft dome 1" (25mm) soft dome
3
/
4
2800 Hz
12 1 x 7 1 x 9 1 "
/ / /
4 2 8
11 lbs (5kg)
R E S U L T S
1 - inch (12mm) or more
/
2
approximately
1
/
2
Self-adhesive rubber feet prevent
marring of the walls surface
H A N D L I N G
CR8
48-20,000 Hz 42-20,000 Hz
15-125 watts 15-150 watts
8 ohms
90 dB
7" (180mm)
3300 Hz
5 x 8 1 x 10 1 " 9 1
/ / /
2 2
(495 x 248 x 289mm)
16 lbs (7.3kg) 21 lbs (9.5kg)
-inch (12mm)
CR9
8 ohms
91 dB
8" (200mm)
3300 Hz
x 9 3 x 11 3 "
/ /
2 4 8
