SERVICE MANUAL
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
With 3.2 Ω loads, both channel driven from 250 – 6,300 Hz; rated 2W per
channel-minimum RMS power, with no more than 10 % total harmonic
distortion in AC operation.
Other Specifications
CD player section
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wave length:780 nm
Emission duration : Continuous
Laser output : Less than 44.6 µW
(This output is the value measured at a distance
of about 200 mm from the objective lens surface
on the optical pick-up block with 7 mm
aperture.)
Spindle speed
200 r/min (rpm) to 500 r/min (rpm) (CLV)
Number of channels
2
Frequency response
20 – 20,000 Hz + 3/-3 dB
Wow and flutter
Below measurable limit
Radio section
Frequency range
FM : 87.6 – 108 MHz
AM : 530 – 1,710 kHz
Aerials
FM : Telescopic aerial
AM : Built-in ferrite bar aerial
MICROFILM
CFD-Z125/Z135
Photo: CFD-Z135
CD
Section
Tape deck
Section
SPECIFICATIONS
Model Name Using Similar Mechanism NEW
CD Mechanism Type
Optical Pick-up Name
Model Name Using Similar Mechanism NEW
Tape Transport Mechanism Type
Cassette-corder section
Recording system
4 -track 2 channel stereo
Fast winding time
Approx. 110 s (sec.) with Sony cassette
C-60
TYPE Ι (normal) : 80 – 10,000 Hz
Frequency response
General
Full range : 10 cm (4 in) dia., 3.2 Ω, cone
Speakers
type (2)
Outputs
Headphones jack (stereo minijack)
For 16 – 68 Ω impedance headphones
Power output (excluding US model)
2.3 W + 2.3 W (at 3.2 Ω, 10 % harmonic
distortion in DC operation)
Power requirements
For CD radio cassette-corder :
120V AC, 60 Hz
9V DC, 6 size D (R20) batteries
For remote (CFD-Z135 only) :
3V DC, 2 size AA (R6) batteries
Power consumption
AC 19W
CD RADIO CASSETTE-CORDER
US Model
CFD-Z125/Z135
E Model
CFD-Z135
KSM-213CDM/Z-NP
KSS-213C/Z-N
MF-Z125
— Continued on next page —

Advertisement

Table of Contents
loading

Summary of Contents for Sony CFD-Z125

  • Page 1 Recording system 4 -track 2 channel stereo channel-minimum RMS power, with no more than 10 % total harmonic Fast winding time Approx. 110 s (sec.) with Sony cassette distortion in AC operation. C-60 TYPE Ι (normal) : 80 – 10,000 Hz...
  • Page 2: Table Of Contents

    ···························································· 3 FM recording 2. GENERAL ·········································································· 4 Sony R20P : approx. 7 h Sony alkaline LR20 : approx. 14.5 h 3. DISASSEMBLY Tape playback 3-1. Rear Cabinet ······································································· 9 Sony R20P : approx. 3.5 h 3-2. CD Block ·········································································· 10 Sony alkaline LR20 : approx.
  • Page 3: Service Notes

    SECTION 1 SERVICE NOTES CHUCK PLATE JIG ON REPAIRING LASER DIODE AND FOCUS SEARCH OPERATION CHECK On repairing CD section, playing a disc without the CD lid, use 1. Turn POWER switch on with no disc inserted and make Function Chuck Plate Jig.
  • Page 4: General

    SECTION 2 This section is extracted from instruction manual. GENERAL — 4 —...
  • Page 5 — 5 —...
  • Page 6 — 6 —...
  • Page 7 — 7 —...
  • Page 8 — 8 —...
  • Page 9: Disassembly

    SECTION 3 DISASSEMBLY • This set can be disassembled in the order shown below. OPTICAL OPTICAL CD DECODER MAIN BOARD, REAR CABINET CD BLOCK PICK-UP PICK-UP SP TERMINAL BOARD BOARD, (Page 10) (Page 9) SECTION (Page 12) LAMP BOARD (Page 10) (Page 11) (Page 11) FRONT BOARD,...
  • Page 10: Cd Block

    3-2. CD BLOCK 3 Screws 5pcs (+BTP 3 × 12) 4 CD Block 2 CN302 1 CN305 3-3. MAIN BOARD, SP TERMINAL BOARD 5 SP TERMINAL Board 4 MAIN Board 1 CN303 3 Screws 3pcs (+BTP 3 × 12) 2 CN07 —...
  • Page 11: Cd Decoder Board, Lamp Board

