All manuals and user guides at all-guides.com CANADA : http//biz.lgservice.com : http//www.lgservice.com : http//lgservice.com/techsup.html PLASMA TV SERVICE MANUAL CHASSIS : AF-044P MODEL : DU-50PY10 CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. POWER TV GUIDE TV/VIDEO...
Page 2
An other abnormality exists that must be corrected before the receiver is returned to the customer. CANADA: LG Electronics Canada, Inc. 550 Matheson Boulevard East Mississauga, Ontario L4Z 4G3 : LG Customer Interactive Center P.O.Box 240007, 201 James Record Road Huntsville,...
All manuals and user guides at all-guides.com TABLE OF CONTENTS DESCRIPTION OF CONTROLS ...........4 SPECIFICATIONS..............7 ADJUSTMENT INSTRUCTIONS ..........8 PRINTED CIRCUIT BOARDS ..........18 BLOCK DIAGRAM...............24 EXPLODED VIEW...............26 EXPLODED VIEW PARTS LIST .........27 REPLACEMENT PARTS LIST ..........28 SCHEMATIC DIAGRAM............- 3 -...
All manuals and user guides at all-guides.com DESCRIPTION OF CONTROLS Controls Controls - This is a simplified representation of front panel. Here shown may be somewhat different from your TV. Front Panel Controls Front Panel Controls INDEX Switches LED Display T T ruSurround XT ruSurround XT on or off.
Page 5
This TV operates on an AC power. The voltage is indi- input port. cated on the Specifications page. Never attempt to oper- ate the TV on DC power. - This manual explains the features available on the DU-50PY10 series TVs. - 5 -...
Page 6
All manuals and user guides at all-guides.com DESCRIPTION OF CONTROLS Remote Control Key Functions Remote Control Key Functions - When using the remote control, aim it at the remote control sensor on the TV. MODE LIGHT Selects the remote operating mode: TV, Illuminates the remote control buttons.
All manuals and user guides at all-guides.com ADJUSTMENT INSTRUCTIONS 1. Application Object 4. Gemstar VBI Micom Download These instructions are applied to all of the PDP TV, AF-044P. 4-1. Preparation for Adjustment (1) As shown below, connect the MPLAB ICD2 equipment, PC and Digital Connector.
Page 9
All manuals and user guides at all-guides.com ADJUSTMENT INSTRUCTIONS (4) Select "Programmer -> Connect". (8) The execution of process (6) is convenient when using the short-cut icon. When connected with the Micom, the display message on 5. Gemstar IR Micom Download the Output window appears as below.
Page 10
All manuals and user guides at all-guides.com ADJUSTMENT INSTRUCTIONS (3) When the "Select Device" window appears, select the (6) Select "Programmer -> Program". PIC18F242 from "Device" and press OK. (7) Download is executed and about 3 seconds later, the "Programming succeeded" message is displayed on the Output window and the Download process is ended.
Page 11
All manuals and user guides at all-guides.com ADJUSTMENT INSTRUCTIONS (2) Select ‘Connection’ and SET connected to RS-232C. (6) When the Dialog window appears, click OK and the write (3) After clicking "Enter", confirm that "Enter Password:" work will begin. appears. (7) When completed, click ‘CP Data Download: OK’...
Page 12
All manuals and user guides at all-guides.com ADJUSTMENT INSTRUCTIONS [ When process (11) malfunctions, it is not Download. (9) After opening the ‘DTCP.dat’ file, confirm the key list in the DTCP Key List window. DTCP Download process start again from (8). 7.
Page 13
All manuals and user guides at all-guides.com ADJUSTMENT INSTRUCTIONS (5) Confrim that VBI Test, Glink Test and IR Test PASS from the screen. 8. Cable Operation Confirmation (1) Confirm that the Cable Card is inserted in the slot. (2) Enter the EZ adjust menu by pressing Adjust on the Service Remote Control (S R/C).
Page 14
All manuals and user guides at all-guides.com ADJUSTMENT INSTRUCTIONS 9-3. Adjustment (42”, 50”) Each PCB Assy must be checked by Check JIG Set before assembly. (Especially, be careful Power PCB Assy which can (1) Va Adjustment cause Damage to the PDP Module.) 1) Connect + terminal of D.M.M to Va pin of P805 and connect –...
