adJUsTiNg ThE VElOciTY
when using your Geo, you may wish to change the
velocity at which your Geo is firing. this is done by
inserting a 1/8" hex key into the adjuster screw at the
bottom of your Geo inline regulator and adjusting it
accordingly
(sEE FigUrE 7.1).
by turning this adjuster
screw clockwise you decrease the output pressure of
the inline regulator and consequently the velocity,
by turning the adjuster screw counter clockwise you
increase the output pressure of the inline regulator
and consequently the velocity.
NOTE: After eAch Adjustment fire two cleArinG
shots to GAin An AccurAte velocity reAdinG.
never exceed 300fps.
adJUsTiNg ThE FiriNg
chaMBEr VOlUME
when using your Geo you may wish to change the
volume of your firing chamber using the prop shaft
Adjuster screw located in the rear of the prop shaft
.
FigUrE 7.2)
this is easily done by inserting a 1/8" hex key into the
prop shaft Adjuster screw and adjusting it accordingly.
by turning the prop shaft Adjuster screw clockwise
you decrease the volume of the firing chamber and
consequently you will need to increase the output
pressure from your inline regulator to achieve
velocities similar to the ones you had prior to adjusting
the prop shaft Adjuster screw. by turning the prop
shaft Adjuster screw counter clockwise you increase
the volume of the firing chamber and consequently
you will need to decrease the output pressure from
your inline regulator to achieve velocities similar to the
ones you had prior to adjusting the prop shaft Adjuster
screw.
NOTE: After eAch Adjustment fire two cleArinG
shots to GAin An AccurAte velocity reAdinG.
22.
never exceed 300fps.
(sEE
Fig 7.1
Fig 7.2
UsEr iNTErFacE
the Geo has a simple user interface through which
all aspects of it's electronic control system can be
monitored and adjusted by means of the three
pushbuttons and graphical lcd which comprise the
navigation console.
swiTchiNg ON
to switch on the Geo press the
button twice in
quick succession, referred to elsewhere in this manual
as 'double-clicking' . the Geo can also be switched on
by pushing and holding the
button. the lcd will
display startup information including model number
and software version before displaying the run screen.
to skip the startup information simply press the
button.
rUN scrEEN laYOUT
the root of the user interface is the run screen. this
screen is the one most often displayed and provides
the user with essential feedback on the state of the
Geo. A typical run screen is shown on the right.
on the left of the screen is a display option that is user
selectable from the main menu (see page 33).
this option can be:-
> a gaME TiMEr
> a shOT cOUNTEr
> aN aVEragE raTE OF FirE iNdicaTOr
> a pEaK raTE OF FirE iNdicaTOr
briefly pressing the
button will replace the display
option with the name of the currently selected preset
(see page 37), or custom if a parameter of the selected
preset mode has been edited.
on the right of the screen are up to five icons, each of
which provides graphical indication on different parts
of the Geo control electronics.
BrEaK BEaM sENsOr sYsTEM
iNdicaTOr
sOUNd iNdicaTOr
TriggEr dETEcTiON
iNdicaTOr
UsEr sElEcTaBlE displaY
OpTiON
lOcK iNdicaTOr
BaTTErY lEVEl iNdicaTOr
