Blodgett B24C-GG Specifications

B24-GG and B24-TT
24" Heavy Duty Sectional Range with
Full Width Griddle
Model B24C-GG with 24" Flue Riser
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Flue riser
24"
36"
Single-shelf (mounts on 24" flue riser)
Solid shelf
Tubed shelf
Double-shelf (mounts on 36" flue riser)
Solid shelves
Tubed shelves
Stainless-steel back
Deep range depth
Bolt down flange feet
Casters (in lieu of legs)
Open frame base with casters
Cable restraint kit for units on casters
Project
Item No.
Quantity
Model B24C-GG (Standard Griddle with Cabinet Base)
Model B24N-GG (Standard Griddle with Modular Range-Top)
Model B24C-TT (Thermostatic Griddle with Cabinet Base)
Model B24N-TT (Thermostatic Griddle with Modular Range-Top)
The Blodgett 24"-wide sectional-range with full width griddle is available
with a either a storage cabinet or with no base (for mounting as a modular
range-top). Three flue-riser heights are available, and the flue riser can
support up to 250 lbs for an optional shelf. An optional rearward-extending
flue riser is available to increase the overall depth to match a deep battery.
Battery-design assistance is available!
SPECIFY
Gas Type
Manifold
Flue Riser Height
Range Depth
Position in Battery
Operating altitude (if above 2000 ft (700 meters) _____________________
Blodgett can often accommodate special or custom requirements. Contact your
Blodgett representative.
STANDARD FEATURES (
Two 32,000 BTU 12" sections with separate controls
1" thick steel surface with side splashers
Grease drawer holds 3/4 gallon
5" flue riser
7" stainless-steel front rail with "belly bar"
Standard range depth
Battery end-units have solid side (no manifold cover plate)
Stainless-steel front and sides
Fully insulated lining and burner boxes
6" adjustable legs (except on modular range-top model)
Warranty: two year parts and labor from date of purchase
STANDARD FEATURES (
Dual side by side stainless-steel doors
BLODGETT
www.blodgett.com
1100 Old Honeycutt Road Fuquay-Varina, NC 27526 USA
Phone: (877) 255-3976 • Fax: (866) 644-1354
Natural Gas Propane
Front (1-1/4") Rear (1")
5" 24" (option)
Standard Deep (option)
Left End Right End
)
All models
)
Base Cabinets
36" (option)
Not at End
