Harbor Freight Tools Bauer 21505C-B Owner's Manual & Safety Instructions

Hide thumbs

Advertisement

Quick Links

Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
For Best results,
use 3.0 amp Hour Battery
(Sold Separately)
email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2020 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
21b

Advertisement

loading

Summary of Contents for Harbor Freight Tools Bauer 21505C-B

  • Page 1 No portion of this manual or any artwork contained herein may be reproduced in Failure to do so can result in serious injury. any shape or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing SAVE THIS MANUAL.

  • Page 2: Table Of Contents

    table of contents Safety ..........2 Maintenance ........10 Specifications ........7 Parts List and Diagram ......11 Setup ..........7 Warranty ..........12 Operation ..........8 WarninG SyMBOLS anD DeFinitiOnS This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

  • Page 3: Safety

    electrical Safety Do not expose power tools to rain or wet conditions. personal Safety 1. Stay alert, watch what you are 3. prevent unintentional starting. doing and use common sense when ensure the power Switch is in the operating a power tool. Do not use off-position before connecting a power tool while you are tired or to power source, picking up or...
  • Page 4 2. The Nozzle becomes very hot. Do not If unreadable or missing, contact lay the Glue Gun on flammable surfaces Harbor Freight Tools for a replacement. when operating the Gun or immediately after turning the Gun off. Always set the 8.
  • Page 5 The battery Charger gets hot 11. This product is not a toy. during use. The Charger’s heat Keep it out of reach of children. can build up to unsafe levels and 12. People with pacemakers should create a fire hazard if it does not consult their physician(s) before use.
  • Page 6 Grounding tO preVent eLectric SHOcK anD DeatH FrOM incOrrect GrOunDinG: check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. Do not modify the power cord plug provided with the charger. Do not use the charger if the power cord or plug is damaged. if damaged, have it repaired by a service facility before use.

  • Page 7: Specifications

    Specifications Battery Type Bauer 20V Li-ion 64816 (sold separately) Charger Type Bauer 20V Li-ion 63947 (sold separately) Maximum Temperature 455°F (Internal Nozzle) Glue Stick Diameter Ø11 (sold separately) Setup - Before use: read the entire iMpOrtant SaFety inFOrMatiOn section at the beginning of this manual including all text under subheadings therein before set up or use of this product.

  • Page 8: Operation

    Operating instructions read the entire iMpOrtant SaFety inFOrMatiOn section at the beginning of this manual including all text under subheadings therein before set up or use of this product. charging Battery pack Charge battery before using this tool. Follow instructions included with battery charger ( sold separately).
  • Page 9 8. When the glue stick cannot not move forward, 10. To prevent accidents, turn off the Glue Gun insert a new glue stick behind it. Use the by pressing the Power Switch. The glue stick until it is completely used up. Work Light and LED should turn off.

  • Page 10: Maintenance

    Maintenance and Servicing procedures not specifically explained in this manual must be performed only by a qualified technician. tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn: remove Battery pack before performing any inspection, maintenance, or cleaning procedures. tO preVent SeriOuS inJury FrOM tOOL FaiLure: Do not use damaged equipment.

  • Page 11: Parts List And Diagram

    parts List and Diagram part Description part Description Left Housing O-Ring Lamp Shade Spacer Power Switch Steel Ball PCBA Spring Ring Nozzle Slide Rest Sleeve Straight Pin Extension Spring Insert Frame Fixed Mount Trigger Joint Pipe Aluminum Plate Spring Coil Hose Cylindrical Plug Pressing Buckle...

  • Page 12: Warranty

    OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
