- Page 1 NUOVA PANDA Quick guide to Repairs...
-
Page 2: Table Of Contents
5. Vehicle towing/lifting 5.1 Towing attachment points 5.2 General warnings for towing 5.3 Vehicle lifting points 6 . T e c hni c al sp ec i fi cat i o ns 6.1 Tyre pressure (bar) 6.2 Fluids NUOVA PANDA Contents... -
Page 3: E H I Cl E I D Ent I F I Cat I On D Ata
Maximum permitted weight of vehicle fully laden plus trailer. Maximum permitted weight on first axle (front). Maximum permitted weight on second axle (rear). Engine type. Bodywork version code. Spare part number. Correct value of smoke coefficient (for diesel engines). NUOVA PANDA Vehicle identification data... -
Page 4: El Ec Tr Ic Al S Y St E M
Current socket/cigar lighter Fuel pump Engine management system (primary loads) (1.2 8V version) / Engine Management Node (0.9 TwinAir 65/85 HP and 1.3 MJet versions) / LPG gas control unit (injector supply) / Engine Management Node (CNG version) NUOVA PANDA Electrical system... - Page 5 Relay switch 2 for starting management with Start&Stop system from Engine Control Node 30 (micro) Relay switch for LPG supply / Methane system supply and regulation relay switch (CNG version) 20 (micro) Fuel pump 30 (micro) Heated blow-by 20 (micro) Heated diesel filter (1.3 MJet version) 30 (micro) NUOVA PANDA Electrical system...
-
Page 6: Dashboard
INT power supply for Radio Receiver Node, voltage stabiliser, Convergence Node, Climate Control Node, brake pedal switch (NC contact), clutch pedal switch, electric sun roof, reverse light switch (versions with robotised gearbox only) +30 power supply for Instrument Panel Node NUOVA PANDA Electrical system... -
Page 7: Luggage Compartment Control Unit
Fuses Ampere Free Free Free City Brake Control system (LSCM with Start&Stop) Free Free Free Free User Relay Ampere switches Right front heated seat Free Left front heated seat City Brake Control system (LSCM with Start&Stop) NUOVA PANDA Electrical system... -
Page 8: Battery Positive Terminal Wiring
BATTERY A010 ALTERNATOR A020 STARTER Battery negative terminal wiring With Start&Stop Without Start&Stop Component code Name A001 BATTERY A005 TERMINAL BOX C002 BATTERY EARTH ON ENGINE C003 BATTERY EARTH ON BODY K059 BATTERY CHARGE STATUS SENSOR NUOVA PANDA Electrical system... -
Page 9: Emergency P Rocedures
Never connect the negative lead (–) of the auxiliary battery to the negative pole A of the vehicle battery, connect it to an earth point of the engine/gearbox. • start the engine; • when the engine has been started, remove the leads reversing the order above. NUOVA PANDA Emergency procedures... -
Page 10: Fuel Cut-Off
• deactivate the right direction indicator; • activate the left direction indicator; • deactivate the left direction indicator; • turn the ignition key to STOP. Emergency starting with CODE CARD Procedure not envisaged. NUOVA PANDA Emergency procedures... -
Page 11: I N Ter Ve N Tio N S Wi T H Flat Batt Ery
Take the Allen key provided from the tool box (in the luggage compartment) or from the glove compartment • fit the wrench into the seat A and turn it: clockwise to open the roof anticlockwise to close the roof. NUOVA PANDA Interventions with flat battery... -
Page 12: Tailgate Emergency Opening
• remove the rear head restraints and fully fold the seats; • remove the protective cap and release the lock using a screwdriver or the metal insert NUOVA PANDA Interventions with flat battery... -
Page 13: Robotised Gearbox - Engagement Of Neutral
• pressing the brake pedal, turn the key to MAR-ON; • wait for five seconds and turn the key to STOP; • check that the vehicle is in neutral by pushing it. NUOVA PANDA Interventions with flat battery... -
Page 14: Vehicle Towing/Lifting
General warnings for towing Before towing, make sure that the tow hook is fully tightened. Clean the threaded seat carefully before tightening the hook. Turn the ignition key to ON and then to OFF and DO NOT EXTRACT IT. NUOVA PANDA Vehicle towing/lifting... -
Page 15: Vehicle Lifting Points
4.3 "Robotised gearbox - engagement of Neutral". Failure to observe the above instructions could cause severe damage to the gearbox. Vehicle lifting points When lifting the vehicle with a portable jack or a workshop lift, place the mountings only in the areas shown in the figure. NUOVA PANDA Vehicle towing/lifting... -
Page 16: T E C Hni C Al Sp Ec I Fi Cat I O Ns
SAE 5W-30 SELENIA WR P.E. COOLANT CUNA NC 956-16, ASTM D 3306 MIXTURE OF PARAFLU UP AND 50% DEMINERALISED WATER FLUID FOR BRAKE/CLUTCH FMVSS No. 116 DOT 4, ISO 4925, SAE J 1704 TUTELA TOP 4 NUOVA PANDA Technical specifications...