    3-4. CD DECODER BOARD, LAMP BOARD 1 CN801 6 CD DECODER Board Remove solder 8 CN706 9 LAMP Board (Z135 only) 2 CN701 3 CN802 3 CN703 7 Two claws 5 Lag 4 Screws 2pcs (+BTP 3 × 10) 3-5. OPTICAL PICK-UP SECTION (KSM-213CDM/Z-NP) 2 Optical Pick-up...
  • Page 12: Optical Pick-Up (Kss-213C/Z-N)

    3-6. OPTICAL PICK-UP 7 Optical Pick-up (KSS-213C/Z-N) (KSS-213C/Z-N) 1 Two claws 2 CD Pick-up Cover 4 A gear 3 Claw 1 Two claws 5 Claw 6 Sled shaft 3-7. MOTOR BOARD, SLED MOTOR (M702) 3 Screws 2pcs (+P 2 × 3) 4 Sled motor (M702) 2 MOTOR Board 1 Remove...
  • Page 13: Front Board, Sensor Board

    3-8. FRONT BOARD, SENSOR BOARD 8 Earth wire 1 CN003 !¡ SENSOR board (Z135 only) 6 Three claws 3 Two claws 2 CN303 7 Remove solder 0 Remove solder 9 FRONT board 5 Screws 3pcs 3 Two claws (+BTP 3 × 10) 4 Function button 3-9.
  • Page 14: Belt, Capstan/Reel Motor (M601)

    3-10. BELT, CAPSTAN/REEL MOTOR (M601) 7 Capstan/reel motor 1 Remove solder (M601) 2 Screw 3 Claw (MB) 6 Motor bracket 5 Screws 2pc (Motor collar) 4 Main belt 3-11. CASSETTE DOOR 2 Two claws 2 Two claws 1 Press the eject ( p 6 ) button 3 Remove the Cassette door to direction of the arrow A —...
  • Page 15: Dial Pointer Setting

    SECTION 4 DIAL POINTER SETTING Note : Follow the disassembly procedure in the numerical order given. 2 Two screws (+BTP3 × 12) 3 Setting the dial pointer. Dial pointer 4 Rotate the dial drum fully in direction of the arrow A . 5 MAIN board Claw 1 Tuning knob holder ass`y...
  • Page 16: Adjustments

    SECTION 5 ADJUSTMENTS 5-1. MECHANICAL ADJUSTMENT 5-2. ELECTRICAL ADJUSTMENT PRECAUTION TAPE DECK SECTION 0 dB = 0.775V 1. Clean the following parts with a denatured-alchool-moistened swab: 1. The adjustments should be perfomed in the order given in the record/playback head pinch roller service manual.
  • Page 17 3. Phase Check Tape Speed Adjustment Mode: playback Procedure : Mode : Playback test tape speed checker test tape P-4-A063 LFM-30 or WS-48B oscilloscope L-CH (6.3kHz, –10dB) digital frequency 32 Ω (3kHz, 0dB) L-CH counter 3.2 Ω – 32 Ω R-CH SPEAKER Terminal R-CH...
  • Page 18: Tuner Section

    TUNER SECTION VCO Adjustment Procedure: [AM] FM RF SSG FM telescopic AM RF SSG Put the lead-wire antenna terminal antenna close to 0.01 µ F the set. Carrier frequency : 98MHz Modulation : no modulation 30% amplitude modulation by 400Hz Output level : 0.1V (100dB) signal.
  • Page 19 Adjustment Locastion: AM Frequency Coverage Adjustment AM Tracking Adjustment [MAIN BOARD] (Component Side) FM Tracking Adjustment RV1 VCO Adjustment FM Frequency Coverage Adjustment AM IF Adjustment AM Tracking Adjustment — 19 —...
  • Page 20: Cd Section

    CD SECTION Before Begining Adjustment Put the set into test mode and perform the following checks. Notes on Adjustment Repair if there are any problems. Perform adjustment in test mode. After adjustment, be sure to release test mode. • Sled Motor Check Press ±...
  • Page 21 E-F Balance Adjustment Focus Bias Adjustment This adjustment is to be done when the optical pick-up is replaced. This adjustment is to be done when the optical pick-up is replaced. Procedure: Procedure: oscilloscope oscilloscope (DC range) (AC range) CD DECODER board CD DECODER board TP702 pin 1 IC701 pin #¡...
  • Page 22 Adjustment Location: [CD DECODER BOARD] (Component Side) VR701 Focus Bias Adjustment TP701 25 31 36 IC701 VR702 E-F Balance Adjustment TP702 LCD801 — 22 —...
  • Page 23: Diagrams