Page 15
All manuals and user guides at all-guides.com ADJUSTMENT INSTRUCTIONS (4) 3.4V Adjustment 10-2. EDID DATA(50”, 60”) 1) Connect + terminal of D.M.M to 3.4V pin of P800B and EDID for HDMI (DDC (Display Data Channel) Data) connect – terminal to GND pin of P800B. EDID table = 2) Adjust VR8801 voltage to be 3.4V.
Page 16
All manuals and user guides at all-guides.com ADJUSTMENT INSTRUCTIONS 11-3. Adjustment _____________________________________________________ (1) Select Component1 or Component2 as the input with 0 | 02 03 13 F2 44 84 85 03 02 23 15 07 50 65 03 0C 100% Vertical Color Bar Pattern in 720p Mode and select 10 | 00 10 00 8C 0A D0 8A 20 E0 2D 10 10 3E 96 00 C4 ‘Normal’...
Page 17
All manuals and user guides at all-guides.com ADJUSTMENT INSTRUCTIONS [ [ . RS-232C Command 13. Main/Sub Contrast Adjustment (Automatic Adjustment) Main/Sub contrast adjustment reduces the contrast difference RS-232C Command CENTER of Main/Sub screen in PIP/POP/SPLIT Screen. [CMD ID DATA] (DEFAULT) (1) After receiving signal for at least 1 second, press the ADJ R Gain ja oo XX...
Page 29
All manuals and user guides at all-guides.com REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION Q102 0TR150400BA CHIP 2SA1504S(ASY) KEC Q306 0TR387500AA CHIP 2SC3875S(ALY) KEC 0TR387500AA CHIP 2SC3875S(ALY) KEC 0TR387500AA CHIP 2SC3875S(ALY) KEC Q103 Q307 Q103 0TR387500AA CHIP 2SC3875S(ALY) KEC...
Page 30
All manuals and user guides at all-guides.com REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION DL1201 0DL233309AC LED,SAM2333 C1232 0CE476SF6DC 47UF MVG 16V M 0DL233309AC LED,SAM2333 0CE476SF6DC 47UF MVG 16V M DL1202 C1234 DL301 0DL233309AC LED,SAM2333 C1235 0CE476SF6DC...
Page 31
All manuals and user guides at all-guides.com REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION C255 0CE476SF6DC 47UF MVG 16V M C443 0CE476SF6DC 47UF MVG 16V M 0CE476SF6DC 47UF MVG 16V M 0CE476SF6DC 47UF MVG 16V M C260 C446 C264...
Page 32
All manuals and user guides at all-guides.com REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION C621 0CE226SF6DC 22UF MVG 16V 20% L308 6140VR0006A COIL,ENERGY RECOVERY 100UH(+-15%) 0CE226SF6DC 22UF MVG 16V 20% 6140VR0006A COIL,ENERGY RECOVERY 100UH(+-15%) C622 L309 C623...
Page 33
All manuals and user guides at all-guides.com REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION AR602 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% IC605 6200C000012 FILTER,B.P. TH355LSK-K5218 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% 6210VC0006A FILTER,EMC FBMH3216 HM501NT AR603...
Page 34
All manuals and user guides at all-guides.com REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION L404 6210VC0006A FILTER,EMC FBMH3216 HM501NT MISCELLANEOUS 6210VC0006A FILTER,EMC FBMH3216 HM501NT L404 L405 6210VC0006A FILTER,EMC FBMH3216 HM501NT F801 0FS1002B53K FUSE,SLOW BLOW 10000MA 250V L406 6210VC0005A FILTER,EMC BK2125 HS 750...
Page 35
All manuals and user guides at all-guides.com Aug., 2004 P/NO : 3828VD0177G Printed in Korea CANADA: LG Electronics Canada, Inc. 550 Matheson Boulevard East Mississauga, Ontario L4Z 4G3 : LG Customer Interactive Center P.O.Box 240007, 201 James Record Road Huntsville,...
