Broan NuTone Overture 1103435 User Manual

INCLUDED
Room Sensor Part No. 1103435
User Manual
Quick Start Guide
CONTROL SPECIFICATIONS
• cULus Listed
• 120 VAC 60 Hz Line Power
• Requires NEMA 5-15R or 5-20R Receptacle
• Maximum load ½ HP Motor, 15A Resistive,
15A Inductive, 3A Incandescent, 0.6A Electronic Ballast
• For Control of Electronic Ballast, CFLs, LED and LED
lamps
• Operating temperature: 32-95°F (0-35°C)
• Purpose of Control: Operating Control
• Rated impulse voltage: 1500 V
SAFETY
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOWING:
1. Install only in a UL Listed NEMA 5-15R or NEMA
5-20R receptacle. The socket-outlet shall be installed
near the equipment and shall be easily accessible.
NOTE: This device shall not be used in combination
with a wall switch controlled receptacle.
2. The automatic operation feature is Type 1 action,
according to UL 60730-1.
3. The enclosure protection rating is IP10.
4. The product is Pollution Degree 2, which is intended
to be used in a household environment or similar.
5. The devices are not intended for use in locations
where the temperature may be less than actual room
conditions, such as unheated warehouses or garages.
6. Avoid water and wet locations. Keep the device
away from water, fire, excessive humidity, or hot
environments.
7. Do not use the device where wireless devices are not
allowed.
8. For passthrough devices, plug the power strips into
the integrated electrical sockets of the devices, but
devices of the same or another type not be stacked in
normal use.
9. Do not attempt to disassemble, repair, or modify the
device. Don't disassemble the product, or make repairs
yourself. You run the risk of electric shock and voiding
the limited warranty. If you need service, please contact
us.
10. Note: When power is applied, the Room Sensor may
require approximately 30 seconds to boot up and be
ready to function.
11. Please read and follow the above safety information
when operating the device. We cannot guarantee that
no accidents or damage will occur due to the improper
use of the device. Please use this product with care
and operate at your own risk.
TM
Overture ROOM SENSOR
INSTALLATION
1. Verify Room Sensor orientation before installation.
Note "TOP" direction shown on the Room Sensor label.
2. Location Notes:
a. Placing the Room Sensor directly above a heater
or near drafts is NOT recommended. Ideal places for
room sensors are bedrooms, family/living rooms,
dens, laundry rooms, etc. Be sure Room Sensor has
adequate airflow in order to have high performance
monitoring. Placing directly behind a dresser,
couch, etc. will prohibit adequate airflow.
b. For bathroom applications, the Room Sensor should
be placed in close proximity to the shower/tub/sink,
etc. (main source of humidity and steam/VOCs) and at
sink height or higher for effective monitoring of your
indoor air quality.
c. Place your Room Sensor within the range of your
Wi-Fi router or access point (approximately 100 feet).
d. Avoid physical obstructions and radio interference
in the surrounding area.
e. Download the Broan-NuTone Overture
step by step set-up instructions to connect your Room
TM
Sensor to the Overture system. Scan QR code to go
to App Store.
For Warranty Statement, Service Parts, Technical
Support, or to Register your product, please visit our
website or call: In the United States - Broan-NuTone.com
800-558-1711. In Canada - Broan.ca or NuTone.ca
877-896-1119
Regulatory Information
TM
The Overture Room Sensor 1103435 is certified to
comply with applicable FCC and IC rules and regulations
governing RF and EMI emissions. Refer to 1103435. This
device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) This device must
accept any interference received, including interference
that may cause undesired operation.
FCC Notice
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in
a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions
may cause harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician to help.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
ISED Compliance Statement
This device contains licence-exempt transmitter(s)/
receiver(s) that comply with Innovation, Science and
Economic Development Canada's licence-exempt RSS(s).
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including
interference that may cause undesired operation of the
device.
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use
of such marks by Broan-NuTone LLC is under license.
Other trademarks and trade names are those of their
respective owners.
The Android robot is reproduced or modified from work
created and shared by Google and used according to
terms described in the Creative Commons 3.0 Attribution
License.
TM App for
Regulatory ID for 1103435 Overture
FCC ID: 2ADLL-1103435
IC: 2143B-1103435
Made in China to the quality standards and
specifications of
Broan-Nutone LLC Hartford, Wisconsin
www.broan-nutone.com 800-558-1711
Venmar Ventilation ULC Drummondville Quebec Canada
www.broan.ca or www.nutone.ca 877-896-1119
For more information and user manuals scan QR code
below.
The distance between user and device should be no less
than 20cm.
la distance entre l'utilisation et l'appareil ne doit pas
être inférieure à 20 cm.
TM
Room Sensor
1103416A