    SECTION 6 DIAGRAMS 6-1. CIRCUIT BOARDS LOCATION 6-2. BLOCK DIAGRAM FM-IFT ANT901 TELESCOPIC ANTENNA MUTE SWITCH BAND MUTE IC301 FM/AM MOTOR board PRE AMP RF IN FE OUT FM IF FRONT END L-OUT IC351 IC302 RADIO FM/AM GRAPHIC EQ. VOLUME IC303 CD DECODER R-OUT...
  • Page 24: Printed Wiring Board -Cd Section

    CFD-Z125/Z135 • IC Block Diagrams 6-3. PRINTED WIRING BOARD — CD SECTION — • See page 23 for Circuit Boards Location. — CD SECTION — IC702 CXD2508AQ • Semiconductor Location Ref. No. Location IC701 CXA1782BQ 73 74 D701 D704 EMPHI...
  • Page 25: Schematic Diagram - Cd Section

    CFD-Z125/Z135 6-4. SCHEMATIC DIAGRAM — CD SECTION — • See page 47 for IC Pin Function. • See page 27 for IC Block Diagrams. • Waveforms 1msec/div !¡ 0.1µsec/div IC701 1 (FEO) IC702 $§ (BCK), $¶ (BCK1) IC801 @∞ (CF IN) 1V/div 0.2V/div...
  • Page 26: Schematic Diagram - Main Section

    CFD-Z125/Z135 6-5. SCHEMATIC DIAGRAM — MAIN SECTION — • See page 42 for IC Block Diagrams. • Waveforms Q303 Bass (REC mode) 10msec/div 1V/div 3.2Vp-p L301 1, 2 (REC mode) 10msec/div 2V/div 9.2Vp-p Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums.
  • Page 27: Printed Wiring Board -Main Section

    CFD-Z125/Z135 6-6. PRINTED WIRING BOARD — MAIN SECTION — • See page 23 for Circuit Boards Location. • Semiconductor • IC Block Diagrams Location — MAIN SECTION — Ref. No. Location IC302 M62429P D301 D302 D303 D304 D305 D306 D307...
  • Page 28: Printed Wiring Board -Front Section

    CFD-Z125/Z135 6-7. PRINTED WIRING BOARD — FRONT SECTION — • See page 23 for Circuit Boards Location. 6-8. SCHEMATIC DIAGRAM — FRONT SECTION — Note on Schematic Diagram: • Power voltage is dc 9 V and fed with regulated dc power •...
  • Page 29: Ic Pin Function Description

    REM IN FUNCTION SW A Mega bass 1 control signal output terminal “H”: on Not used (open). Not used only (CFD-Z125 is not used) FUNCTION SW B Mega bass 2 control signal output terminal “H”: on Not used (open). Not used...
  • Page 30: Exploded Views

    SECTION 7 EXPLODED VIEWS NOTE: 7-2. FRONT PANEL SECTION • -XX, -X mean standardized parts, so they may • The mechanical parts with no reference number When indicating parts by reference number, have some differences from the original one. in the exploded views are not supplied. please include the board name.
  • Page 31: Cd Block Section

    7-3. CD BLOCK SECTION S702 Z135 not supplied not supplied Z135 KSM213CDM Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks * 101 3-014-413-01 DRUM, DIAL 1-452-732-11 MAGNET 1-782-391-11 LEAD, CONNECTOR (300MM) 5P * 117 3-013-775-01 PLATE, MAGNET * 103 3-013-704-01 SPACER, LEVER (SW) 3-013-667-01 WINDOW, CD DOOR...
  • Page 32: Optical Pick-Up Section (Ksm-213Cdm/Z-Np)

    7-4. OPTICAL PICK-UP SECTION (KSM-213CDM/Z-NP) not supplied M701 M702 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks ! 151 8-848-483-05 OPTICAL, PIC-UP KSS-213C/Q-RP * 155 1-639-678-12 MOTOR BOARD 2-626-907-01 GEAR (A) X-2626-202-1 CHSSIS ASSY (MB) (RP), MOTOR 2-627-003-02 GEAR (B) (RP) (INCLUDING M701) (SPINDLE) 2-626-908-01 SHAFT, SLED...
  • Page 33: Mechanism Deck Section-1

    7-5. MECHANISM DECK SECTION-1 (MF-Z125) HE901 HRP901 M601 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 3-014-765-01 FLYWHEEL 3-014-757-01 M CONTROL SPRING 3-014-779-01 C SCREW 2 × 3 3-014-763-01 F BELT (W) 3-014-755-01 HEAD BASE * 219 3-014-778-01 PACK SPRING PLATE 3-014-783-01 SCREW 2 ×...
  • Page 34: Mechanism Deck Section-2

    7-6. MECHANISM DECK SECTION-2 (MF-Z125) S302 S307 S301 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 3-014-780-01 C SCREW 2 × 4 3-915-740-01 BASE ASSY (A) 3-014-759-01 P ARM COLLAR 3-915-752-01 SPRING, P CONTROL 3-014-758-01 RECORD ARM 3-014-744-01 LEVER (F), PAUSE 3-014-749-01 PS LEVER SPRING 3-014-745-01 P LEVER SPRING...
  • Page 35: Speaker Section

    7-7. SPEAKER SECTION SP101,SP201 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks * 304 3-012-998-11 CABINET (L), SPEAKER (BACK) 3-013-683-01 EMBLEM * 304 3-012-999-11 CABINET (R), SPEAKER (BACK) X-3375-655-1 CABINET ASSY, FRONT 3-013-666-01 RETAINER, SPK WIRE 3-012-996-11 PANEL, SPEAKER (FRONT) SP101 1-505-953-11 SPEAKER (4 INCH 2.3W)
  • Page 36: Electrical Parts List

    BATTERY (A) BATTERY (B) SECTION 8 CD DECODER ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in the • RESISTORS When indicating parts by reference number, parts list may be different from the parts All resistors are in ohms. please include the board name.
  • Page 37 CD DECODER Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C889 1-161-494-00 CERAMIC 0.022uF R706 1-249-430-11 CARBON 1/4W C891 1-126-382-11 ELECT 100uF R707 1-249-430-11 CARBON 1/4W C892 1-162-201-31 CERAMIC 12PF R708 1-249-430-11 CARBON 1/4W C893 1-162-201-31 CERAMIC 12PF R709 1-249-430-11 CARBON...
  • Page 38 CD DECODER FRONT Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R776 1-247-855-11 CARBON 1/4W C258 1-162-306-11 CERAMIC 0.01uF R777 1-249-427-11 CARBON 6.8K 1/4W F C259 1-126-956-11 ELECT 0.1uF R778 1-247-847-11 CARBON 4.7K 1/4W C262 1-162-286-31 CERAMIC 220PF R779 1-249-409-11 CARBON...
  • Page 39 LAMP LEAF SW MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 1-670-118-11 LAMP BOARD (Z135) 1-162-205-31 CERAMIC 18PF C101 1-126-963-11 ELECT 4.7uF *********** C102 1-162-282-31 CERAMIC 100PF 3-014-417-01 COVER, LED C103 1-126-963-11 ELECT 4.7uF 3-014-418-01 CAP (BLUE), LAMP C104 1-162-282-31 CERAMIC 100PF...
  • Page 40 MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C328 1-128-548-11 ELECT 4700uF < COIL > C329 1-106-383-00 MYLAR 0.047uF 200V C330 1-126-964-51 ELECT 10uF 1-416-273-11 COIL, FM RF C331 1-126-964-51 ELECT 10uF 1-416-274-11 COIL, SPRING 1-501-926-11 ANTENNA, MW FERRITE-ROD <...
  • Page 41 MAIN MOTOR POWER Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R103 1-247-843-11 CARBON 3.3K 1/4W < VARIABLE RESISTOR > R104 1-249-403-11 CARBON 1/4W F R106 1-249-432-11 CARBON 1/4W 1-225-473-11 RES, ADJ 20K R109 1-247-855-11 CARBON 1/4W R112 1-247-847-11 CARBON...
  • Page 42 CFD-Z125/Z135 POWER SENSOR SP TERMINAL Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < RESISTOR > ACCESSORIES & PACKING MATERIALS ******************************* R901 1-249-420-11 CARBON 1.8K 1/4W F 1-475-922-11 REMOTE CONTROL (RMT-CZ135A) (Z135) < TRANSFORMER > 1-782-401-11 CORD, POWER (US)
